As usual with complex problems, explaining what the problem is, is more difficult than explaining the solution. So bear with me.

The goal of a machine learning regression problem is to predict a single numeric value. For example, a bank might want to predict the maximum safe loan amount to a customer, based on age, account balance, current debt, and so on.

There are many regression techniques. The techniques fall into two main categories: 1.) classical math-based techniques (linear regression, nearest neighbors regression, quadratic regression, kernel ridge regression, neural network regression, and others) and 2.) tree-based techniques (random forest regression, Extra Trees (“extreme random”) regression, AdaBoost regression, Gradient Boost regression, and others).

The tree-based Gradient Boosting regression technique uses a collection of simple decision trees — they’re called the learners or the estimators. Each tree is constructed sequentially, based on error information of the previous tree. Each tree gets slightly better. The final prediction is based on the sum of indirect predictions of the trees (it’s very subtle and extremely complicated to explain).

Although Gradient Boosting regression almost always uses standard decision trees as the learners, in theory, any kind of simple regression technique can be used. Paradoxically, the base learners need to be weak instead of powerful, but that’s another long and complicated story.

I decided to implement Gradient Boost regression using Extra Trees learners. Bottom line: For my demo dataset, the technique worked surprisingly well.

Extra Trees are even weaker than standard decision trees. When constructing a standard decision tree, for each tree node, an optimal split column and split value are found (where “optimal” is a complex topic). When constructing an Extra Trees tree, for each node, a random split value is selected from each column, and then the best of those is used. So Extra Trees trees have a kind of built-in regularization that, at least in one experiment, help Gradient Boost regression.

For my demo, I used one of my standard datasets It looks like:

-0.1660,  0.4406, -0.9998, -0.3953, -0.7065,  0.4840
 0.0776, -0.1616,  0.3704, -0.5911,  0.7562,  0.1568
-0.9452,  0.3409, -0.1654,  0.1174, -0.7192,  0.8054
. . .

The data is synthetic. The first five values on each line are the predictors. The last value on each line is the target to predict. There are 200 training items and 40 test items.

The key parts of the output of my demo are:

Begin C# Gradient Boosting with Extra Trees demo

Loading synthetic train (200) and test (40) data
Done

First three train X:
 -0.1660  0.4406 -0.9998 -0.3953 -0.7065
  0.0776 -0.1616  0.3704 -0.5911  0.7562
 -0.9452  0.3409 -0.1654  0.1174 -0.7192

First three train y:
  0.4840
  0.1568
  0.8054

Setting numTrees = 800
Setting maxDepth = 4
Setting minSamples = 2
Setting minLeaf = 1
Setting lrnRate = 0.0500

Creating and training GradientBoostRegression model
Done

Evaluating model

Accuracy train (within 0.10) = 1.0000
Accuracy test (within 0.10) = 0.8750

MSE train = 0.0000
MSE test = 0.0005

R2 train = 1.0000
R2 test = 0.9835

Predicting for x =
  -0.1660   0.4406  -0.9998  -0.3953  -0.7065

Initial prediction: 0.3493
t =   0  pred_res =  0.0935  delta =  0.0047  pred =  0.3540
t =   1  pred_res = -0.0017  delta = -0.0001  pred =  0.3539
t =   2  pred_res =  0.1130  delta =  0.0056  pred =  0.3596
t =   3  pred_res =  0.0108  delta =  0.0005  pred =  0.3601
t =   4  pred_res =  0.1886  delta =  0.0094  pred =  0.3695
. . .
t = 798  pred_res = -0.0001  delta = -0.0000  pred =  0.4838
t = 799  pred_res =  0.0001  delta =  0.0000  pred =  0.4838
Predicted y = 0.4838

End demo

A very interesting investigation.

Gradient Boost regression code is a wrapper around a collection of weak learners. I’m a big fan of science fiction movies of the 1950s. Many of these movies had creatures that were actors wrapped in costumes of some kind.

Right: In “The Mole People” (1956), an expedition of archaeologists in the Himalayan Mountains discover an underground civilization created by Sumerian descendants. The neo-Sumerians use mole people as slaves to tend to their fungus farms. Objectively, this movie isn’t very good, but I like it anyway. My grade = solid B.

Demo program. Very long, quite complex. Replace “lt” (less than), “gt”, “lte”, “gte” with Boolean operator symbols. (My blog editor chokes on symbols).

using System;
using System.IO;
using System.Collections.Generic;

namespace GradientBoostWithExtraTrees
{
  internal class GradientBoostWithExtraTreesProgram
  {
    static void Main(string[] args)
    {
      Console.WriteLine("\nBegin C# Gradient Boosting" +
        " with Extra Trees demo ");

      // 1. load data
      Console.WriteLine("\nLoading synthetic train" +
        " (200) and test (40) data");
      string trainFile =
        "..\\..\\..\\Data\\synthetic_train_200.txt";
      int[] colsX = new int[] { 0, 1, 2, 3, 4 };
      double[][] trainX =
        MatLoad(trainFile, colsX, ',', "#");
      double[] trainY =
        MatToVec(MatLoad(trainFile,
        [5], ',', "#"));

      string testFile =
        "..\\..\\..\\Data\\synthetic_test_40.txt";
      double[][] testX =
        MatLoad(testFile, colsX, ',', "#");
      double[] testY =
        MatToVec(MatLoad(testFile,
        [5], ',', "#"));
      Console.WriteLine("Done ");

      Console.WriteLine("\nFirst three train X: ");
      for (int i = 0; i "lt" 3; ++i)
        VecShow(trainX[i], 4, 8);

      Console.WriteLine("\nFirst three train y: ");
      for (int i = 0; i "lt" 3; ++i)
        Console.WriteLine(trainY[i].ToString("F4").
          PadLeft(8));

      // 2. create and train model
            int numTrees = 800;
      int maxDepth = 4;
      int minSamples = 2;
      int minLeaf = 1;
      int numSplitCols = -1; // use all columns
      double lrnRate = 0.05;  // 1.0000 .8750 .0000 .0005

      Console.WriteLine("\nSetting numTrees = " +
        numTrees);
      Console.WriteLine("Setting maxDepth = " +
        maxDepth);
      Console.WriteLine("Setting minSamples = " +
        minSamples);
      Console.WriteLine("Setting minLeaf = " +
        minLeaf);
      Console.WriteLine("Setting lrnRate = " +
        lrnRate.ToString("F4"));

      Console.WriteLine("\nCreating and training" +
        " GradientBoostRegression model ");
      GradientBoostRegressor gbr =
        new GradientBoostRegressor(numTrees, maxDepth,
        minSamples, minLeaf, numSplitCols, lrnRate);
      gbr.Train(trainX, trainY);
      Console.WriteLine("Done ");

      // 3. evaluate model
      Console.WriteLine("\nEvaluating model ");
      double accTrain = gbr.Accuracy(trainX, trainY, 0.10);
      Console.WriteLine("\nAccuracy train (within 0.10) = " +
        accTrain.ToString("F4"));
      double accTest = gbr.Accuracy(testX, testY, 0.10);
      Console.WriteLine("Accuracy test (within 0.10) = " +
        accTest.ToString("F4"));

      double mseTrain = gbr.MSE(trainX, trainY);
      Console.WriteLine("\nMSE train = " +
        mseTrain.ToString("F4"));
      double mseTest = gbr.MSE(testX, testY);
      Console.WriteLine("MSE test = " +
        mseTest.ToString("F4"));

      double r2Train = gbr.R2(trainX, trainY);
      Console.WriteLine("\nR2 train = " +
        r2Train.ToString("F4"));
      double r2Test = gbr.R2(testX, testY);
      Console.WriteLine("R2 test = " +
        r2Test.ToString("F4"));

      // 4. use model
      double[] x = trainX[0];
      Console.WriteLine("\nPredicting for x = ");
      VecShow(x, 4, 9);
      double predY = gbr.Predict(x, verbose: true);
      Console.WriteLine("Predicted y = " +
        predY.ToString("F4"));

      Console.WriteLine("\nEnd demo ");
      Console.ReadLine();
    } // Main()

    // ------------------------------------------------------
    // helpers for Main()
    // ------------------------------------------------------

    static double[][] MatLoad(string fn, int[] usecols,
      char sep, string comment)
    {
      List"lt"double[]"gt" result = new List"lt"double[]"gt"();
      string line = "";
      FileStream ifs = new FileStream(fn, FileMode.Open);
      StreamReader sr = new StreamReader(ifs);
      while ((line = sr.ReadLine()) != null)
      {
        if (line.StartsWith(comment) == true)
          continue;
        string[] tokens = line.Split(sep);
        List"lt"double"gt" lst = new List"lt"double"gt"();
        for (int j = 0; j "lt" usecols.Length; ++j)
          lst.Add(double.Parse(tokens[usecols[j]]));
        double[] row = lst.ToArray();
        result.Add(row);
      }
      sr.Close(); ifs.Close();
      return result.ToArray();
    }

    static double[] MatToVec(double[][] mat)
    {
      int nRows = mat.Length;
      int nCols = mat[0].Length;
      double[] result = new double[nRows * nCols];
      int k = 0;
      for (int i = 0; i "lt" nRows; ++i)
        for (int j = 0; j "lt" nCols; ++j)
          result[k++] = mat[i][j];
      return result;
    }

    static void VecShow(double[] vec, int dec, int wid)
    {
      for (int i = 0; i "lt" vec.Length; ++i)
        Console.Write(vec[i].ToString("F" + dec).
          PadLeft(wid));
      Console.WriteLine("");
    }

  } // class Program

  // ========================================================

  public class GradientBoostRegressor
  {
    public double lrnRate;
    public int nTrees;
    public int maxDepth;
    public int minSamples;
    public int minLeaf;
    public int numSplitCols;
    public List"lt"ExtraTreesBaseTree"gt" trees;
    public double pred0;  // initial prediction
    private Random rnd;

    public GradientBoostRegressor(int nTrees, int maxDepth,
      int minSamples, int minLeaf, int numSplitCols,
      double lrnRate, int seed=0)
    {
      this.nTrees = nTrees;
      this.maxDepth = maxDepth;
      this.minSamples = minSamples;
      this.minLeaf = minLeaf;
      this.numSplitCols = numSplitCols;
      this.trees = new List"lt"ExtraTreesBaseTree"gt"();
      this.lrnRate = lrnRate;
      this.rnd = new Random(seed);
    }

    public void Train(double[][] trainX, double[] trainY)
    {
      int n = trainX.Length;
      this.pred0 = Mean(trainY);

      double[] preds = new double[n]; //each data item
      for (int i = 0; i "lt" n; ++i)
        preds[i] = this.pred0;

      for (int t = 0; t "lt" this.nTrees; ++t) // each tree
      {
        double[] residuals = new double[n]; // for curr tree
        for (int i = 0; i "lt" n; ++i)
          residuals[i] = trainY[i] - preds[i];

        ExtraTreesBaseTree et =
          new ExtraTreesBaseTree(this.maxDepth,
          this.minSamples, this.minLeaf, this.numSplitCols,
          false, this.rnd.Next(0,1_000_000));
        et.Train(trainX, residuals); // predict residuals

        for (int i = 0; i "lt" n; ++i)
        {
          double predResidual = et.Predict(trainX[i]);
          preds[i] += this.lrnRate * predResidual;
        }
        this.trees.Add(et);
      }
    } // Train

    public double Predict(double[] x, bool verbose = false)
    {
      double result = this.pred0;
      if (verbose == true)
      {
        Console.WriteLine("\nInitial prediction: " +
        result.ToString("F4"));
      }
      for (int t = 0; t "lt" this.nTrees; ++t)
      {
        double predResidual = this.trees[t].Predict(x);
        double delta = this.lrnRate * predResidual;
        result += delta;

        if (verbose == true)
        {
          if (t "gte" 0 && t "lte" 4 || t "gte" this.nTrees - 2 &&
            t "lte" this.nTrees - 1)
          {
            Console.Write("t = " + t.ToString().PadLeft(3) +
              "  pred_res = " + predResidual.ToString("F4").
              PadLeft(7));
            Console.Write("  delta = " + delta.ToString("F4").
              PadLeft(7));
            Console.WriteLine("  pred = " +
              result.ToString("F4").PadLeft(7));
          }
          if (t == 5)
            Console.WriteLine(". . . ");
        }
      }
      return result;
    }

    public double Accuracy(double[][] dataX, double[] dataY,
      double pctClose)
    {
      int numCorrect = 0; int numWrong = 0;
      for (int i = 0; i "lt" dataX.Length; ++i)
      {
        double actualY = dataY[i];
        double predY = Predict(dataX[i]);
        if (Math.Abs(predY - actualY) "lt"
          (pctClose * Math.Abs(actualY)))
          ++numCorrect;
        else
          ++numWrong;
      }
      return (numCorrect * 1.0) / (numWrong + numCorrect);
    }

    public double MSE(double[][] dataX,
      double[] dataY)
    {
      int n = dataX.Length;
      double sum = 0.0;
      for (int i = 0; i "lt" n; ++i)
      {
        double actualY = dataY[i];
        double predY = this.Predict(dataX[i]);
        sum += (actualY - predY) * (actualY - predY);
      }
      return sum / n;
    }

    public double R2(double[][] dataX, double[] dataY)
    {
      // coefficient of determination
      int n = dataX.Length;
      double sum = 0.0;

      for (int i = 0; i "lt" n; ++i)
        sum += dataY[i];
      double meanActual = sum / n;

      double ssRes = 0.0;
      double ssTot = 0.0;
      for (int i = 0; i "lt" n; ++i)
      {
        double predY = this.Predict(dataX[i]);
        ssRes += (dataY[i] - predY) * (dataY[i] - predY);
        ssTot += (dataY[i] - meanActual) *
          (dataY[i] - meanActual);
      }
      if (Math.Abs(ssTot) "lt" 1.0e-12)
        return 0.0;
      else
        return 1.0 - (ssRes / ssTot);
    }

    private static double Mean(double[] data)
    {
      int n = data.Length;
      double sum = 0.0;
      for (int i = 0; i "lt" n; ++i)
        sum += data[i];
      return sum / n;
    }

  } // class GradientBoostRegression

  // ========================================================
  // ========================================================

  public class ExtraTreesBaseTree
  {
    // same as DecisionTreeRegressor except BestSplit()
    public int maxDepth;
    public int minSamples;  // aka min_samples_split
    public int minLeaf;  // min number of values in a leaf
    public int numSplitCols;
    public List"lt"Node"gt" tree;
    public Random rnd;  // order in which cols are searched
    public bool saveRows;  // keep rows in Nodes after train

    public double[][] trainX;  // store data by ref
    public double[] trainY;    // more convenient

    // ------------------------------------------------------

    public class Node
    {
      public int id;
      public int colIdx;      // aka feature index
      public double thresh;   // aka split value
      public int left;        // index into List
      public int right;
      public double value;    // aka predicted y
      public bool isLeaf;
      public List"lt"int"gt" rows;  // assoc rows in train data

      public Node()
      {
        this.id = -1;
        this.colIdx = -1;
        this.thresh = 0.0;
        this.left = -1;
        this.right = -1;
        this.value = 0.0;  // aka pred y
        this.isLeaf = false;
        this.rows = null;
      }
    } // class Node

    // ------------------------------------------------------

    public ExtraTreesBaseTree(int maxDepth = 2,
      int minSamples = 2, int minLeaf = 1,
      int numSplitCols = -1, bool saveRows = false,
      int seed = 0)
    {
      // if maxDepth = n, at most 2^(n+1) - 1 nodes
      this.maxDepth = maxDepth;
      this.minSamples = minSamples;
      this.minLeaf = minLeaf;
      this.numSplitCols = numSplitCols;  // -1 = all
      this.saveRows = saveRows;

      this.tree = new List"lt"Node"gt"();

      // create full tree List with null nodes
      int numNodes = (int)Math.Pow(2, (maxDepth + 1)) - 1;
      for (int i = 0; i "lt" numNodes; ++i)
        this.tree.Add(null);  // empty nodes

      this.rnd = new Random(seed);
    }

    // ------------------------------------------------------
    // public: ctor(), Train(), Predict()
    // private helpers: BestSplit(), TreeTargetMean()
    // ------------------------------------------------------

    public void Train(double[][] trainX, double[] trainY)
    {
      this.trainX = trainX; // useful to avoid passing args
      this.trainY = trainY;

      int maxID = (int)Math.Pow(2, (this.maxDepth + 1)) - 2;
      int maxStartID = (int)Math.Pow(2, this.maxDepth) - 1;

      // prepare root node
      List"lt"int"gt" allRows = new List"lt"int"gt"();
      for (int i = 0; i "lt" this.trainX.Length; ++i)
        allRows.Add(i);
      double grandMean = this.TreeTargetMean(allRows);

      // wait to supply root colIdx and thresh in main loop
      Node root = new Node();
      root.id = 0;
      root.left = 1;
      root.right = 2;
      root.value = grandMean;
      root.isLeaf = false; // (already set)
      root.rows = allRows;
      this.tree[0] = root;

      for (int i = 0; i "lt" this.tree.Count; ++i)
      {
        Node currNode = this.tree[i];
        if (currNode == null) continue;

        if (currNode.id "gte" maxStartID ||
          currNode.rows.Count "lt" this.minSamples)
        {
          // unable to attempt split
          currNode.isLeaf = true;
          continue;
        }

        // try to split curr node
        double[] splitInfo = this.BestSplit(currNode.rows);
        int colIdx = (int)splitInfo[0];
        double splitVal = splitInfo[1];  //split value

        if (colIdx == -1)  // bad split
        {
          currNode.isLeaf = true;
          currNode.left = -1;
          currNode.right = -1;
          continue;
        }

        // got successful split info
        // complete the fields for curr node
        currNode.colIdx = colIdx;
        currNode.thresh = splitVal;

        // compute associated rows for the children
        List"lt"int"gt" leftIdxs = new List"lt"int"gt"();
        List"lt"int"gt" rightIdxs = new List"lt"int"gt"();
        for (int k = 0; k "lt" currNode.rows.Count; ++k)
        {
          int r = currNode.rows[k];
          if (this.trainX[r][colIdx] "lte" splitVal)
            leftIdxs.Add(r);
          else
            rightIdxs.Add(r);
        }

        // explicitly assign child structural
        // pointers to the parent node
        int leftID = currNode.id * 2 + 1;
        if (leftID "lte" maxID && leftIdxs.Count "gte" this.minLeaf)
        {
          currNode.left = leftID;
          Node leftNode = new Node();
          leftNode.id = leftID;
          leftNode.rows = leftIdxs;
          leftNode.value =
            this.TreeTargetMean(leftNode.rows);
          this.tree[leftID] = leftNode;
        }
        else
        {
          currNode.left = -1;
        }

        int rightID = currNode.id * 2 + 2;
        if (rightID "lte" maxID &&
          rightIdxs.Count "gte" this.minLeaf)
        {
          currNode.right = rightID;
          Node rightNode = new Node();
          rightNode.id = rightID;
          rightNode.rows = rightIdxs;
          rightNode.value =
            this.TreeTargetMean(rightNode.rows);
          this.tree[rightID] = rightNode;
        }
        else
        {
          currNode.right = -1;
        }

        // if child splits could not be formed
        // adequately, default parent to leaf
        if (currNode.left == -1 && currNode.right == -1)
        {
          currNode.isLeaf = true;
        }
      }

      if (this.saveRows == false)
      {
        for (int i = 0; i "lt" this.tree.Count; ++i)
          if (this.tree[i] != null)
            this.tree[i].rows = null;
      }
    } // Train()

    // ------------------------------------------------------------------------

    public double Predict(double[] x)
    {
      int p = 0;
      double lastValidValue = 0.0;

      while (p != -1 && p "lt" this.tree.Count)
      {
        Node currNode = this.tree[p];
        if (currNode == null) break;

        lastValidValue = currNode.value;
        if (currNode.isLeaf == true) break;

        if (x[currNode.colIdx] "lte" currNode.thresh)
          p = currNode.left;
        else
          p = currNode.right;
      }
      return lastValidValue;
    }

    // ------------------------------------------------------------------------
    // helpers: BestSplit(), TreeTargetMean()
    // ------------------------------------------------------------------------

    private double[] BestSplit(List"lt"int"gt" rows)
    {
      // special algorithm for Extra Trees Regression
      int bestColIdx = -1;
      double bestThresh = 0.0;
      double bestVar = double.MaxValue;

      int nRows = rows.Count;
      int nCols = this.trainX[0].Length;

      if (nRows == 0)
        throw new Exception("Empty data in BestSplit()");

      // 1. Fisher-Yates the columns
      int[] colIndices = new int[nCols];
      for (int k = 0; k "lt" nCols; ++k) colIndices[k] = k;

      for (int i = 0; i "lt" nCols - 1; ++i)
      {
        int ri = rnd.Next(i, nCols);
        int tmp = colIndices[i];
        colIndices[i] = colIndices[ri];
        colIndices[ri] = tmp;
      }

      int nColsToUse;
      if (this.numSplitCols != -1)
        nColsToUse = Math.Min(this.numSplitCols, nCols);
      else
        nColsToUse = nCols;

      int[] activeCols = new int[nColsToUse];
      for (int i = 0; i "lt" nColsToUse; ++i)
        activeCols[i] = colIndices[i];

      // pre-calculate total sums for the rows at this node
      double totalSumY = 0.0;
      double totalSumSqY = 0.0;
      for (int i = 0; i "lt" nRows; ++i)
      {
        int r = rows[i];
        double y = this.trainY[r];
        totalSumY += y;
        totalSumSqY += y * y;
      }

      // evaluate a random thresh in each active column
      for (int j = 0; j "lt" activeCols.Length; ++j)
      {
        int currColIdx = activeCols[j];

        // find min and max val in curr column
        // for the current rows
        double minVal = double.MaxValue;
        double maxVal = double.MinValue;
        for (int i = 0; i "lt" nRows; ++i)
        {
          int r = rows[i];
          double currVal = this.trainX[r][currColIdx];
          if (currVal "lt" minVal) minVal = currVal;
          if (currVal "gt" maxVal) maxVal = currVal;
        }

        if (minVal == maxVal)
          continue; // Cannot split this column

        double ranSplitVal = (maxVal - minVal) *
          this.rnd.NextDouble() + minVal;

        int leftCount = 0;
        int rightCount = 0;
        double leftSumY = 0.0;
        double leftSumSqY = 0.0;

        for (int i = 0; i "lt" nRows; ++i)
        {
          int r = rows[i];
          double yCurr = this.trainY[r];
          if (this.trainX[r][currColIdx] "lte" ranSplitVal)
          {
            ++leftCount;
            leftSumY += yCurr;
            leftSumSqY += yCurr * yCurr;
          }
          else
          {
            ++rightCount;
          }
        }

        // enforce minLeaf
        if (leftCount "lt" this.minLeaf ||
          rightCount "lt" this.minLeaf)
          continue;

        double rightSumY = totalSumY - leftSumY;
        double rightSumSqY = totalSumSqY - leftSumSqY;

        double tmp1 =
        (leftSumY / leftCount) * (leftSumY / leftCount);
        double leftVar = (leftSumSqY / leftCount) - tmp1;

        double tmp2 =
        (rightSumY / rightCount) * (rightSumY / rightCount);
        double rightVar = (rightSumSqY / rightCount) - tmp2;

        if (leftVar "lt" 0.0) leftVar = 0.0;
        if (rightVar "lt" 0.0) rightVar = 0.0;

        double weightedVar =
          ((leftCount * leftVar) +
          (rightCount * rightVar)) / nRows;

        if (weightedVar "lt" bestVar)
        {
          bestVar = weightedVar;
          bestColIdx = currColIdx;
          bestThresh = ranSplitVal;
        }
      }

      double[] result = new double[2];
      result[0] = 1.0 * bestColIdx;
      result[1] = bestThresh;
      return result;
    }

    // ------------------------------------------------------

    private double TreeTargetMean(List"lt"int"gt" rows)
    {
      // mean of rows items in trainY
      // for node prediction
      if (rows == null || rows.Count == 0) return 0.0;
      double sum = 0.0;
      for (int i = 0; i "lt" rows.Count; ++i)
      {
        int r = rows[i];
        sum += this.trainY[r];
      }
      return sum / rows.Count;
    }

  } // class ExtraTreesBaseTree

  // ========================================================

} // ns

Training data:

# synthetic_train_200.txt
#
-0.1660,  0.4406, -0.9998, -0.3953, -0.7065,  0.4840
 0.0776, -0.1616,  0.3704, -0.5911,  0.7562,  0.1568
-0.9452,  0.3409, -0.1654,  0.1174, -0.7192,  0.8054
 0.9365, -0.3732,  0.3846,  0.7528,  0.7892,  0.1345
-0.8299, -0.9219, -0.6603,  0.7563, -0.8033,  0.7955
 0.0663,  0.3838, -0.3690,  0.3730,  0.6693,  0.3206
-0.9634,  0.5003,  0.9777,  0.4963, -0.4391,  0.7377
-0.1042,  0.8172, -0.4128, -0.4244, -0.7399,  0.4801
-0.9613,  0.3577, -0.5767, -0.4689, -0.0169,  0.6861
-0.7065,  0.1786,  0.3995, -0.7953, -0.1719,  0.5569
 0.3888, -0.1716, -0.9001,  0.0718,  0.3276,  0.2500
 0.1731,  0.8068, -0.7251, -0.7214,  0.6148,  0.3297
-0.2046, -0.6693,  0.8550, -0.3045,  0.5016,  0.2129
 0.2473,  0.5019, -0.3022, -0.4601,  0.7918,  0.2613
-0.1438,  0.9297,  0.3269,  0.2434, -0.7705,  0.5171
 0.1568, -0.1837, -0.5259,  0.8068,  0.1474,  0.3307
-0.9943,  0.2343, -0.3467,  0.0541,  0.7719,  0.5581
 0.2467, -0.9684,  0.8589,  0.3818,  0.9946,  0.1092
-0.6553, -0.7257,  0.8652,  0.3936, -0.8680,  0.7018
 0.8460,  0.4230, -0.7515, -0.9602, -0.9476,  0.1996
-0.9434, -0.5076,  0.7201,  0.0777,  0.1056,  0.5664
 0.9392,  0.1221, -0.9627,  0.6013, -0.5341,  0.1533
 0.6142, -0.2243,  0.7271,  0.4942,  0.1125,  0.1661
 0.4260,  0.1194, -0.9749, -0.8561,  0.9346,  0.2230
 0.1362, -0.5934, -0.4953,  0.4877, -0.6091,  0.3810
 0.6937, -0.5203, -0.0125,  0.2399,  0.6580,  0.1460
-0.6864, -0.9628, -0.8600, -0.0273,  0.2127,  0.5387
 0.9772,  0.1595, -0.2397,  0.1019,  0.4907,  0.1611
 0.3385, -0.4702, -0.8673, -0.2598,  0.2594,  0.2270
-0.8669, -0.4794,  0.6095, -0.6131,  0.2789,  0.4700
 0.0493,  0.8496, -0.4734, -0.8681,  0.4701,  0.3516
 0.8639, -0.9721, -0.5313,  0.2336,  0.8980,  0.1412
 0.9004,  0.1133,  0.8312,  0.2831, -0.2200,  0.1782
 0.0991,  0.8524,  0.8375, -0.2102,  0.9265,  0.2150
-0.6521, -0.7473, -0.7298,  0.0113, -0.9570,  0.7422
 0.6190, -0.3105,  0.8802,  0.1640,  0.7577,  0.1056
 0.6895,  0.8108, -0.0802,  0.0927,  0.5972,  0.2214
 0.1982, -0.9689,  0.1870, -0.1326,  0.6147,  0.1310
-0.3695,  0.7858,  0.1557, -0.6320,  0.5759,  0.3773
-0.1596,  0.3581,  0.8372, -0.9992,  0.9535,  0.2071
-0.2468,  0.9476,  0.2094,  0.6577,  0.1494,  0.4132
 0.1737,  0.5000,  0.7166,  0.5102,  0.3961,  0.2611
 0.7290, -0.3546,  0.3416, -0.0983, -0.2358,  0.1332
-0.3652,  0.2438, -0.1395,  0.9476,  0.3556,  0.4170
-0.6029, -0.1466, -0.3133,  0.5953,  0.7600,  0.4334
-0.4596, -0.4953,  0.7098,  0.0554,  0.6043,  0.2775
 0.1450,  0.4663,  0.0380,  0.5418,  0.1377,  0.2931
-0.8636, -0.2442, -0.8407,  0.9656, -0.6368,  0.7429
 0.6237,  0.7499,  0.3768,  0.1390, -0.6781,  0.2185
-0.5499,  0.1850, -0.3755,  0.8326,  0.8193,  0.4399
-0.4858, -0.7782, -0.6141, -0.0008,  0.4572,  0.4197
 0.7033, -0.1683,  0.2334, -0.5327, -0.7961,  0.1776
 0.0317, -0.0457, -0.6947,  0.2436,  0.0880,  0.3345
 0.5031, -0.5559,  0.0387,  0.5706, -0.9553,  0.3107
-0.3513,  0.7458,  0.6894,  0.0769,  0.7332,  0.3170
 0.2205,  0.5992, -0.9309,  0.5405,  0.4635,  0.3532
-0.4806, -0.4859,  0.2646, -0.3094,  0.5932,  0.3202
 0.9809, -0.3995, -0.7140,  0.8026,  0.0831,  0.1600
 0.9495,  0.2732,  0.9878,  0.0921,  0.0529,  0.1289
-0.9476, -0.6792,  0.4913, -0.9392, -0.2669,  0.5966
 0.7247,  0.3854,  0.3819, -0.6227, -0.1162,  0.1550
-0.5922, -0.5045, -0.4757,  0.5003, -0.0860,  0.5863
-0.8861,  0.0170, -0.5761,  0.5972, -0.4053,  0.7301
 0.6877, -0.2380,  0.4997,  0.0223,  0.0819,  0.1404
 0.9189,  0.6079, -0.9354,  0.4188, -0.0700,  0.1907
-0.1428, -0.7820,  0.2676,  0.6059,  0.3936,  0.2790
 0.5324, -0.3151,  0.6917, -0.1425,  0.6480,  0.1071
-0.8432, -0.9633, -0.8666, -0.0828, -0.7733,  0.7784
-0.9444,  0.5097, -0.2103,  0.4939, -0.0952,  0.6787
-0.0520,  0.6063, -0.1952,  0.8094, -0.9259,  0.4836
 0.5477, -0.7487,  0.2370, -0.9793,  0.0773,  0.1241
 0.2450,  0.8116,  0.9799,  0.4222,  0.4636,  0.2355
 0.8186, -0.1983, -0.5003, -0.6531, -0.7611,  0.1511
-0.4714,  0.6382, -0.3788,  0.9648, -0.4667,  0.5950
 0.0673, -0.3711,  0.8215, -0.2669, -0.1328,  0.2677
-0.9381,  0.4338,  0.7820, -0.9454,  0.0441,  0.5518
-0.3480,  0.7190,  0.1170,  0.3805, -0.0943,  0.4724
-0.9813,  0.1535, -0.3771,  0.0345,  0.8328,  0.5438
-0.1471, -0.5052, -0.2574,  0.8637,  0.8737,  0.3042
-0.5454, -0.3712, -0.6505,  0.2142, -0.1728,  0.5783
 0.6327, -0.6297,  0.4038, -0.5193,  0.1484,  0.1153
-0.5424,  0.3282, -0.0055,  0.0380, -0.6506,  0.6613
 0.1414,  0.9935,  0.6337,  0.1887,  0.9520,  0.2540
-0.9351, -0.8128, -0.8693, -0.0965, -0.2491,  0.7353
 0.9507, -0.6640,  0.9456,  0.5349,  0.6485,  0.1059
-0.0462, -0.9737, -0.2940, -0.0159,  0.4602,  0.2606
-0.0627, -0.0852, -0.7247, -0.9782,  0.5166,  0.2977
 0.0478,  0.5098, -0.0723, -0.7504, -0.3750,  0.3335
 0.0090,  0.3477,  0.5403, -0.7393, -0.9542,  0.4415
-0.9748,  0.3449,  0.3736, -0.1015,  0.8296,  0.4358
 0.2887, -0.9895, -0.0311,  0.7186,  0.6608,  0.2057
 0.1570, -0.4518,  0.1211,  0.3435, -0.2951,  0.3244
 0.7117, -0.6099,  0.4946, -0.4208,  0.5476,  0.1096
-0.2929, -0.5726,  0.5346, -0.3827,  0.4665,  0.2465
 0.4889, -0.5572, -0.5718, -0.6021, -0.7150,  0.2163
-0.7782,  0.3491,  0.5996, -0.8389, -0.5366,  0.6516
-0.5847,  0.8347,  0.4226,  0.1078, -0.3910,  0.6134
 0.8469,  0.4121, -0.0439, -0.7476,  0.9521,  0.1571
-0.6803, -0.5948, -0.1376, -0.1916, -0.7065,  0.7156
 0.2878,  0.5086, -0.5785,  0.2019,  0.4979,  0.2980
 0.2764,  0.1943, -0.4090,  0.4632,  0.8906,  0.2960
-0.8877,  0.6705, -0.6155, -0.2098, -0.3998,  0.7107
-0.8398,  0.8093, -0.2597,  0.0614, -0.0118,  0.6502
-0.8476,  0.0158, -0.4769, -0.2859, -0.7839,  0.7715
 0.5751, -0.7868,  0.9714, -0.6457,  0.1448,  0.1175
 0.4802, -0.7001,  0.1022, -0.5668,  0.5184,  0.1090
 0.4458, -0.6469,  0.7239, -0.9604,  0.7205,  0.0779
 0.5175,  0.4339,  0.9747, -0.4438, -0.9924,  0.2879
 0.8678,  0.7158,  0.4577,  0.0334,  0.4139,  0.1678
 0.5406,  0.5012,  0.2264, -0.1963,  0.3946,  0.2088
-0.9938,  0.5498,  0.7928, -0.5214, -0.7585,  0.7687
 0.7661,  0.0863, -0.4266, -0.7233, -0.4197,  0.1466
 0.2277, -0.3517, -0.0853, -0.1118,  0.6563,  0.1767
 0.3499, -0.5570, -0.0655, -0.3705,  0.2537,  0.1632
 0.7547, -0.1046,  0.5689, -0.0861,  0.3125,  0.1257
 0.8186,  0.2110,  0.5335,  0.0094, -0.0039,  0.1391
 0.6858, -0.8644,  0.1465,  0.8855,  0.0357,  0.1845
-0.4967,  0.4015,  0.0805,  0.8977,  0.2487,  0.4663
 0.6760, -0.9841,  0.9787, -0.8446, -0.3557,  0.1509
-0.1203, -0.4885,  0.6054, -0.0443, -0.7313,  0.4854
 0.8557,  0.7919, -0.0169,  0.7134, -0.1628,  0.2002
 0.0115, -0.6209,  0.9300, -0.4116, -0.7931,  0.4052
-0.7114, -0.9718,  0.4319,  0.1290,  0.5892,  0.3661
 0.3915,  0.5557, -0.1870,  0.2955, -0.6404,  0.2954
-0.3564, -0.6548, -0.1827, -0.5172, -0.1862,  0.4622
 0.2392, -0.4959,  0.5857, -0.1341, -0.2850,  0.2470
-0.3394,  0.3947, -0.4627,  0.6166, -0.4094,  0.5325
 0.7107,  0.7768, -0.6312,  0.1707,  0.7964,  0.2757
-0.1078,  0.8437, -0.4420,  0.2177,  0.3649,  0.4028
-0.3139,  0.5595, -0.6505, -0.3161, -0.7108,  0.5546
 0.4335,  0.3986,  0.3770, -0.4932,  0.3847,  0.1810
-0.2562, -0.2894, -0.8847,  0.2633,  0.4146,  0.4036
 0.2272,  0.2966, -0.6601, -0.7011,  0.0284,  0.2778
-0.0743, -0.1421, -0.0054, -0.6770, -0.3151,  0.3597
-0.4762,  0.6891,  0.6007, -0.1467,  0.2140,  0.4266
-0.4061,  0.7193,  0.3432,  0.2669, -0.7505,  0.6147
-0.0588,  0.9731,  0.8966,  0.2902, -0.6966,  0.4955
-0.0627, -0.1439,  0.1985,  0.6999,  0.5022,  0.3077
 0.1587,  0.8494, -0.8705,  0.9827, -0.8940,  0.4263
-0.7850,  0.2473, -0.9040, -0.4308, -0.8779,  0.7199
 0.4070,  0.3369, -0.2428, -0.6236,  0.4940,  0.2215
-0.0242,  0.0513, -0.9430,  0.2885, -0.2987,  0.3947
-0.5416, -0.1322, -0.2351, -0.0604,  0.9590,  0.3683
 0.1055,  0.7783, -0.2901, -0.5090,  0.8220,  0.2984
-0.9129,  0.9015,  0.1128, -0.2473,  0.9901,  0.4776
-0.9378,  0.1424, -0.6391,  0.2619,  0.9618,  0.5368
 0.7498, -0.0963,  0.4169,  0.5549, -0.0103,  0.1614
-0.2612, -0.7156,  0.4538, -0.0460, -0.1022,  0.3717
 0.7720,  0.0552, -0.1818, -0.4622, -0.8560,  0.1685
-0.4177,  0.0070,  0.9319, -0.7812,  0.3461,  0.3052
-0.0001,  0.5542, -0.7128, -0.8336, -0.2016,  0.3803
 0.5356, -0.4194, -0.5662, -0.9666, -0.2027,  0.1776
-0.2378,  0.3187, -0.8582, -0.6948, -0.9668,  0.5474
-0.1947, -0.3579,  0.1158,  0.9869,  0.6690,  0.2992
 0.3992,  0.8365, -0.9205, -0.8593, -0.0520,  0.3154
-0.0209,  0.0793,  0.7905, -0.1067,  0.7541,  0.1864
-0.4928, -0.4524, -0.3433,  0.0951, -0.5597,  0.6261
-0.8118,  0.7404, -0.5263, -0.2280,  0.1431,  0.6349
 0.0516, -0.8480,  0.7483,  0.9023,  0.6250,  0.1959
-0.3212,  0.1093,  0.9488, -0.3766,  0.3376,  0.2735
-0.3481,  0.5490, -0.3484,  0.7797,  0.5034,  0.4379
-0.5785, -0.9170, -0.3563, -0.9258,  0.3877,  0.4121
 0.3407, -0.1391,  0.5356,  0.0720, -0.9203,  0.3458
-0.3287, -0.8954,  0.2102,  0.0241,  0.2349,  0.3247
-0.1353,  0.6954, -0.0919, -0.9692,  0.7461,  0.3338
 0.9036, -0.8982, -0.5299, -0.8733, -0.1567,  0.1187
 0.7277, -0.8368, -0.0538, -0.7489,  0.5458,  0.0830
 0.9049,  0.8878,  0.2279,  0.9470, -0.3103,  0.2194
 0.7957, -0.1308, -0.5284,  0.8817,  0.3684,  0.2172
 0.4647, -0.4931,  0.2010,  0.6292, -0.8918,  0.3371
-0.7390,  0.6849,  0.2367,  0.0626, -0.5034,  0.7039
-0.1567, -0.8711,  0.7940, -0.5932,  0.6525,  0.1710
 0.7635, -0.0265,  0.1969,  0.0545,  0.2496,  0.1445
 0.7675,  0.1354, -0.7698, -0.5460,  0.1920,  0.1728
-0.5211, -0.7372, -0.6763,  0.6897,  0.2044,  0.5217
 0.1913,  0.1980,  0.2314, -0.8816,  0.5006,  0.1998
 0.8964,  0.0694, -0.6149,  0.5059, -0.9854,  0.1825
 0.1767,  0.7104,  0.2093,  0.6452,  0.7590,  0.2832
-0.3580, -0.7541,  0.4426, -0.1193, -0.7465,  0.5657
-0.5996,  0.5766, -0.9758, -0.3933, -0.9572,  0.6800
 0.9950,  0.1641, -0.4132,  0.8579,  0.0142,  0.2003
-0.4717, -0.3894, -0.2567, -0.5111,  0.1691,  0.4266
 0.3917, -0.8561,  0.9422,  0.5061,  0.6123,  0.1212
-0.0366, -0.1087,  0.3449, -0.1025,  0.4086,  0.2475
 0.3633,  0.3943,  0.2372, -0.6980,  0.5216,  0.1925
-0.5325, -0.6466, -0.2178, -0.3589,  0.6310,  0.3568
 0.2271,  0.5200, -0.1447, -0.8011, -0.7699,  0.3128
 0.6415,  0.1993,  0.3777, -0.0178, -0.8237,  0.2181
-0.5298, -0.0768, -0.6028, -0.9490,  0.4588,  0.4356
 0.6870, -0.1431,  0.7294,  0.3141,  0.1621,  0.1632
-0.5985,  0.0591,  0.7889, -0.3900,  0.7419,  0.2945
 0.3661,  0.7984, -0.8486,  0.7572, -0.6183,  0.3449
 0.6995,  0.3342, -0.3113, -0.6972,  0.2707,  0.1712
 0.2565,  0.9126,  0.1798, -0.6043, -0.1413,  0.2893
-0.3265,  0.9839, -0.2395,  0.9854,  0.0376,  0.4770
 0.2690, -0.1722,  0.9818,  0.8599, -0.7015,  0.3954
-0.2102, -0.0768,  0.1219,  0.5607, -0.0256,  0.3949
 0.8216, -0.9555,  0.6422, -0.6231,  0.3715,  0.0801
-0.2896,  0.9484, -0.7545, -0.6249,  0.7789,  0.4370
-0.9985, -0.5448, -0.7092, -0.5931,  0.7926,  0.5402

Test data:

# synthetic_test_40.txt
#
 0.7462,  0.4006, -0.0590,  0.6543, -0.0083,  0.1935
 0.8495, -0.2260, -0.0142, -0.4911,  0.7699,  0.1078
-0.2335, -0.4049,  0.4352, -0.6183, -0.7636,  0.5088
 0.1810, -0.5142,  0.2465,  0.2767, -0.3449,  0.3136
-0.8650,  0.7611, -0.0801,  0.5277, -0.4922,  0.7140
-0.2358, -0.7466, -0.5115, -0.8413, -0.3943,  0.4533
 0.4834,  0.2300,  0.3448, -0.9832,  0.3568,  0.1360
-0.6502, -0.6300,  0.6885,  0.9652,  0.8275,  0.3046
-0.3053,  0.5604,  0.0929,  0.6329, -0.0325,  0.4756
-0.7995,  0.0740, -0.2680,  0.2086,  0.9176,  0.4565
-0.2144, -0.2141,  0.5813,  0.2902, -0.2122,  0.4119
-0.7278, -0.0987, -0.3312, -0.5641,  0.8515,  0.4438
 0.3793,  0.1976,  0.4933,  0.0839,  0.4011,  0.1905
-0.8568,  0.9573, -0.5272,  0.3212, -0.8207,  0.7415
-0.5785,  0.0056, -0.7901, -0.2223,  0.0760,  0.5551
 0.0735, -0.2188,  0.3925,  0.3570,  0.3746,  0.2191
 0.1230, -0.2838,  0.2262,  0.8715,  0.1938,  0.2878
 0.4792, -0.9248,  0.5295,  0.0366, -0.9894,  0.3149
-0.4456,  0.0697,  0.5359, -0.8938,  0.0981,  0.3879
 0.8629, -0.8505, -0.4464,  0.8385,  0.5300,  0.1769
 0.1995,  0.6659,  0.7921,  0.9454,  0.9970,  0.2330
-0.0249, -0.3066, -0.2927, -0.4923,  0.8220,  0.2437
 0.4513, -0.9481, -0.0770, -0.4374, -0.9421,  0.2879
-0.3405,  0.5931, -0.3507, -0.3842,  0.8562,  0.3987
 0.9538,  0.0471,  0.9039,  0.7760,  0.0361,  0.1706
-0.0887,  0.2104,  0.9808,  0.5478, -0.3314,  0.4128
-0.8220, -0.6302,  0.0537, -0.1658,  0.6013,  0.4306
-0.4123, -0.2880,  0.9074, -0.0461, -0.4435,  0.5144
 0.0060,  0.2867, -0.7775,  0.5161,  0.7039,  0.3599
-0.7968, -0.5484,  0.9426, -0.4308,  0.8148,  0.2979
 0.7811,  0.8450, -0.6877,  0.7594,  0.2640,  0.2362
-0.6802, -0.1113, -0.8325, -0.6694, -0.6056,  0.6544
 0.3821,  0.1476,  0.7466, -0.5107,  0.2592,  0.1648
 0.7265,  0.9683, -0.9803, -0.4943, -0.5523,  0.2454
-0.9049, -0.9797, -0.0196, -0.9090, -0.4433,  0.6447
-0.4607,  0.1811, -0.2389,  0.4050, -0.0078,  0.5229
 0.2664, -0.2932, -0.4259, -0.7336,  0.8742,  0.1834
-0.4507,  0.1029, -0.6294, -0.1158, -0.6294,  0.6081
 0.8948, -0.0124,  0.9278,  0.2899, -0.0314,  0.1534
-0.1323, -0.8813, -0.0146, -0.0697,  0.6135,  0.2386

RBF networks for regression had a brief period of popularity in the 1990s. They are now rarely used because other techniques, notably, neural networks, kernel ridge regression, and gradient boost regression, are much easier to train and typically have better prediction accuracy.

Just for fun, I decided to implement RBF network regression, from scratch, using the C# language. The effort was made much easier through the use of AI coding assistance.

For my demo, I used one of my standard synthetic datasets. The data looks like:

-0.1660,  0.4406, -0.9998, -0.3953, -0.7065,  0.4840
 0.0776, -0.1616,  0.3704, -0.5911,  0.7562,  0.1568
-0.9452,  0.3409, -0.1654,  0.1174, -0.7192,  0.8054
. . .

The first five values on each line are predictors. The last value is the target to predict. There are 200 training items and 40 test items.

The output of my demo is:

Begin RBF network regression using C#

Loading synthetic train (200) and test (40) data
Done

First three train X:
 -0.1660  0.4406 -0.9998 -0.3953 -0.7065
  0.0776 -0.1616  0.3704 -0.5911  0.7562
 -0.9452  0.3409 -0.1654  0.1174 -0.7192

First three train y:
  0.4840
  0.1568
  0.8054

Creating 5-100-1 RBF network
Done

Setting lrnRate = 0.0010
Setting maxEpochs = 500000
Setting decay = 0.0e+0

Starting training
epoch:      0   MSE = 0.0329   acc = 0.0500
epoch:  25000   MSE = 0.0002   acc = 0.7350
epoch:  50000   MSE = 0.0002   acc = 0.7400
epoch:  75000   MSE = 0.0002   acc = 0.7150
. . .
epoch: 425000   MSE = 0.0001   acc = 0.7850
epoch: 450000   MSE = 0.0001   acc = 0.7800
epoch: 475000   MSE = 0.0001   acc = 0.7950
Done

Evaluating model

Accuracy (5%) on train data = 0.7850
Accuracy (5%) on test data  = 0.8250

MSE on train data = 0.0001
MSE on test data = 0.0001

Predicting for x =
  -0.1660   0.4406  -0.9998  -0.3953  -0.7065
Predicted y = 0.4917

End demo

An interesting exploration.

Writing machine learning code is kind of like solving a mystery.

Right: Inspector Lestrade on the left (actor Archie Duncan) believes the murdered man’s fiance is the murderer, but Watson and Holmes prove that the victim’s brother is the villain.

Demo program. Replace “lt” (less than), “gt”, “lte”, “gte”, “lte’ with Boolean operator symbols (my blog editor chokes on symbols).

using System;
using System.Collections.Generic;
using System.IO;

// Four reasons why RBF networks are rarely used:
// 1. Because Gaussian RBFs rely on Euclidean distance,
//  they only cover localized regions.
// 2. RBF centers are selected using K-Means clustering,
//  which places centers where X data density is highest,
//  blind to the y target values.
// 3. RBF hyperparameters are extremely sensitive:
//  number centers, center positions, gamma.
// 4. Other techniques -- neural network regression,
//  kernel ridge regression, gradient boost regression -- are
//  easier to train and therefore usually predict better.

// RBF networks sometimes useful for incremental learning:
// Because RBF nodes are local, updating a weight only
// changes predictions in the immediate neighborhood of
// that center.

namespace RbfNetworkRegression
{
  internal class RbfNetworkRegressionProgram
  {
    static void Main(string[] args)
    {
      Console.WriteLine("\nBegin RBF network " +
        "regression using C# ");

      // 1. load data
      Console.WriteLine("\nLoading synthetic train (200)" +
        " and test (40) data ");
      string trainFile =
        "..\\..\\..\\Data\\synthetic_train_200.txt";
      double[][] trainX = MatLoad(trainFile,
        new int[] { 0, 1, 2, 3, 4 }, ',', "#");
      double[] trainY = MatToVec(MatLoad(trainFile,
        new int[] { 5 }, ',', "#"));

      string testFile =
        "..\\..\\..\\Data\\synthetic_test_40.txt";
      double[][] testX = MatLoad(testFile,
        new int[] { 0, 1, 2, 3, 4 }, ',', "#");
      double[] testY = MatToVec(MatLoad(testFile,
        new int[] { 5 }, ',', "#"));
      Console.WriteLine("Done ");

      Console.WriteLine("\nFirst three train X: ");
      for (int i = 0; i "lt" 3; ++i)
        VecShow(trainX[i], 4, 8);

      Console.WriteLine("\nFirst three train y: ");
      for (int i = 0; i "lt" 3; ++i)
        Console.WriteLine(trainY[i].ToString("F4").
          PadLeft(8));

      // 2. create RBF network
      Console.WriteLine("\nCreating 5-100-1 RBF network ");
      RbfNetworkRegressor nn =
        new RbfNetworkRegressor(5, 100, 1);
      Console.WriteLine("Done ");

      // 3. train RBF network
      double lrnRate = 0.001;
      int maxEpochs = 500000;
      double decay = 0.00000;

      Console.WriteLine("\nSetting lrnRate = " +
        lrnRate.ToString("F4"));
      Console.WriteLine("Setting maxEpochs = " +
        maxEpochs);
      Console.WriteLine("Setting decay = " +
        decay.ToString("0.0e+0"));

      Console.WriteLine("\nStarting training ");
      nn.Train(trainX, trainY, lrnRate, maxEpochs, decay);
      Console.WriteLine("Done ");

      // 5. evaluate trained model
      Console.WriteLine("\nEvaluating model ");
      double trainAcc = nn.Accuracy(trainX, trainY, 0.05);
      Console.WriteLine("\nAccuracy (5%) on train data = " +
        trainAcc.ToString("F4"));

      double testAcc = nn.Accuracy(testX, testY, 0.05);
      Console.WriteLine("Accuracy (5%) on test data  = " +
        testAcc.ToString("F4"));

      double trainMSE = nn.MSE(trainX, trainY);
      Console.WriteLine("\nMSE on train data = " +
        trainMSE.ToString("F4"));

      double testMSE = nn.MSE(testX, testY);
      Console.WriteLine("MSE on test data = " +
        testMSE.ToString("F4"));

      // 6. use model
      double[] x = trainX[0];
      Console.WriteLine("\nPredicting for x = ");
      VecShow(x, 4, 9);
      double predY = nn.Predict(x);
      Console.WriteLine("Predicted y = " +
        predY.ToString("F4"));

      Console.WriteLine("\nEnd demo ");
      Console.ReadLine();
    } // Main

    // ------------------------------------------------------
    // helpers for Main(): MatLoad(), MatToVec(), VecShow()
    // ------------------------------------------------------

    static double[][] MatLoad(string fn, int[] usecols,
      char sep, string comment)
    {
      List"lt"double[]"gt" result =
        new List"lt"double[]"gt"();
      string line = "";
      FileStream ifs = new FileStream(fn, FileMode.Open);
      StreamReader sr = new StreamReader(ifs);
      while ((line = sr.ReadLine()) != null)
      {
        if (line.StartsWith(comment) == true)
          continue;
        string[] tokens = line.Split(sep);
        List"lt"double"gt" lst = new List"lt"double"gt"();
        for (int j = 0; j "lt" usecols.Length; ++j)
          lst.Add(double.Parse(tokens[usecols[j]]));
        double[] row = lst.ToArray();
        result.Add(row);
      }
      sr.Close(); ifs.Close();
      return result.ToArray();
    }

    static double[] MatToVec(double[][] M)
    {
      int nRows = M.Length;
      int nCols = M[0].Length;
      double[] result = new double[nRows * nCols];
      int k = 0;
      for (int i = 0; i "lt" nRows; ++i)
        for (int j = 0; j "lt" nCols; ++j)
          result[k++] = M[i][j];
      return result;
    }

    static void VecShow(double[] vec, int dec, int wid)
    {
      for (int i = 0; i "lt" vec.Length; ++i)
        Console.Write(vec[i].ToString("F" + dec).
          PadLeft(wid));
      Console.WriteLine("");
    }

  } // class Program

  // ========================================================

  public class RbfNetworkRegressor
  {
    public int ni; // number of input features
    public int nh; // number of hidden/RBF nodes
    public int no; // output nodes (1 for regression)

    public Random rnd;

    public double[] iNodes;
    public double[] hNodes;
    public double[] oNodes;

    // RBF specific hidden layer components:
    public double[][] centers; // shape: [nh][ni]
    public double[] gammas;    // shape: [nh]

    // Output layer components:
    public double[][] hoWeights; // shape: [nh][no]
    public double[] oBiases;     // shape: [no]

    // ------------------------------------------------------

    public RbfNetworkRegressor(int numIn, int numHid,
      int numOut, int seed = 0)
    {
      this.ni = numIn;
      this.nh = numHid;
      this.no = numOut;

      this.iNodes = new double[numIn];
      this.hNodes = new double[numHid];
      this.oNodes = new double[numOut];

      this.centers = MatMake(numHid, numIn);
      this.gammas = new double[numHid];

      this.hoWeights = MatMake(numHid, numOut);
      this.oBiases = new double[numOut];

      this.rnd = new Random(seed);
    }

    // ------------------------------------------------------

    public double Predict(double[] x)
    {
      for (int i = 0; i "lt" x.Length; ++i)
        this.iNodes[i] = x[i];

      // 1. hidden node activations via Gaussian RBF
      for (int j = 0; j "lt" this.nh; ++j)
      {
        double distSq = 0.0;
        for (int i = 0; i "lt" this.ni; ++i)
        {
          double diff = this.iNodes[i] - this.centers[j][i];
          distSq += diff * diff;
        }
        this.hNodes[j] = Math.Exp(-this.gammas[j] * distSq);
      }

      // 2. Compute linear output combination
      for (int k = 0; k "lt" this.no; ++k)
      {
        double sum = 0.0;
        for (int j = 0; j "lt" this.nh; ++j)
          sum += this.hNodes[j] * this.hoWeights[j][k];
        sum += this.oBiases[k];
        this.oNodes[k] = Identity(sum);
      }

      return this.oNodes[0];
    }

    // ------------------------------------------------------

    public void Train(double[][] trainX, double[] trainY,
      double lrnRate, int maxEpochs, double decay)
    {
      int freq = Math.Max(1, maxEpochs / 20);

      // initialize Centers via K-Means Clustering on trainX
      this.InitCentersKMeans(trainX);

      // set Widths based on distance between centers
      this.InitGammas();

      // Step 3: Initialize output weights randomly
      double lo = -0.01; double hi = +0.01;
      for (int j = 0; j "lt" this.nh; ++j)
        for (int k = 0; k "lt" this.no; ++k)
          this.hoWeights[j][k] = (hi - lo) *
            this.rnd.NextDouble() + lo;

      // Gradient buffers for output layer
      double[][] hoGrads = MatMake(this.nh, this.no);
      double[] obGrads = new double[this.no];
      double[] oSignals = new double[this.no];

      int n = trainX.Length;
      int[] indices = new int[n];
      for (int i = 0; i "lt" n; ++i) indices[i] = i;

      // train for hidden-to-output weights
      for (int epoch = 0; epoch "lt" maxEpochs; ++epoch)
      {
        this.Shuffle(indices);

        for (int ii = 0; ii "lt" n; ++ii)
        {
          int idx = indices[ii];
          double[] x = trainX[idx];
          double actualY = trainY[idx];
          double predY = this.Predict(x);

          // Compute output node signal
          for (int k = 0; k "lt" this.no; ++k)
          {
            double derivative = 1.0; // Identity derivative
            oSignals[k] = derivative * (predY - actualY);
          }

          // gradients for hidden-to-output weights & biases
          for (int j = 0; j "lt" this.nh; ++j)
            for (int k = 0; k "lt" this.no; ++k)
              hoGrads[j][k] = oSignals[k] * this.hNodes[j];

          for (int k = 0; k "lt" this.no; ++k)
            obGrads[k] = oSignals[k] * 1.0;

          // apply weight decay
          for (int j = 0; j "lt" this.nh; ++j)
            for (int k = 0; k "lt" this.no; ++k)
              this.hoWeights[j][k] *= (1.0 - decay);

          // update output weights and biases using SGD
          for (int j = 0; j "lt" this.nh; ++j)
            for (int k = 0; k "lt" this.no; ++k)
              this.hoWeights[j][k] -= lrnRate *
                hoGrads[j][k];

          for (int k = 0; k "lt" this.no; ++k)
            this.oBiases[k] -= lrnRate * obGrads[k];
        }

        if (epoch % freq == 0)
        {
          double mse = this.MSE(trainX, trainY);
          double acc = this.Accuracy(trainX, trainY, 0.05);

          string s1 = "epoch: " + epoch.ToString().PadLeft(6);
          string s2 = "   MSE = " + mse.ToString("F4");
          string s3 = "   acc = " + acc.ToString("F4");
          Console.WriteLine(s1 + s2 + s3);
        }
      }
    }

    // ------------------------------------------------------
    // Helper Methods & Clustering Operations
    // ------------------------------------------------------

    private void InitCentersKMeans(double[][] trainX)
    {
      int n = trainX.Length;
      int[] clustering = new int[n];

      // assign initial centers from data samples
      int[] centerIndices = new int[this.nh];
      for (int j = 0; j "lt" this.nh; ++j)
      {
        int idx = this.rnd.Next(0, n);
        for (int k = 0; k "lt" j; ++k)
        {
          if (centerIndices[k] == idx)
          {
            --j;
            break;
          } // avoid duplicates
        }
        centerIndices[j] = idx;
        Array.Copy(trainX[idx], this.centers[j], this.ni);
      }

      bool changed = true;
      int maxIter = 100;
      int iter = 0;

      while (changed && iter "lt" maxIter)
      {
        ++iter;
        changed = false;

        // Assign each data point to nearest center
        for (int i = 0; i "lt" n; ++i)
        {
          int closest = 0;
          double minDist = EuclideanDistance(trainX[i],
            this.centers[0]);

          for (int j = 1; j "lt" this.nh; ++j)
          {
            double dist = EuclideanDistance(trainX[i],
              this.centers[j]);
            if (dist "lt" minDist)
            {
              minDist = dist;
              closest = j;
            }
          }

          if (clustering[i] != closest)
          {
            clustering[i] = closest;
            changed = true;
          }
        }

        // recalculate cluster centers
        double[][] newCenters = MatMake(this.nh, this.ni);
        int[] counts = new int[this.nh];

        for (int i = 0; i "lt" n; ++i)
        {
          int c = clustering[i];
          counts[c]++;
          for (int j = 0; j "lt" this.ni; ++j)
            newCenters[c][j] += trainX[i][j];
        }

        for (int j = 0; j "lt" this.nh; ++j)
        {
          if (counts[j] "gt" 0)
          {
            for (int k = 0; k "lt" this.ni; ++k)
              this.centers[j][k] =
                newCenters[j][k] / counts[j];
          }
        }
      }
    }

    private void InitGammas()
    {
      // gamma = 1 / (2 * sigma^2)
      // using distance between centers
      double totalDist = 0.0;
      int count = 0;

      for (int i = 0; i "lt" this.nh; ++i)
      {
        for (int j = i + 1; j "lt" this.nh; ++j)
        {
          totalDist +=
            EuclideanDistance(this.centers[i],
            this.centers[j]);
          count++;
        }
      }

      //double avgDist = count "gt" 0 ? totalDist / count : 1.0;
      double avgDist;
      if (count "gt" 0)
        avgDist = totalDist / count;
      else
        avgDist = 1.0;
      double sigma = avgDist;
      double gamma = 1.0 / (2.0 * sigma * sigma);

      for (int j = 0; j "lt" this.nh; ++j)
        this.gammas[j] = gamma;
    }

    private static double EuclideanDistance(double[] v1,
      double[] v2)
    {
      double sum = 0.0;
      for (int i = 0; i "lt" v1.Length; ++i)
      {
        double diff = v1[i] - v2[i];
        sum += diff * diff;
      }
      return Math.Sqrt(sum);
    }

    public double Accuracy(double[][] dataX, double[] dataY,
      double pctClose)
    {
      int n = dataX.Length;
      int nCorrect = 0; int nWrong = 0;
      for (int i = 0; i "lt" n; ++i)
      {
        double predY = this.Predict(dataX[i]);
        double actualY = dataY[i];
        if (Math.Abs(predY - actualY) "lt"
          (pctClose * Math.Abs(actualY)))
          ++nCorrect;
        else
          ++nWrong;
      }
      return (nCorrect * 1.0) / (nCorrect + nWrong);
    }

    public double MSE(double[][] dataX, double[] dataY)
    {
      int n = dataX.Length;
      double sum = 0.0;
      for (int i = 0; i "lt" n; ++i)
      {
        double predY = this.Predict(dataX[i]);
        double actualY = dataY[i];
        sum += (predY - actualY) * (predY - actualY);
      }
      return sum / n;
    }

    private static double[][] MatMake(int nRows, int nCols)
    {
      double[][] result = new double[nRows][];
      for (int i = 0; i "lt" nRows; ++i)
        result[i] = new double[nCols];
      return result;
    }

    private void Shuffle(int[] indices)
    {
      for (int i = 0; i "lt" indices.Length; ++i)
      {
        int r = this.rnd.Next(i, indices.Length);
        int tmp = indices[r];
        indices[r] = indices[i];
        indices[i] = tmp;
      }
    }

    private static double Identity(double x)
    {
      return x;
    }

  } // RbfNetworkRegressor class

  // ========================================================

} // ns

Training data:

# synthetic_train_200.txt
#
-0.1660,  0.4406, -0.9998, -0.3953, -0.7065,  0.4840
 0.0776, -0.1616,  0.3704, -0.5911,  0.7562,  0.1568
-0.9452,  0.3409, -0.1654,  0.1174, -0.7192,  0.8054
 0.9365, -0.3732,  0.3846,  0.7528,  0.7892,  0.1345
-0.8299, -0.9219, -0.6603,  0.7563, -0.8033,  0.7955
 0.0663,  0.3838, -0.3690,  0.3730,  0.6693,  0.3206
-0.9634,  0.5003,  0.9777,  0.4963, -0.4391,  0.7377
-0.1042,  0.8172, -0.4128, -0.4244, -0.7399,  0.4801
-0.9613,  0.3577, -0.5767, -0.4689, -0.0169,  0.6861
-0.7065,  0.1786,  0.3995, -0.7953, -0.1719,  0.5569
 0.3888, -0.1716, -0.9001,  0.0718,  0.3276,  0.2500
 0.1731,  0.8068, -0.7251, -0.7214,  0.6148,  0.3297
-0.2046, -0.6693,  0.8550, -0.3045,  0.5016,  0.2129
 0.2473,  0.5019, -0.3022, -0.4601,  0.7918,  0.2613
-0.1438,  0.9297,  0.3269,  0.2434, -0.7705,  0.5171
 0.1568, -0.1837, -0.5259,  0.8068,  0.1474,  0.3307
-0.9943,  0.2343, -0.3467,  0.0541,  0.7719,  0.5581
 0.2467, -0.9684,  0.8589,  0.3818,  0.9946,  0.1092
-0.6553, -0.7257,  0.8652,  0.3936, -0.8680,  0.7018
 0.8460,  0.4230, -0.7515, -0.9602, -0.9476,  0.1996
-0.9434, -0.5076,  0.7201,  0.0777,  0.1056,  0.5664
 0.9392,  0.1221, -0.9627,  0.6013, -0.5341,  0.1533
 0.6142, -0.2243,  0.7271,  0.4942,  0.1125,  0.1661
 0.4260,  0.1194, -0.9749, -0.8561,  0.9346,  0.2230
 0.1362, -0.5934, -0.4953,  0.4877, -0.6091,  0.3810
 0.6937, -0.5203, -0.0125,  0.2399,  0.6580,  0.1460
-0.6864, -0.9628, -0.8600, -0.0273,  0.2127,  0.5387
 0.9772,  0.1595, -0.2397,  0.1019,  0.4907,  0.1611
 0.3385, -0.4702, -0.8673, -0.2598,  0.2594,  0.2270
-0.8669, -0.4794,  0.6095, -0.6131,  0.2789,  0.4700
 0.0493,  0.8496, -0.4734, -0.8681,  0.4701,  0.3516
 0.8639, -0.9721, -0.5313,  0.2336,  0.8980,  0.1412
 0.9004,  0.1133,  0.8312,  0.2831, -0.2200,  0.1782
 0.0991,  0.8524,  0.8375, -0.2102,  0.9265,  0.2150
-0.6521, -0.7473, -0.7298,  0.0113, -0.9570,  0.7422
 0.6190, -0.3105,  0.8802,  0.1640,  0.7577,  0.1056
 0.6895,  0.8108, -0.0802,  0.0927,  0.5972,  0.2214
 0.1982, -0.9689,  0.1870, -0.1326,  0.6147,  0.1310
-0.3695,  0.7858,  0.1557, -0.6320,  0.5759,  0.3773
-0.1596,  0.3581,  0.8372, -0.9992,  0.9535,  0.2071
-0.2468,  0.9476,  0.2094,  0.6577,  0.1494,  0.4132
 0.1737,  0.5000,  0.7166,  0.5102,  0.3961,  0.2611
 0.7290, -0.3546,  0.3416, -0.0983, -0.2358,  0.1332
-0.3652,  0.2438, -0.1395,  0.9476,  0.3556,  0.4170
-0.6029, -0.1466, -0.3133,  0.5953,  0.7600,  0.4334
-0.4596, -0.4953,  0.7098,  0.0554,  0.6043,  0.2775
 0.1450,  0.4663,  0.0380,  0.5418,  0.1377,  0.2931
-0.8636, -0.2442, -0.8407,  0.9656, -0.6368,  0.7429
 0.6237,  0.7499,  0.3768,  0.1390, -0.6781,  0.2185
-0.5499,  0.1850, -0.3755,  0.8326,  0.8193,  0.4399
-0.4858, -0.7782, -0.6141, -0.0008,  0.4572,  0.4197
 0.7033, -0.1683,  0.2334, -0.5327, -0.7961,  0.1776
 0.0317, -0.0457, -0.6947,  0.2436,  0.0880,  0.3345
 0.5031, -0.5559,  0.0387,  0.5706, -0.9553,  0.3107
-0.3513,  0.7458,  0.6894,  0.0769,  0.7332,  0.3170
 0.2205,  0.5992, -0.9309,  0.5405,  0.4635,  0.3532
-0.4806, -0.4859,  0.2646, -0.3094,  0.5932,  0.3202
 0.9809, -0.3995, -0.7140,  0.8026,  0.0831,  0.1600
 0.9495,  0.2732,  0.9878,  0.0921,  0.0529,  0.1289
-0.9476, -0.6792,  0.4913, -0.9392, -0.2669,  0.5966
 0.7247,  0.3854,  0.3819, -0.6227, -0.1162,  0.1550
-0.5922, -0.5045, -0.4757,  0.5003, -0.0860,  0.5863
-0.8861,  0.0170, -0.5761,  0.5972, -0.4053,  0.7301
 0.6877, -0.2380,  0.4997,  0.0223,  0.0819,  0.1404
 0.9189,  0.6079, -0.9354,  0.4188, -0.0700,  0.1907
-0.1428, -0.7820,  0.2676,  0.6059,  0.3936,  0.2790
 0.5324, -0.3151,  0.6917, -0.1425,  0.6480,  0.1071
-0.8432, -0.9633, -0.8666, -0.0828, -0.7733,  0.7784
-0.9444,  0.5097, -0.2103,  0.4939, -0.0952,  0.6787
-0.0520,  0.6063, -0.1952,  0.8094, -0.9259,  0.4836
 0.5477, -0.7487,  0.2370, -0.9793,  0.0773,  0.1241
 0.2450,  0.8116,  0.9799,  0.4222,  0.4636,  0.2355
 0.8186, -0.1983, -0.5003, -0.6531, -0.7611,  0.1511
-0.4714,  0.6382, -0.3788,  0.9648, -0.4667,  0.5950
 0.0673, -0.3711,  0.8215, -0.2669, -0.1328,  0.2677
-0.9381,  0.4338,  0.7820, -0.9454,  0.0441,  0.5518
-0.3480,  0.7190,  0.1170,  0.3805, -0.0943,  0.4724
-0.9813,  0.1535, -0.3771,  0.0345,  0.8328,  0.5438
-0.1471, -0.5052, -0.2574,  0.8637,  0.8737,  0.3042
-0.5454, -0.3712, -0.6505,  0.2142, -0.1728,  0.5783
 0.6327, -0.6297,  0.4038, -0.5193,  0.1484,  0.1153
-0.5424,  0.3282, -0.0055,  0.0380, -0.6506,  0.6613
 0.1414,  0.9935,  0.6337,  0.1887,  0.9520,  0.2540
-0.9351, -0.8128, -0.8693, -0.0965, -0.2491,  0.7353
 0.9507, -0.6640,  0.9456,  0.5349,  0.6485,  0.1059
-0.0462, -0.9737, -0.2940, -0.0159,  0.4602,  0.2606
-0.0627, -0.0852, -0.7247, -0.9782,  0.5166,  0.2977
 0.0478,  0.5098, -0.0723, -0.7504, -0.3750,  0.3335
 0.0090,  0.3477,  0.5403, -0.7393, -0.9542,  0.4415
-0.9748,  0.3449,  0.3736, -0.1015,  0.8296,  0.4358
 0.2887, -0.9895, -0.0311,  0.7186,  0.6608,  0.2057
 0.1570, -0.4518,  0.1211,  0.3435, -0.2951,  0.3244
 0.7117, -0.6099,  0.4946, -0.4208,  0.5476,  0.1096
-0.2929, -0.5726,  0.5346, -0.3827,  0.4665,  0.2465
 0.4889, -0.5572, -0.5718, -0.6021, -0.7150,  0.2163
-0.7782,  0.3491,  0.5996, -0.8389, -0.5366,  0.6516
-0.5847,  0.8347,  0.4226,  0.1078, -0.3910,  0.6134
 0.8469,  0.4121, -0.0439, -0.7476,  0.9521,  0.1571
-0.6803, -0.5948, -0.1376, -0.1916, -0.7065,  0.7156
 0.2878,  0.5086, -0.5785,  0.2019,  0.4979,  0.2980
 0.2764,  0.1943, -0.4090,  0.4632,  0.8906,  0.2960
-0.8877,  0.6705, -0.6155, -0.2098, -0.3998,  0.7107
-0.8398,  0.8093, -0.2597,  0.0614, -0.0118,  0.6502
-0.8476,  0.0158, -0.4769, -0.2859, -0.7839,  0.7715
 0.5751, -0.7868,  0.9714, -0.6457,  0.1448,  0.1175
 0.4802, -0.7001,  0.1022, -0.5668,  0.5184,  0.1090
 0.4458, -0.6469,  0.7239, -0.9604,  0.7205,  0.0779
 0.5175,  0.4339,  0.9747, -0.4438, -0.9924,  0.2879
 0.8678,  0.7158,  0.4577,  0.0334,  0.4139,  0.1678
 0.5406,  0.5012,  0.2264, -0.1963,  0.3946,  0.2088
-0.9938,  0.5498,  0.7928, -0.5214, -0.7585,  0.7687
 0.7661,  0.0863, -0.4266, -0.7233, -0.4197,  0.1466
 0.2277, -0.3517, -0.0853, -0.1118,  0.6563,  0.1767
 0.3499, -0.5570, -0.0655, -0.3705,  0.2537,  0.1632
 0.7547, -0.1046,  0.5689, -0.0861,  0.3125,  0.1257
 0.8186,  0.2110,  0.5335,  0.0094, -0.0039,  0.1391
 0.6858, -0.8644,  0.1465,  0.8855,  0.0357,  0.1845
-0.4967,  0.4015,  0.0805,  0.8977,  0.2487,  0.4663
 0.6760, -0.9841,  0.9787, -0.8446, -0.3557,  0.1509
-0.1203, -0.4885,  0.6054, -0.0443, -0.7313,  0.4854
 0.8557,  0.7919, -0.0169,  0.7134, -0.1628,  0.2002
 0.0115, -0.6209,  0.9300, -0.4116, -0.7931,  0.4052
-0.7114, -0.9718,  0.4319,  0.1290,  0.5892,  0.3661
 0.3915,  0.5557, -0.1870,  0.2955, -0.6404,  0.2954
-0.3564, -0.6548, -0.1827, -0.5172, -0.1862,  0.4622
 0.2392, -0.4959,  0.5857, -0.1341, -0.2850,  0.2470
-0.3394,  0.3947, -0.4627,  0.6166, -0.4094,  0.5325
 0.7107,  0.7768, -0.6312,  0.1707,  0.7964,  0.2757
-0.1078,  0.8437, -0.4420,  0.2177,  0.3649,  0.4028
-0.3139,  0.5595, -0.6505, -0.3161, -0.7108,  0.5546
 0.4335,  0.3986,  0.3770, -0.4932,  0.3847,  0.1810
-0.2562, -0.2894, -0.8847,  0.2633,  0.4146,  0.4036
 0.2272,  0.2966, -0.6601, -0.7011,  0.0284,  0.2778
-0.0743, -0.1421, -0.0054, -0.6770, -0.3151,  0.3597
-0.4762,  0.6891,  0.6007, -0.1467,  0.2140,  0.4266
-0.4061,  0.7193,  0.3432,  0.2669, -0.7505,  0.6147
-0.0588,  0.9731,  0.8966,  0.2902, -0.6966,  0.4955
-0.0627, -0.1439,  0.1985,  0.6999,  0.5022,  0.3077
 0.1587,  0.8494, -0.8705,  0.9827, -0.8940,  0.4263
-0.7850,  0.2473, -0.9040, -0.4308, -0.8779,  0.7199
 0.4070,  0.3369, -0.2428, -0.6236,  0.4940,  0.2215
-0.0242,  0.0513, -0.9430,  0.2885, -0.2987,  0.3947
-0.5416, -0.1322, -0.2351, -0.0604,  0.9590,  0.3683
 0.1055,  0.7783, -0.2901, -0.5090,  0.8220,  0.2984
-0.9129,  0.9015,  0.1128, -0.2473,  0.9901,  0.4776
-0.9378,  0.1424, -0.6391,  0.2619,  0.9618,  0.5368
 0.7498, -0.0963,  0.4169,  0.5549, -0.0103,  0.1614
-0.2612, -0.7156,  0.4538, -0.0460, -0.1022,  0.3717
 0.7720,  0.0552, -0.1818, -0.4622, -0.8560,  0.1685
-0.4177,  0.0070,  0.9319, -0.7812,  0.3461,  0.3052
-0.0001,  0.5542, -0.7128, -0.8336, -0.2016,  0.3803
 0.5356, -0.4194, -0.5662, -0.9666, -0.2027,  0.1776
-0.2378,  0.3187, -0.8582, -0.6948, -0.9668,  0.5474
-0.1947, -0.3579,  0.1158,  0.9869,  0.6690,  0.2992
 0.3992,  0.8365, -0.9205, -0.8593, -0.0520,  0.3154
-0.0209,  0.0793,  0.7905, -0.1067,  0.7541,  0.1864
-0.4928, -0.4524, -0.3433,  0.0951, -0.5597,  0.6261
-0.8118,  0.7404, -0.5263, -0.2280,  0.1431,  0.6349
 0.0516, -0.8480,  0.7483,  0.9023,  0.6250,  0.1959
-0.3212,  0.1093,  0.9488, -0.3766,  0.3376,  0.2735
-0.3481,  0.5490, -0.3484,  0.7797,  0.5034,  0.4379
-0.5785, -0.9170, -0.3563, -0.9258,  0.3877,  0.4121
 0.3407, -0.1391,  0.5356,  0.0720, -0.9203,  0.3458
-0.3287, -0.8954,  0.2102,  0.0241,  0.2349,  0.3247
-0.1353,  0.6954, -0.0919, -0.9692,  0.7461,  0.3338
 0.9036, -0.8982, -0.5299, -0.8733, -0.1567,  0.1187
 0.7277, -0.8368, -0.0538, -0.7489,  0.5458,  0.0830
 0.9049,  0.8878,  0.2279,  0.9470, -0.3103,  0.2194
 0.7957, -0.1308, -0.5284,  0.8817,  0.3684,  0.2172
 0.4647, -0.4931,  0.2010,  0.6292, -0.8918,  0.3371
-0.7390,  0.6849,  0.2367,  0.0626, -0.5034,  0.7039
-0.1567, -0.8711,  0.7940, -0.5932,  0.6525,  0.1710
 0.7635, -0.0265,  0.1969,  0.0545,  0.2496,  0.1445
 0.7675,  0.1354, -0.7698, -0.5460,  0.1920,  0.1728
-0.5211, -0.7372, -0.6763,  0.6897,  0.2044,  0.5217
 0.1913,  0.1980,  0.2314, -0.8816,  0.5006,  0.1998
 0.8964,  0.0694, -0.6149,  0.5059, -0.9854,  0.1825
 0.1767,  0.7104,  0.2093,  0.6452,  0.7590,  0.2832
-0.3580, -0.7541,  0.4426, -0.1193, -0.7465,  0.5657
-0.5996,  0.5766, -0.9758, -0.3933, -0.9572,  0.6800
 0.9950,  0.1641, -0.4132,  0.8579,  0.0142,  0.2003
-0.4717, -0.3894, -0.2567, -0.5111,  0.1691,  0.4266
 0.3917, -0.8561,  0.9422,  0.5061,  0.6123,  0.1212
-0.0366, -0.1087,  0.3449, -0.1025,  0.4086,  0.2475
 0.3633,  0.3943,  0.2372, -0.6980,  0.5216,  0.1925
-0.5325, -0.6466, -0.2178, -0.3589,  0.6310,  0.3568
 0.2271,  0.5200, -0.1447, -0.8011, -0.7699,  0.3128
 0.6415,  0.1993,  0.3777, -0.0178, -0.8237,  0.2181
-0.5298, -0.0768, -0.6028, -0.9490,  0.4588,  0.4356
 0.6870, -0.1431,  0.7294,  0.3141,  0.1621,  0.1632
-0.5985,  0.0591,  0.7889, -0.3900,  0.7419,  0.2945
 0.3661,  0.7984, -0.8486,  0.7572, -0.6183,  0.3449
 0.6995,  0.3342, -0.3113, -0.6972,  0.2707,  0.1712
 0.2565,  0.9126,  0.1798, -0.6043, -0.1413,  0.2893
-0.3265,  0.9839, -0.2395,  0.9854,  0.0376,  0.4770
 0.2690, -0.1722,  0.9818,  0.8599, -0.7015,  0.3954
-0.2102, -0.0768,  0.1219,  0.5607, -0.0256,  0.3949
 0.8216, -0.9555,  0.6422, -0.6231,  0.3715,  0.0801
-0.2896,  0.9484, -0.7545, -0.6249,  0.7789,  0.4370
-0.9985, -0.5448, -0.7092, -0.5931,  0.7926,  0.5402

Test data:

# synthetic_test_40.txt
#
 0.7462,  0.4006, -0.0590,  0.6543, -0.0083,  0.1935
 0.8495, -0.2260, -0.0142, -0.4911,  0.7699,  0.1078
-0.2335, -0.4049,  0.4352, -0.6183, -0.7636,  0.5088
 0.1810, -0.5142,  0.2465,  0.2767, -0.3449,  0.3136
-0.8650,  0.7611, -0.0801,  0.5277, -0.4922,  0.7140
-0.2358, -0.7466, -0.5115, -0.8413, -0.3943,  0.4533
 0.4834,  0.2300,  0.3448, -0.9832,  0.3568,  0.1360
-0.6502, -0.6300,  0.6885,  0.9652,  0.8275,  0.3046
-0.3053,  0.5604,  0.0929,  0.6329, -0.0325,  0.4756
-0.7995,  0.0740, -0.2680,  0.2086,  0.9176,  0.4565
-0.2144, -0.2141,  0.5813,  0.2902, -0.2122,  0.4119
-0.7278, -0.0987, -0.3312, -0.5641,  0.8515,  0.4438
 0.3793,  0.1976,  0.4933,  0.0839,  0.4011,  0.1905
-0.8568,  0.9573, -0.5272,  0.3212, -0.8207,  0.7415
-0.5785,  0.0056, -0.7901, -0.2223,  0.0760,  0.5551
 0.0735, -0.2188,  0.3925,  0.3570,  0.3746,  0.2191
 0.1230, -0.2838,  0.2262,  0.8715,  0.1938,  0.2878
 0.4792, -0.9248,  0.5295,  0.0366, -0.9894,  0.3149
-0.4456,  0.0697,  0.5359, -0.8938,  0.0981,  0.3879
 0.8629, -0.8505, -0.4464,  0.8385,  0.5300,  0.1769
 0.1995,  0.6659,  0.7921,  0.9454,  0.9970,  0.2330
-0.0249, -0.3066, -0.2927, -0.4923,  0.8220,  0.2437
 0.4513, -0.9481, -0.0770, -0.4374, -0.9421,  0.2879
-0.3405,  0.5931, -0.3507, -0.3842,  0.8562,  0.3987
 0.9538,  0.0471,  0.9039,  0.7760,  0.0361,  0.1706
-0.0887,  0.2104,  0.9808,  0.5478, -0.3314,  0.4128
-0.8220, -0.6302,  0.0537, -0.1658,  0.6013,  0.4306
-0.4123, -0.2880,  0.9074, -0.0461, -0.4435,  0.5144
 0.0060,  0.2867, -0.7775,  0.5161,  0.7039,  0.3599
-0.7968, -0.5484,  0.9426, -0.4308,  0.8148,  0.2979
 0.7811,  0.8450, -0.6877,  0.7594,  0.2640,  0.2362
-0.6802, -0.1113, -0.8325, -0.6694, -0.6056,  0.6544
 0.3821,  0.1476,  0.7466, -0.5107,  0.2592,  0.1648
 0.7265,  0.9683, -0.9803, -0.4943, -0.5523,  0.2454
-0.9049, -0.9797, -0.0196, -0.9090, -0.4433,  0.6447
-0.4607,  0.1811, -0.2389,  0.4050, -0.0078,  0.5229
 0.2664, -0.2932, -0.4259, -0.7336,  0.8742,  0.1834
-0.4507,  0.1029, -0.6294, -0.1158, -0.6294,  0.6081
 0.8948, -0.0124,  0.9278,  0.2899, -0.0314,  0.1534
-0.1323, -0.8813, -0.0146, -0.0697,  0.6135,  0.2386

One Saturday morning, after I walked my two dogs (Riley and Kevin) and a visiting dog (Llama), I figured I would take a look at the XBGoost (“extreme gradient boosting”) regression code library.

The goal of a machine learning regression problem is to predict a single numeric value. For example, you might want to predict the bank account balance of a person based on their age, annual income, and so on.

There are roughly one dozen major regression techniques: linear regression, nearest neighbors regression, quadratic regression, kernel ridge regression (and its cousin Gaussian process regression), support vector regression, neural network regression, decision tree regression, random forest regression (and its cousin bagging tree regression), AdaBoost regression, and gradient boosting regression.

Gradient boost regression uses a collection (typically about 100) of basic decision tree regressors. Very loosely speaking, each tree is constructed based on predicting the errors (residuals) of the previous tree, so, in theory, each tree is a bit better than the previous tree at predicting difficult items. The ideas behind gradient boosting regression are actually extremely deep and subtle.

I implementing gradient boost regression from scratch is possible, but quite difficult. Therefore there are several code libraries for gradient boost regression available. One of the most widely-used libraries is called XGBoost. XGBoost can do both classification (predict a non-numeric value) and regression.

XGBoost is implemented using C/C++ but since calling C/C++ code is difficult, there are wrappers for different, easier-to-use languages. The most popular wrapper for XGBoost is the scikit-learn API version.

I installed the xgboost scikit library using the command “pip install xgboost”. The library installed successfully. I put together a demo. The output is:

Begin XGBoost Regression demo

Loading synthetic train (200), test (40) data
Done

First three X predictors:
[[-0.1660  0.4406 -0.9998 -0.3953 -0.7065]
 [ 0.0776 -0.1616  0.3704 -0.5911  0.7562]
 [-0.9452  0.3409 -0.1654  0.1174 -0.7192]]

First three y targets:
0.4840
0.1568
0.8054

Setting n_estimators = 90
Setting max_depth = 5
Setting lrn_rate = 0.0500

Training XGB Regression model
Done

Evaluating model

Accuracy train (within 0.10): 0.9600
Accuracy test (within 0.10): 0.5500

MSE train: 0.0000
MSE test: 0.0014

R2 train: 0.9988
R2 test: 0.9490

Predicting for x =
[-0.1660  0.4406 -0.9998 -0.3953 -0.7065]
Predicted y = 0.4868

End demo

For my demo, I used one of my standard datasets. The data is synthetic (generated by a neural network with random weights and biases). Each data item has five predictors. There are 200 training items annd 40 test items.

The trained model scores 96.00% accuracy on the training data (192 out of 200 correct), but only 55.00% accuracy on the test data (22 out of 40 correct). A prediction is scored as correct if it’s within 10% of the true target value.

This illustrates the biggest problem with tree-based regression systems — model overfitting, where the model predicts the training data with near-perfect accuracy, but predicts poorly on new, previously unseen data.

I ran the data through a from-scratch gradient boost regression model, and also through the scikit-learn GradientBoostingRegressor module. The accuracy, MSE, and R2 evaluation metrics were essentially identical (the same to within 4 decimal places).

I am not a big fan of the XGBoost regression system, mostly because there are a huge number of training parameters (40) to deal with:

n_estimators, max_depth , max_leave, max_bin, grow_policy,
learning_rate, verbosity, objective, booster, tree_method,
n_jobs, gamma, min_child_weight, max_delta_step, subsample,
sampling_method, colsample_bytree, colsample_bylevel,
colsample_bynode, reg_alpha, reg_lambda, scale_pos_weight,
base_score, random_state, missing, num_parallel_tree,
monotone_constraints, interaction_constraints,
importance_type, device, validate_parameters,
enable_categorical, feature_types, feature_weights,
max_cat_to_onehot, max_cat_threshold, multi_strategy,
eval_metric, early_stopping_rounds, callbacks, kwargs

This is a library API that is completely out of control. It’s true that all the parameters have reasonable default values, but still, 40 parameters is just too many.

Anyway, good fun for me on a Saturday morning.

The many parameters of the XGBoost regression system are like actors in a movie — some are extremely important and some play supporting roles. Asian actors and actresses appeared very rarely in Western science fiction films of the 1950s and 1960s.

Right: In “The Phantom Planet” (1961), two astronauts go to investigate a mysterious asteroid. One astronaut is killed in an accident. The other lands on the asteroid, and is immediate shrunk to six inches tall, and finds a race a similarly-sized aliens. He eventually returns to Earth. Actress Akemi Tani (no relation to actress Yoko Tani) plays a communications officer on Earth. Weird movie, but interesting to me. My grade = C-.

Demo program. Replace “lt” (less than), “gt”, “lte”, “gte” with Boolean operator symbols. (My blog editor consistently chokes on symbols).

# xgboost_regression.py

import numpy as np
import xgboost as xgb

# -----------------------------------------------------------

def accuracy(model, data_X, data_y, pct_close):
  # assumes model has a predict(X)
  n = len(data_X)
  n_correct = 0; n_wrong = 0
  for i in range(n):
    x = data_X[i].reshape(1,-1)  # make it a matrix
    y = data_y[i]
    y_pred = model.predict(x)[0]  # predict() expects 2D

    if np.abs(y - y_pred) "lt" np.abs(y * pct_close):
      n_correct += 1
    else:
      n_wrong += 1
  # print("Correct = " + str(n_correct))
  # print("Wrong   = " + str(n_wrong))
  return n_correct / (n_correct + n_wrong)

# -----------------------------------------------------------

def MSE(model, data_X, data_y):
  n = len(data_X)
  sum = 0.0
  for i in range(n):
    x = data_X[i].reshape(1,-1)
    y = data_y[i]
    y_pred = model.predict(x)[0]
    sum += (y - y_pred) * (y - y_pred)

  return sum / n

# -----------------------------------------------------------

def main():
  print("\nBegin XGBoost Regression demo ")

  np.set_printoptions(precision=4, suppress=True,
    floatmode='fixed')
  np.random.seed(0)  # not used this version

  # 1. load data
  print("\nLoading synthetic train (200), test (40) data ")
  train_file = ".\\Data\\synthetic_train_200.txt"
  # -0.1660,0.4406,-0.9998,-0.3953,-0.7065,0.4840
  #  0.0776,-0.1616,0.3704,-0.5911,0.7562,0.1568
  # -0.9452,0.3409,-0.1654,0.1174,-0.7192,0.8054
  # . . .

  train_X = np.loadtxt(train_file, comments="#",
    usecols=[0,1,2,3,4],
    delimiter=",",  dtype=np.float64)
  train_y = np.loadtxt(train_file, comments="#", usecols=5,
    delimiter=",",  dtype=np.float64)

  test_file = ".\\Data\\synthetic_test_40.txt"
  test_X = np.loadtxt(test_file, comments="#",
    usecols=[0,1,2,3,4],
    delimiter=",",  dtype=np.float64)
  test_y = np.loadtxt(test_file, comments="#", usecols=5,
    delimiter=",",  dtype=np.float64)
  print("Done ")

  print("\nFirst three X predictors: ")
  print(train_X[0:3,:])
  print("\nFirst three y targets: ")
  for i in range(3):
    print("%0.4f" % train_y[i])

  n_estimators = 90
  max_depth = 5
  learning_rate = 0.05
  seed = 0

  print("\nSetting n_estimators = " + \
    str(n_estimators))
  print("Setting max_depth = " + \
    str(max_depth))
  print("Setting lrn_rate = %0.4f " % learning_rate)

  model = \
    xgb.XGBRegressor(n_estimators=n_estimators,
    learning_rate=learning_rate, max_depth=max_depth,
    random_state=seed)

  print("\nTraining XGB Regression model ")
  model.fit(train_X, train_y)
  print("Done " )

  print("\nEvaluating model ")
  acc_train = accuracy(model, train_X, train_y, 0.10)
  print("\nAccuracy train (within 0.10): %0.4f " % acc_train)
  acc_test = accuracy(model, test_X, test_y, 0.10)
  print("Accuracy test (within 0.10): %0.4f " % acc_test)

  mse_train = MSE(model, train_X, train_y)
  print("\nMSE train: %0.4f " % mse_train)
  mse_test = MSE(model, test_X, test_y)
  print("MSE test: %0.4f " % mse_test)

  r2_train = model.score(train_X, train_y)
  print("\nR2 train: %0.4f " % r2_train)
  r2_test = model.score(test_X, test_y)
  print("R2 test: %0.4f " % r2_test)

  print("\nPredicting for x = ")
  print(train_X[0])
  pred_y = model.predict(train_X[0].reshape(1,-1))[0]
  print("Predicted y = %0.4f " % pred_y)

  print("\nEnd demo ")

if __name__ == "__main__":
  main()

Training data:

# synthetic_train_200.txt
#
-0.1660,  0.4406, -0.9998, -0.3953, -0.7065,  0.4840
 0.0776, -0.1616,  0.3704, -0.5911,  0.7562,  0.1568
-0.9452,  0.3409, -0.1654,  0.1174, -0.7192,  0.8054
 0.9365, -0.3732,  0.3846,  0.7528,  0.7892,  0.1345
-0.8299, -0.9219, -0.6603,  0.7563, -0.8033,  0.7955
 0.0663,  0.3838, -0.3690,  0.3730,  0.6693,  0.3206
-0.9634,  0.5003,  0.9777,  0.4963, -0.4391,  0.7377
-0.1042,  0.8172, -0.4128, -0.4244, -0.7399,  0.4801
-0.9613,  0.3577, -0.5767, -0.4689, -0.0169,  0.6861
-0.7065,  0.1786,  0.3995, -0.7953, -0.1719,  0.5569
 0.3888, -0.1716, -0.9001,  0.0718,  0.3276,  0.2500
 0.1731,  0.8068, -0.7251, -0.7214,  0.6148,  0.3297
-0.2046, -0.6693,  0.8550, -0.3045,  0.5016,  0.2129
 0.2473,  0.5019, -0.3022, -0.4601,  0.7918,  0.2613
-0.1438,  0.9297,  0.3269,  0.2434, -0.7705,  0.5171
 0.1568, -0.1837, -0.5259,  0.8068,  0.1474,  0.3307
-0.9943,  0.2343, -0.3467,  0.0541,  0.7719,  0.5581
 0.2467, -0.9684,  0.8589,  0.3818,  0.9946,  0.1092
-0.6553, -0.7257,  0.8652,  0.3936, -0.8680,  0.7018
 0.8460,  0.4230, -0.7515, -0.9602, -0.9476,  0.1996
-0.9434, -0.5076,  0.7201,  0.0777,  0.1056,  0.5664
 0.9392,  0.1221, -0.9627,  0.6013, -0.5341,  0.1533
 0.6142, -0.2243,  0.7271,  0.4942,  0.1125,  0.1661
 0.4260,  0.1194, -0.9749, -0.8561,  0.9346,  0.2230
 0.1362, -0.5934, -0.4953,  0.4877, -0.6091,  0.3810
 0.6937, -0.5203, -0.0125,  0.2399,  0.6580,  0.1460
-0.6864, -0.9628, -0.8600, -0.0273,  0.2127,  0.5387
 0.9772,  0.1595, -0.2397,  0.1019,  0.4907,  0.1611
 0.3385, -0.4702, -0.8673, -0.2598,  0.2594,  0.2270
-0.8669, -0.4794,  0.6095, -0.6131,  0.2789,  0.4700
 0.0493,  0.8496, -0.4734, -0.8681,  0.4701,  0.3516
 0.8639, -0.9721, -0.5313,  0.2336,  0.8980,  0.1412
 0.9004,  0.1133,  0.8312,  0.2831, -0.2200,  0.1782
 0.0991,  0.8524,  0.8375, -0.2102,  0.9265,  0.2150
-0.6521, -0.7473, -0.7298,  0.0113, -0.9570,  0.7422
 0.6190, -0.3105,  0.8802,  0.1640,  0.7577,  0.1056
 0.6895,  0.8108, -0.0802,  0.0927,  0.5972,  0.2214
 0.1982, -0.9689,  0.1870, -0.1326,  0.6147,  0.1310
-0.3695,  0.7858,  0.1557, -0.6320,  0.5759,  0.3773
-0.1596,  0.3581,  0.8372, -0.9992,  0.9535,  0.2071
-0.2468,  0.9476,  0.2094,  0.6577,  0.1494,  0.4132
 0.1737,  0.5000,  0.7166,  0.5102,  0.3961,  0.2611
 0.7290, -0.3546,  0.3416, -0.0983, -0.2358,  0.1332
-0.3652,  0.2438, -0.1395,  0.9476,  0.3556,  0.4170
-0.6029, -0.1466, -0.3133,  0.5953,  0.7600,  0.4334
-0.4596, -0.4953,  0.7098,  0.0554,  0.6043,  0.2775
 0.1450,  0.4663,  0.0380,  0.5418,  0.1377,  0.2931
-0.8636, -0.2442, -0.8407,  0.9656, -0.6368,  0.7429
 0.6237,  0.7499,  0.3768,  0.1390, -0.6781,  0.2185
-0.5499,  0.1850, -0.3755,  0.8326,  0.8193,  0.4399
-0.4858, -0.7782, -0.6141, -0.0008,  0.4572,  0.4197
 0.7033, -0.1683,  0.2334, -0.5327, -0.7961,  0.1776
 0.0317, -0.0457, -0.6947,  0.2436,  0.0880,  0.3345
 0.5031, -0.5559,  0.0387,  0.5706, -0.9553,  0.3107
-0.3513,  0.7458,  0.6894,  0.0769,  0.7332,  0.3170
 0.2205,  0.5992, -0.9309,  0.5405,  0.4635,  0.3532
-0.4806, -0.4859,  0.2646, -0.3094,  0.5932,  0.3202
 0.9809, -0.3995, -0.7140,  0.8026,  0.0831,  0.1600
 0.9495,  0.2732,  0.9878,  0.0921,  0.0529,  0.1289
-0.9476, -0.6792,  0.4913, -0.9392, -0.2669,  0.5966
 0.7247,  0.3854,  0.3819, -0.6227, -0.1162,  0.1550
-0.5922, -0.5045, -0.4757,  0.5003, -0.0860,  0.5863
-0.8861,  0.0170, -0.5761,  0.5972, -0.4053,  0.7301
 0.6877, -0.2380,  0.4997,  0.0223,  0.0819,  0.1404
 0.9189,  0.6079, -0.9354,  0.4188, -0.0700,  0.1907
-0.1428, -0.7820,  0.2676,  0.6059,  0.3936,  0.2790
 0.5324, -0.3151,  0.6917, -0.1425,  0.6480,  0.1071
-0.8432, -0.9633, -0.8666, -0.0828, -0.7733,  0.7784
-0.9444,  0.5097, -0.2103,  0.4939, -0.0952,  0.6787
-0.0520,  0.6063, -0.1952,  0.8094, -0.9259,  0.4836
 0.5477, -0.7487,  0.2370, -0.9793,  0.0773,  0.1241
 0.2450,  0.8116,  0.9799,  0.4222,  0.4636,  0.2355
 0.8186, -0.1983, -0.5003, -0.6531, -0.7611,  0.1511
-0.4714,  0.6382, -0.3788,  0.9648, -0.4667,  0.5950
 0.0673, -0.3711,  0.8215, -0.2669, -0.1328,  0.2677
-0.9381,  0.4338,  0.7820, -0.9454,  0.0441,  0.5518
-0.3480,  0.7190,  0.1170,  0.3805, -0.0943,  0.4724
-0.9813,  0.1535, -0.3771,  0.0345,  0.8328,  0.5438
-0.1471, -0.5052, -0.2574,  0.8637,  0.8737,  0.3042
-0.5454, -0.3712, -0.6505,  0.2142, -0.1728,  0.5783
 0.6327, -0.6297,  0.4038, -0.5193,  0.1484,  0.1153
-0.5424,  0.3282, -0.0055,  0.0380, -0.6506,  0.6613
 0.1414,  0.9935,  0.6337,  0.1887,  0.9520,  0.2540
-0.9351, -0.8128, -0.8693, -0.0965, -0.2491,  0.7353
 0.9507, -0.6640,  0.9456,  0.5349,  0.6485,  0.1059
-0.0462, -0.9737, -0.2940, -0.0159,  0.4602,  0.2606
-0.0627, -0.0852, -0.7247, -0.9782,  0.5166,  0.2977
 0.0478,  0.5098, -0.0723, -0.7504, -0.3750,  0.3335
 0.0090,  0.3477,  0.5403, -0.7393, -0.9542,  0.4415
-0.9748,  0.3449,  0.3736, -0.1015,  0.8296,  0.4358
 0.2887, -0.9895, -0.0311,  0.7186,  0.6608,  0.2057
 0.1570, -0.4518,  0.1211,  0.3435, -0.2951,  0.3244
 0.7117, -0.6099,  0.4946, -0.4208,  0.5476,  0.1096
-0.2929, -0.5726,  0.5346, -0.3827,  0.4665,  0.2465
 0.4889, -0.5572, -0.5718, -0.6021, -0.7150,  0.2163
-0.7782,  0.3491,  0.5996, -0.8389, -0.5366,  0.6516
-0.5847,  0.8347,  0.4226,  0.1078, -0.3910,  0.6134
 0.8469,  0.4121, -0.0439, -0.7476,  0.9521,  0.1571
-0.6803, -0.5948, -0.1376, -0.1916, -0.7065,  0.7156
 0.2878,  0.5086, -0.5785,  0.2019,  0.4979,  0.2980
 0.2764,  0.1943, -0.4090,  0.4632,  0.8906,  0.2960
-0.8877,  0.6705, -0.6155, -0.2098, -0.3998,  0.7107
-0.8398,  0.8093, -0.2597,  0.0614, -0.0118,  0.6502
-0.8476,  0.0158, -0.4769, -0.2859, -0.7839,  0.7715
 0.5751, -0.7868,  0.9714, -0.6457,  0.1448,  0.1175
 0.4802, -0.7001,  0.1022, -0.5668,  0.5184,  0.1090
 0.4458, -0.6469,  0.7239, -0.9604,  0.7205,  0.0779
 0.5175,  0.4339,  0.9747, -0.4438, -0.9924,  0.2879
 0.8678,  0.7158,  0.4577,  0.0334,  0.4139,  0.1678
 0.5406,  0.5012,  0.2264, -0.1963,  0.3946,  0.2088
-0.9938,  0.5498,  0.7928, -0.5214, -0.7585,  0.7687
 0.7661,  0.0863, -0.4266, -0.7233, -0.4197,  0.1466
 0.2277, -0.3517, -0.0853, -0.1118,  0.6563,  0.1767
 0.3499, -0.5570, -0.0655, -0.3705,  0.2537,  0.1632
 0.7547, -0.1046,  0.5689, -0.0861,  0.3125,  0.1257
 0.8186,  0.2110,  0.5335,  0.0094, -0.0039,  0.1391
 0.6858, -0.8644,  0.1465,  0.8855,  0.0357,  0.1845
-0.4967,  0.4015,  0.0805,  0.8977,  0.2487,  0.4663
 0.6760, -0.9841,  0.9787, -0.8446, -0.3557,  0.1509
-0.1203, -0.4885,  0.6054, -0.0443, -0.7313,  0.4854
 0.8557,  0.7919, -0.0169,  0.7134, -0.1628,  0.2002
 0.0115, -0.6209,  0.9300, -0.4116, -0.7931,  0.4052
-0.7114, -0.9718,  0.4319,  0.1290,  0.5892,  0.3661
 0.3915,  0.5557, -0.1870,  0.2955, -0.6404,  0.2954
-0.3564, -0.6548, -0.1827, -0.5172, -0.1862,  0.4622
 0.2392, -0.4959,  0.5857, -0.1341, -0.2850,  0.2470
-0.3394,  0.3947, -0.4627,  0.6166, -0.4094,  0.5325
 0.7107,  0.7768, -0.6312,  0.1707,  0.7964,  0.2757
-0.1078,  0.8437, -0.4420,  0.2177,  0.3649,  0.4028
-0.3139,  0.5595, -0.6505, -0.3161, -0.7108,  0.5546
 0.4335,  0.3986,  0.3770, -0.4932,  0.3847,  0.1810
-0.2562, -0.2894, -0.8847,  0.2633,  0.4146,  0.4036
 0.2272,  0.2966, -0.6601, -0.7011,  0.0284,  0.2778
-0.0743, -0.1421, -0.0054, -0.6770, -0.3151,  0.3597
-0.4762,  0.6891,  0.6007, -0.1467,  0.2140,  0.4266
-0.4061,  0.7193,  0.3432,  0.2669, -0.7505,  0.6147
-0.0588,  0.9731,  0.8966,  0.2902, -0.6966,  0.4955
-0.0627, -0.1439,  0.1985,  0.6999,  0.5022,  0.3077
 0.1587,  0.8494, -0.8705,  0.9827, -0.8940,  0.4263
-0.7850,  0.2473, -0.9040, -0.4308, -0.8779,  0.7199
 0.4070,  0.3369, -0.2428, -0.6236,  0.4940,  0.2215
-0.0242,  0.0513, -0.9430,  0.2885, -0.2987,  0.3947
-0.5416, -0.1322, -0.2351, -0.0604,  0.9590,  0.3683
 0.1055,  0.7783, -0.2901, -0.5090,  0.8220,  0.2984
-0.9129,  0.9015,  0.1128, -0.2473,  0.9901,  0.4776
-0.9378,  0.1424, -0.6391,  0.2619,  0.9618,  0.5368
 0.7498, -0.0963,  0.4169,  0.5549, -0.0103,  0.1614
-0.2612, -0.7156,  0.4538, -0.0460, -0.1022,  0.3717
 0.7720,  0.0552, -0.1818, -0.4622, -0.8560,  0.1685
-0.4177,  0.0070,  0.9319, -0.7812,  0.3461,  0.3052
-0.0001,  0.5542, -0.7128, -0.8336, -0.2016,  0.3803
 0.5356, -0.4194, -0.5662, -0.9666, -0.2027,  0.1776
-0.2378,  0.3187, -0.8582, -0.6948, -0.9668,  0.5474
-0.1947, -0.3579,  0.1158,  0.9869,  0.6690,  0.2992
 0.3992,  0.8365, -0.9205, -0.8593, -0.0520,  0.3154
-0.0209,  0.0793,  0.7905, -0.1067,  0.7541,  0.1864
-0.4928, -0.4524, -0.3433,  0.0951, -0.5597,  0.6261
-0.8118,  0.7404, -0.5263, -0.2280,  0.1431,  0.6349
 0.0516, -0.8480,  0.7483,  0.9023,  0.6250,  0.1959
-0.3212,  0.1093,  0.9488, -0.3766,  0.3376,  0.2735
-0.3481,  0.5490, -0.3484,  0.7797,  0.5034,  0.4379
-0.5785, -0.9170, -0.3563, -0.9258,  0.3877,  0.4121
 0.3407, -0.1391,  0.5356,  0.0720, -0.9203,  0.3458
-0.3287, -0.8954,  0.2102,  0.0241,  0.2349,  0.3247
-0.1353,  0.6954, -0.0919, -0.9692,  0.7461,  0.3338
 0.9036, -0.8982, -0.5299, -0.8733, -0.1567,  0.1187
 0.7277, -0.8368, -0.0538, -0.7489,  0.5458,  0.0830
 0.9049,  0.8878,  0.2279,  0.9470, -0.3103,  0.2194
 0.7957, -0.1308, -0.5284,  0.8817,  0.3684,  0.2172
 0.4647, -0.4931,  0.2010,  0.6292, -0.8918,  0.3371
-0.7390,  0.6849,  0.2367,  0.0626, -0.5034,  0.7039
-0.1567, -0.8711,  0.7940, -0.5932,  0.6525,  0.1710
 0.7635, -0.0265,  0.1969,  0.0545,  0.2496,  0.1445
 0.7675,  0.1354, -0.7698, -0.5460,  0.1920,  0.1728
-0.5211, -0.7372, -0.6763,  0.6897,  0.2044,  0.5217
 0.1913,  0.1980,  0.2314, -0.8816,  0.5006,  0.1998
 0.8964,  0.0694, -0.6149,  0.5059, -0.9854,  0.1825
 0.1767,  0.7104,  0.2093,  0.6452,  0.7590,  0.2832
-0.3580, -0.7541,  0.4426, -0.1193, -0.7465,  0.5657
-0.5996,  0.5766, -0.9758, -0.3933, -0.9572,  0.6800
 0.9950,  0.1641, -0.4132,  0.8579,  0.0142,  0.2003
-0.4717, -0.3894, -0.2567, -0.5111,  0.1691,  0.4266
 0.3917, -0.8561,  0.9422,  0.5061,  0.6123,  0.1212
-0.0366, -0.1087,  0.3449, -0.1025,  0.4086,  0.2475
 0.3633,  0.3943,  0.2372, -0.6980,  0.5216,  0.1925
-0.5325, -0.6466, -0.2178, -0.3589,  0.6310,  0.3568
 0.2271,  0.5200, -0.1447, -0.8011, -0.7699,  0.3128
 0.6415,  0.1993,  0.3777, -0.0178, -0.8237,  0.2181
-0.5298, -0.0768, -0.6028, -0.9490,  0.4588,  0.4356
 0.6870, -0.1431,  0.7294,  0.3141,  0.1621,  0.1632
-0.5985,  0.0591,  0.7889, -0.3900,  0.7419,  0.2945
 0.3661,  0.7984, -0.8486,  0.7572, -0.6183,  0.3449
 0.6995,  0.3342, -0.3113, -0.6972,  0.2707,  0.1712
 0.2565,  0.9126,  0.1798, -0.6043, -0.1413,  0.2893
-0.3265,  0.9839, -0.2395,  0.9854,  0.0376,  0.4770
 0.2690, -0.1722,  0.9818,  0.8599, -0.7015,  0.3954
-0.2102, -0.0768,  0.1219,  0.5607, -0.0256,  0.3949
 0.8216, -0.9555,  0.6422, -0.6231,  0.3715,  0.0801
-0.2896,  0.9484, -0.7545, -0.6249,  0.7789,  0.4370
-0.9985, -0.5448, -0.7092, -0.5931,  0.7926,  0.5402

Test data:

# synthetic_test_40.txt
#
 0.7462,  0.4006, -0.0590,  0.6543, -0.0083,  0.1935
 0.8495, -0.2260, -0.0142, -0.4911,  0.7699,  0.1078
-0.2335, -0.4049,  0.4352, -0.6183, -0.7636,  0.5088
 0.1810, -0.5142,  0.2465,  0.2767, -0.3449,  0.3136
-0.8650,  0.7611, -0.0801,  0.5277, -0.4922,  0.7140
-0.2358, -0.7466, -0.5115, -0.8413, -0.3943,  0.4533
 0.4834,  0.2300,  0.3448, -0.9832,  0.3568,  0.1360
-0.6502, -0.6300,  0.6885,  0.9652,  0.8275,  0.3046
-0.3053,  0.5604,  0.0929,  0.6329, -0.0325,  0.4756
-0.7995,  0.0740, -0.2680,  0.2086,  0.9176,  0.4565
-0.2144, -0.2141,  0.5813,  0.2902, -0.2122,  0.4119
-0.7278, -0.0987, -0.3312, -0.5641,  0.8515,  0.4438
 0.3793,  0.1976,  0.4933,  0.0839,  0.4011,  0.1905
-0.8568,  0.9573, -0.5272,  0.3212, -0.8207,  0.7415
-0.5785,  0.0056, -0.7901, -0.2223,  0.0760,  0.5551
 0.0735, -0.2188,  0.3925,  0.3570,  0.3746,  0.2191
 0.1230, -0.2838,  0.2262,  0.8715,  0.1938,  0.2878
 0.4792, -0.9248,  0.5295,  0.0366, -0.9894,  0.3149
-0.4456,  0.0697,  0.5359, -0.8938,  0.0981,  0.3879
 0.8629, -0.8505, -0.4464,  0.8385,  0.5300,  0.1769
 0.1995,  0.6659,  0.7921,  0.9454,  0.9970,  0.2330
-0.0249, -0.3066, -0.2927, -0.4923,  0.8220,  0.2437
 0.4513, -0.9481, -0.0770, -0.4374, -0.9421,  0.2879
-0.3405,  0.5931, -0.3507, -0.3842,  0.8562,  0.3987
 0.9538,  0.0471,  0.9039,  0.7760,  0.0361,  0.1706
-0.0887,  0.2104,  0.9808,  0.5478, -0.3314,  0.4128
-0.8220, -0.6302,  0.0537, -0.1658,  0.6013,  0.4306
-0.4123, -0.2880,  0.9074, -0.0461, -0.4435,  0.5144
 0.0060,  0.2867, -0.7775,  0.5161,  0.7039,  0.3599
-0.7968, -0.5484,  0.9426, -0.4308,  0.8148,  0.2979
 0.7811,  0.8450, -0.6877,  0.7594,  0.2640,  0.2362
-0.6802, -0.1113, -0.8325, -0.6694, -0.6056,  0.6544
 0.3821,  0.1476,  0.7466, -0.5107,  0.2592,  0.1648
 0.7265,  0.9683, -0.9803, -0.4943, -0.5523,  0.2454
-0.9049, -0.9797, -0.0196, -0.9090, -0.4433,  0.6447
-0.4607,  0.1811, -0.2389,  0.4050, -0.0078,  0.5229
 0.2664, -0.2932, -0.4259, -0.7336,  0.8742,  0.1834
-0.4507,  0.1029, -0.6294, -0.1158, -0.6294,  0.6081
 0.8948, -0.0124,  0.9278,  0.2899, -0.0314,  0.1534
-0.1323, -0.8813, -0.0146, -0.0697,  0.6135,  0.2386

Arguably the most basic form of machine learning regression is linear regression. The liner regression prediction model is y’ = (x0 * w0) + (x1 * w1) + . . (xn * wn) + b. The y’ is the predicted value. The xi are the predictor values, the wi are the model weights (aka coefficients), and b is the bias (aka intercept).

If you have a set of training data with known correct target values, training the model is the process of finding good values for the weights and bias so that the mean squared error between predicted y values and target y values is minimized.

There are many training techniques. One category of techniques is iterative, with a training loop that gets closer and closer to optimal weight and bias values (SGD and its variations). Another category of techniques is called closed form solutions. The weights and bias are computed directly, using clever math. The three closed-form techniques I use most often are: 1.) The QR decomp + Solve OLS technique, 2.) The Moore-Penrose pseudo-inverse via QR technique, 3.) The left pseudo-inverse via Cholesky inverse technique.

1. The QR decomp + Solve OLS technique:

1. X * w = y
2. (Q * R) * w = y
3. Qt * (Q * R) * w = Qt * y
4. R * w = Qt * y
5. w = Solve(R, Qt * y) // back-substitution

The X is a matrix of predictor values, with a leading column of 1.0 values added to stand in for the model bias. The w is a vector that holds the bias in cell [0] and the weights in the remaining cells. Step 1 is the starting point. In step 2, X hs been decomposed using QR decomposition. In step 3, both sides are multiplied by Qt, which is the transpose of Q. Step 4 uses the fact that Qt is the matrix inverse of Q. Step 5 solves for the weight vector using an abbreviated form os sort-of matrix inverse called ordinary least squares solve, which uses a technique called back-substitution.

Example C# code:

public void Train(double[][] trainX, double[] trainY)
{
  // w = Solve(R, Qt * y)
  int dim = trainX[0].Length;
  this.weights = new double[dim];
  double[][] X = MatToDesign(trainX);

  double[][] Q; double[][] R;
  QRHouseholder.MatDecompQR(X, out Q, out R);
  double[][] Qt = QRHouseholder.MatTranspose(Q);
  double[] biasAndWts = MatSolveQR(R, Qt, trainY);
  this.bias = biasAndWts[0];
  for (int i = 1; i < biasAndWts.Length; ++i)
    this.weights[i - 1] = biasAndWts[i];
}

public static double[] MatSolveQR(double[][] R,
  double[][] Qt, double[] y)
{
  double[] z = MatVecProd(Qt, y); // Qt * y

  int n = R[0].Length;
  double[] w = new double[n];
  // back-substitution
  for (int i = n - 1; i >= 0; --i)
  {
    double sum = z[i];
    for (int j = i + 1; j < n; ++j)
      sum -= R[i][j] * w[j];
    w[i] = sum / R[i][i];
  }
  return w;
}

This technique is used by most library implementations. The solve() function is similar to a matrix inverse() function but uses far fewer operations and so is more stable.

2. The Moore-Penrose pseudo-inverse via QR technique:

1. X * w = y
2. inv(X) * X * w = inv(X) * y // inv() is matrix inverse
3. w = inv(X) * y
4. w = inv(Q * R) * y
5. w = inv(R) * inv(Q) * y
6. w = inv(R) * Qt * y // inv(R) easy, Qt is transpose Q

Step 1 is the starting point. In step 2, both sides are multiplied by inv(X), which is the pseudo-inverse. Step 3 uses the fact that inx(X) * X = I the identity matrix. Step 4 applies QR decomposition to X. Step 5 is a consequence of inv(A*B) = inv(B)*inv(A). Step 6 uses the fact that the transpose of Q, Qt, is the inverse of Q. The inverse of R is a special, easy case (because R is an upper triangular matrix).

Example C# code:

public void Train(double[][] trainX, double[] trainY)
{
  // w = inv(R) * Qt * y
  int dim = trainX[0].Length;
  this.weights = new double[dim];
  double[][] X = MatToDesign(trainX);

  double[][] Q; double[][] R;
  QRHouseholder.MatDecompQR(X, out Q, out R);
  double[][] Ri = QRHouseholder.MatInvUpperTri(R);
  double[][] Qt = QRHouseholder.MatTranspose(Q);
  double[][] RiQt = QRHouseholder.MatProduct(Ri, Qt);
  double[] biasAndWts = MatVecProd(RiQt, trainY);
  this.bias = biasAndWts[0];
  for (int i = 1; i < biasAndWts.Length; ++i)
    this.weights[i - 1] = biasAndWts[i]; }

This technique is not bad but it explicitly computes inv(R). The solve() technique does not compute an explicit inverse and is faster and more stable.

3. The left pseudo-inverse via Cholesky inverse technique:

1. X * w = y
2. (Xt * X) * w = Xt * y // problematic
3. inv(Xt * X) * (Xt * X) * w = inv(Xt * X) * Xt * y
4. w = inv(Xt * X) * Xt * y

Step 1 is the starting point. In step 2, both sides are pre-multiplied by Xt, the transpose of X. In step 3, both sides are pre-multiplied by inv(Xt * X). Step 4 uses the fact that inv(A) * A = I, the identity matrix. The inv(Xt * X) inverse calculation uses Cholesky inverse and is relatively easy because (Xt * X) is square symmetic positive definite.

Example C# code:

public void Train(double[][] trainX, double[] trainY)
{
  // w = inv(Xt * X) * Xt * y
  int dim = trainX[0].Length;
  this.weights = new double[dim];
  double[][] X = MatToDesign(trainX);

  double[][] Xt = Cholesky.MatTranspose(X);
  double[][] XtX = Cholesky.MatProduct(Xt, X);
  double[][] XtXinv = Cholesky.MatInvCholesky(XtX);
  double[][] tmp = Cholesky.MatProduct(XtXinv, Xt);

  double[] biasAndWts = MatVecProd(tmp, trainY);
  // extract bias and weights
  this.bias = biasAndWts[0];
  for (int i = 1; i < biasAndWts.Length; ++i)
    this.weights[i - 1] = biasAndWts[i];
}

The left pseudo-inverse training technique is rarely used except when X is small. If X has m rows and n columns, the Xt * X calculation requires m * n^2 multiplications and n^2 * (m-1) additions. For example, if m is 10,000 rows and n is 10 columns, there are 10,000 * 100 = 1,000,000 multiplication and approximately 100 * 10,000 = 1,000,000 additions. Arithmetic overflow, underflow, or a inaccurate result could easily happen.

I miss the days of newspapers

Demo program. Replace "lt" (less than), "gt", "lte", "gte" with Boolean operator symbols (my blog editor chokes on symbols).

using System;
using System.IO;
using System.Collections.Generic;

namespace LinearRegressionThreeClosedFormTrainingTechniques
{
  internal class LinearRegressionProgram
  {
    static void Main(string[] args)
    {
      Console.WriteLine("\nBegin C# linear regression" +
        " with three closed-form training techniques ");

      // 1. load data
      Console.WriteLine("\nLoading synthetic train" +
        " (200) and test (40) data");
      string trainFile =
        "..\\..\\..\\Data\\synthetic_train_200.txt";
      int[] colsX = new int[] { 0, 1, 2, 3, 4 };
      double[][] trainX =
        MatLoad(trainFile, colsX, ',', "#");
      double[] trainY =
        MatToVec(MatLoad(trainFile,
        new int[] { 5 }, ',', "#"));

      string testFile =
        "..\\..\\..\\Data\\synthetic_test_40.txt";
      double[][] testX =
         MatLoad(testFile, colsX, ',', "#");
      double[] testY =
        MatToVec(MatLoad(testFile,
        new int[] { 5 }, ',', "#"));
      Console.WriteLine("Done ");

      Console.WriteLine("\nFirst three train X: ");
      for (int i = 0; i "lt" 3; ++i)
        VecShow(trainX[i], 4, 8);

      Console.WriteLine("\nFirst three train y: ");
      for (int i = 0; i "lt" 3; ++i)
        Console.WriteLine(trainY[i].ToString("F4").
          PadLeft(8));

      // 1. QR OLS Solve training
      Console.WriteLine("\n1. QR OLS Solve training ");
      LinearRegressor model1 = new LinearRegressor();
      model1.Train_QR_Solve(trainX, trainY);
      Console.WriteLine("Done ");
      Console.WriteLine("\nCoefficients/weights: ");
      for (int i = 0; i "lt" model1.weights.Length; ++i)
        Console.Write(model1.weights[i].
          ToString("F4") + "  ");
      Console.WriteLine("\nBias/constant: " +
        model1.bias.ToString("F4"));

      // 2. MP pseudo-inverse training
      Console.WriteLine("\n2. Moore-Penrose pinv via" +
        " QR training ");
      LinearRegressor model2 = new LinearRegressor();
      model2.Train_MP_Pinv(trainX, trainY);
      Console.WriteLine("Done ");
      Console.WriteLine("\nCoefficients/weights: ");
      for (int i = 0; i "lt" model2.weights.Length; ++i)
        Console.Write(model2.weights[i].
          ToString("F4") + "  ");
      Console.WriteLine("\nBias/constant: " +
        model2.bias.ToString("F4"));

      // 3. left pinv via normal equations (Cholesky)
      Console.WriteLine("\n3. left pseudo-inv via Cholesky");
      LinearRegressor model3 = new LinearRegressor();
      model3.Train_Left_Pinv(trainX, trainY);
      Console.WriteLine("Done ");
      Console.WriteLine("\nCoefficients/weights: ");
      for (int i = 0; i "lt" model3.weights.Length; ++i)
        Console.Write(model3.weights[i].
          ToString("F4") + "  ");
      Console.WriteLine("\nBias/constant: " +
        model3.bias.ToString("F4"));

      Console.WriteLine("\nEnd demo ");
      Console.ReadLine();

    } // Main

    // helpers for Main()
    // MatLoad(), MatToVec(), VecShow()

    static double[][] MatLoad(string fn, int[] usecols,
      char sep, string comment)
    {
      List"lt"double[]"gt" result =
        new List"lt"double[]"gt"();
      string line = "";
      FileStream ifs = new FileStream(fn, FileMode.Open);
      StreamReader sr = new StreamReader(ifs);
      while ((line = sr.ReadLine()) != null)
      {
        if (line.StartsWith(comment) == true)
          continue;
        string[] tokens = line.Split(sep);
        List"lt"double"gt" lst = new List"lt"double"gt"();
        for (int j = 0; j "lt" usecols.Length; ++j)
          lst.Add(double.Parse(tokens[usecols[j]]));
        double[] row = lst.ToArray();
        result.Add(row);
      }
      sr.Close(); ifs.Close();
      return result.ToArray();
    }

    static double[] MatToVec(double[][] mat)
    {
      int nRows = mat.Length;
      int nCols = mat[0].Length;
      double[] result = new double[nRows * nCols];
      int k = 0;
      for (int i = 0; i "lt" nRows; ++i)
        for (int j = 0; j "lt" nCols; ++j)
          result[k++] = mat[i][j];
      return result;
    }

    static void VecShow(double[] vec, int dec, int wid)
    {
      for (int i = 0; i "lt" vec.Length; ++i)
        Console.Write(vec[i].ToString("F" + dec).
          PadLeft(wid));
      Console.WriteLine("");
    }

  } // class Program

  // ========================================================

  public class LinearRegressor
  {
    public double[] weights;
    public double bias;
    private Random rnd;  // not used in most closed-form

    // ------------------------------------------------------

    public LinearRegressor(int seed = 0)  // ctor
    {
      this.weights = new double[0];
      this.bias = 0;
      this.rnd = new Random(seed); // not used this version
    }

    // ------------------------------------------------------

    public double Predict(double[] x)
    {
      double result = 0.0;
      for (int j = 0; j "lt" x.Length; ++j)
        result += x[j] * this.weights[j];
      result += this.bias;
      return result;
    }

    // ------------------------------------------------------

    public void Train_QR_Solve(double[][] trainX,
      double[] trainY)
    {
      // w = Solve(R, Qt * y)
      int dim = trainX[0].Length;
      this.weights = new double[dim];
      double[][] X = MatToDesign(trainX);

      double[][] Q; double[][] R;
      QRHouseholder.MatDecompQR(X, out Q, out R);
      double[][] Qt = QRHouseholder.MatTranspose(Q);
      double[] biasAndWts = MatSolveQR(R, Qt, trainY);
      this.bias = biasAndWts[0];
      for (int i = 1; i "lt" biasAndWts.Length; ++i)
        this.weights[i - 1] = biasAndWts[i];
    }

    private static double[] MatSolveQR(double[][] R,
      double[][] Qt, double[] y)
    {
      double[] z = MatVecProd(Qt, y); // Qt * y

      int n = R[0].Length;
      double[] w = new double[n];
      // back-substitution
      for (int i = n - 1; i "gte" 0; --i)
      {
        double sum = z[i];
        for (int j = i + 1; j "lt" n; ++j)
        {
          sum -= R[i][j] * w[j];
        }
        w[i] = sum / R[i][i];
      }
      return w;
    }

    // ------------------------------------------------------

    public void Train_MP_Pinv(double[][] trainX,
       double[] trainY)
    {
      // w = inv(R) * Qt * y
      int dim = trainX[0].Length;
      this.weights = new double[dim];
      double[][] X = MatToDesign(trainX);

      double[][] Q; double[][] R;
      QRHouseholder.MatDecompQR(X, out Q, out R);
      double[][] Ri = QRHouseholder.MatInvUpperTri(R);
      double[][] Qt = QRHouseholder.MatTranspose(Q);
      double[][] RiQt = QRHouseholder.MatProduct(Ri, Qt);
      double[] biasAndWts = MatVecProd(RiQt, trainY);
      this.bias = biasAndWts[0];
      for (int i = 1; i "lt" biasAndWts.Length; ++i)
        this.weights[i - 1] = biasAndWts[i];
    }

    // ------------------------------------------------------

    public void Train_Left_Pinv(double[][] trainX,
      double[] trainY)
    {
      // w = inv(Xt * X) * Xt * y
      int dim = trainX[0].Length;
      this.weights = new double[dim];
      double[][] X = MatToDesign(trainX);

      double[][] Xt = Cholesky.MatTranspose(X);
      double[][] XtX = Cholesky.MatProduct(Xt, X);
      double[][] XtXinv = Cholesky.MatInvCholesky(XtX);
      double[][] tmp = Cholesky.MatProduct(XtXinv, Xt);

      double[] biasAndWts = MatVecProd(tmp, trainY);
      // extract bias and weights
      this.bias = biasAndWts[0];
      for (int i = 1; i "lt" biasAndWts.Length; ++i)
        this.weights[i - 1] = biasAndWts[i];
    }

    // ------------------------------------------------------

    private static double[] MatVecProd(double[][] M,
      double[] v)
    {
      // return a regular vector
      int nRows = M.Length;
      int nCols = M[0].Length;
      int n = v.Length;
      if (nCols != n)
        throw new Exception("non-conform in MatVecProd");

      double[] result = new double[nRows];
      for (int i = 0; i "lt" nRows; ++i)
        for (int k = 0; k "lt" nCols; ++k)
          result[i] += M[i][k] * v[k];

      return result;
    }

    // ------------------------------------------------------

    private static double[][] MatToDesign(double[][] M)
    {
      // add a column of 1s
      int nRows = M.Length;
      int nCols = M[0].Length;
      double[][] result = new double[nRows][];
      for (int i = 0; i "lt" nRows; ++i)
        result[i] = new double[nCols + 1];

      for (int i = 0; i "lt" nRows; ++i)
      {
        result[i][0] = 1.0;
        for (int j = 1; j "lt" nCols + 1; ++j)
          result[i][j] = M[i][j - 1];
      }
      return result;
    }

  } // class LinearRegressor

  // ========================================================

  public class QRHouseholder
  {
    // container for MP pseudo-inverse via QR-Householder
    // A = Q * R
    // pinv(A) = inv(R) * inv(Q)  note order matters
    //         = inv upper tri (easy) * transpose (easy)

    public static double[][] MatPinv(double[][] M)
    {
      double[][] Q; double[][] R;
      MatDecompQR(M, out Q, out R);  // Householder
      double[][] Ri = MatInvUpperTri(R);
      double[][] Qi = MatTranspose(Q);
      double[][] result = MatProduct(Ri, Qi);
      return result;
    }

    // ------------------------------------------------------

    public static double[][] MatInvUpperTri(double[][] U)
    {
      int n = U.Length;  // must be square matrix

      double[][] result = MatMake(n, n);
      for (int i = 0; i "lt" n; ++i)
        result[i][i] = 1.0;
      for (int k = 0; k "lt" n; ++k)
      {
        for (int j = 0; j "lt" n; ++j)
        {
          for (int i = 0; i "lt" k; ++i)
          {
            result[j][k] -= result[j][i] * U[i][k];
          }
          result[j][k] /= U[k][k];
        }
      }
      return result;
    }

    // ------------------------------------------------------

    public static double[][] MatMake(int nRows, int nCols)
    {
      double[][] result = new double[nRows][];
      for (int i = 0; i "lt" nRows; ++i)
        result[i] = new double[nCols];
      return result;
    }

    // ------------------------------------------------------

    public static double[][] MatTranspose(double[][] M)
    {
      int nRows = M.Length;
      int nCols = M[0].Length;
      double[][] result = MatMake(nCols, nRows);
      for (int i = 0; i "lt" nRows; ++i)
        for (int j = 0; j "lt" nCols; ++j)
          result[j][i] = M[i][j];
      return result;
    }

    // ------------------------------------------------------

    public static double[][] MatProduct(double[][] A,
      double[][] B)
    {
      int aRows = A.Length; int aCols = A[0].Length;
      int bRows = B.Length; int bCols = B[0].Length;
      if (aCols != bRows)
        throw new Exception("Non-conformable matrices");

      double[][] result = new double[aRows][];
      for (int i = 0; i "lt" aRows; ++i)
        result[i] = new double[bCols];

      for (int i = 0; i "lt" aRows; ++i) // each row of A
        for (int j = 0; j "lt" bCols; ++j) // each col of B
          for (int k = 0; k "lt" aCols; ++k)
            result[i][j] += A[i][k] * B[k][j];

      return result;
    }

    // ------------------------------------------------------

    public static void MatDecompQR(double[][] A,
      out double[][] Q,  out double[][] R)
    {
      int m = A.Length; int n = A[0].Length;
      if (m "lt" n)
        Console.WriteLine("FATAL: nRows must be gte nCols");

      double[][] QQ = MatMake(m, m); // working full Q
      for (int i = 0; i "lt" m; ++i)
        QQ[i][i] = 1.0;  // identity matrix

      double[][] RR = MatMake(m, n);
      for (int i = 0; i "lt" m; ++i)
        for (int j = 0; j "lt" n; ++j)
          RR[i][j] = A[i][j]; // copy of A is working R

      int k = Math.Min(m, n);  // or just use n
      for (int j = 0; j "lt" k; ++j) // main processing loop
      {
        int xn = m - j;
        double[] x = new double[xn];
        for (int i = 0; i "lt" xn; ++i)
          x[i] = RR[j + i][j];

        double ss = 0.0;
        for (int i = 0; i "lt" xn; ++i)
          ss += x[i] * x[i];
        double normX = Math.Sqrt(ss);

        // if (normX == 0.0) continue;
        if (Math.Abs(normX) "lt" 1.0e-12) continue;

        double sign;
        if (x[0] "gte" 0.0) sign = -1.0;
        else sign = 1.0; // counter-intuitive

        double[] u = new double[xn];
        for (int i = 0; i "lt" xn; ++i)
          u[i] = x[i] / (x[0] - sign * normX); // check div 0
        u[0] = 1.0;

        // compute scaling factor tau = 2 / (u^T * u)
        double tau = -sign * (x[0] - sign * normX) / normX;

        // dimensions for sub-matrices
        int nRowsSubR = m - j;   int nColsSubR = n - j;
        int nRowsSubQ = m;       int nColsSubQ = m - j;

        double[] vr = new double[nColsSubR];
        for (int c = 0; c "lt" nColsSubR; ++c)
        {
          double acc = 0.0;
          for (int r = 0; r "lt" nRowsSubR; ++r)
            acc += u[r] * RR[j + r][j + c];
          vr[c] = acc;
        }

        double[] vq = new double[nRowsSubQ];
        for (int r = 0; r "lt" nRowsSubQ; ++r)
        {
          double acc = 0.0;
          for (int c = 0; c "lt" nColsSubQ; ++c)
            acc += u[c] * QQ[r][j + c];
          vq[r] = acc;
        }

        // update sub-R
        for (int r = 0; r "lt" nRowsSubR; ++r)
          for (int c = 0; c "lt" nColsSubR; ++c)
            RR[j + r][j + c] -= tau * u[r] * vr[c];

        // update sub-Q
        for (int r = 0; r "lt" nRowsSubQ; ++r)
          for (int c = 0; c "lt" nColsSubQ; ++c)
            QQ[r][j + c] -= tau * vq[r] * u[c];

      } // j

      // extract QQ RR into out params
      Q = MatMake(m, n);
      for (int i = 0; i "lt" m; ++i)
        for (int j = 0; j "lt" n; ++j)
          Q[i][j] = QQ[i][j];

      R = MatMake(n, n);
      for (int i = 0; i "lt" n; ++i)
        for (int j = 0; j "lt" n; ++j)
          R[i][j] = RR[i][j];

      return;
    } // MatDecompQR

  } // class QRHouseholder

  // ========================================================

  public class Cholesky
  {
    // MatPseudoInv(), MatInvCholesky(),
    // MatTranspose(), MatProduct()

    public static double[][] MatPseudoInv(double[][] A)
    {
      // left pseudo-inverse via normal equations
      // nRows must be gte nCols
      // inv(At * A) * A
      double[][] At = MatTranspose(A);
      double[][] AtA = MatProduct(At, A);
      for (int i = 0; i "lt" AtA.Length; ++i)
        AtA[i][i] += 1.0e-8; /// condition before inv

      double[][] AtAinv = MatInvCholesky(AtA);
      double[][] pinv = MatProduct(AtAinv, At);
      return pinv;
    } // MatPseudoInv()

    // ------------------------------------------------------

    public static double[][] MatInvCholesky(double[][] A)
    {
      // A must be square, symmetric, positive definite
      int m = A.Length; int n = A[0].Length;  // m == n
      // 1. decompose A to L
      double[][] L = new double[n][];
      for (int i = 0; i "lt" n; ++i)
        L[i] = new double[n];

      for (int i = 0; i "lt" n; ++i)
      {
        for (int j = 0; j "lte" i; ++j)
        {
          double sum = 0.0;
          for (int k = 0; k "lt" j; ++k)
            sum += L[i][k] * L[j][k];
          if (i == j)
          {
            double tmp = A[i][i] - sum;
            if (tmp "lt" 0.0)
              throw new
                Exception("decomp Cholesky fatal");
            L[i][j] = Math.Sqrt(tmp);
          }
          else
          {
            if (L[j][j] == 0.0)
              throw new
                Exception("decomp Cholesky fatal ");
            L[i][j] = (A[i][j] - sum) / L[j][j];
          }
        } // j
      } // i

      // 2. compute inverse from L
      double[][] result = new double[n][];  // make Identity
      for (int i = 0; i "lt" n; ++i)
        result[i] = new double[n];
      for (int i = 0; i "lt" n; ++i)
        result[i][i] = 1.0;

      for (int k = 0; k "lt" n; ++k)
      {
        for (int j = 0; j "lt" n; j++)
        {
          for (int i = 0; i "lt" k; i++)
          {
            result[k][j] -= result[i][j] * L[k][i];
          }
          result[k][j] /= L[k][k];
        }
      }

      for (int k = n - 1; k "gte" 0; --k)
      {
        for (int j = 0; j "lt" n; j++)
        {
          for (int i = k + 1; i "lt" n; i++)
          {
            result[k][j] -= result[i][j] * L[i][k];
          }
          result[k][j] /= L[k][k];
        }
      }
      return result;
    } // MatInvCholesky()

    // ------------------------------------------------------

    public static double[][] MatTranspose(double[][] M)
    {
      int nr = M.Length; int nc = M[0].Length;
      double[][] result = new double[nc][]; // note
      for (int i = 0; i "lt" nc; ++i)
        result[i] = new double[nr];
      for (int i = 0; i "lt" nr; ++i)
        for (int j = 0; j "lt" nc; ++j)
          result[j][i] = M[i][j]; // note
      return result;
    }

    // ````````````````````````````````````````````````````

    public static double[][] MatProduct(double[][] A,
      double[][] B)
    {
      int aRows = A.Length; int aCols = A[0].Length;
      int bRows = B.Length; int bCols = B[0].Length;
      if (aCols != bRows)
        throw new Exception("Non-conformable matrices");

      double[][] result = new double[aRows][];
      for (int i = 0; i "lt" aRows; ++i)
        result[i] = new double[bCols];

      for (int i = 0; i "lt" aRows; ++i) // each row of A
        for (int j = 0; j "lt" bCols; ++j) // each col of B
          for (int k = 0; k "lt" aCols; ++k)
            result[i][j] += A[i][k] * B[k][j];
      return result;
    }

    // ------------------------------------------------------

  } // class Cholesky

} // ns

Training data:

# synthetic_train_200.txt
#
-0.1660,  0.4406, -0.9998, -0.3953, -0.7065,  0.4840
 0.0776, -0.1616,  0.3704, -0.5911,  0.7562,  0.1568
-0.9452,  0.3409, -0.1654,  0.1174, -0.7192,  0.8054
 0.9365, -0.3732,  0.3846,  0.7528,  0.7892,  0.1345
-0.8299, -0.9219, -0.6603,  0.7563, -0.8033,  0.7955
 0.0663,  0.3838, -0.3690,  0.3730,  0.6693,  0.3206
-0.9634,  0.5003,  0.9777,  0.4963, -0.4391,  0.7377
-0.1042,  0.8172, -0.4128, -0.4244, -0.7399,  0.4801
-0.9613,  0.3577, -0.5767, -0.4689, -0.0169,  0.6861
-0.7065,  0.1786,  0.3995, -0.7953, -0.1719,  0.5569
 0.3888, -0.1716, -0.9001,  0.0718,  0.3276,  0.2500
 0.1731,  0.8068, -0.7251, -0.7214,  0.6148,  0.3297
-0.2046, -0.6693,  0.8550, -0.3045,  0.5016,  0.2129
 0.2473,  0.5019, -0.3022, -0.4601,  0.7918,  0.2613
-0.1438,  0.9297,  0.3269,  0.2434, -0.7705,  0.5171
 0.1568, -0.1837, -0.5259,  0.8068,  0.1474,  0.3307
-0.9943,  0.2343, -0.3467,  0.0541,  0.7719,  0.5581
 0.2467, -0.9684,  0.8589,  0.3818,  0.9946,  0.1092
-0.6553, -0.7257,  0.8652,  0.3936, -0.8680,  0.7018
 0.8460,  0.4230, -0.7515, -0.9602, -0.9476,  0.1996
-0.9434, -0.5076,  0.7201,  0.0777,  0.1056,  0.5664
 0.9392,  0.1221, -0.9627,  0.6013, -0.5341,  0.1533
 0.6142, -0.2243,  0.7271,  0.4942,  0.1125,  0.1661
 0.4260,  0.1194, -0.9749, -0.8561,  0.9346,  0.2230
 0.1362, -0.5934, -0.4953,  0.4877, -0.6091,  0.3810
 0.6937, -0.5203, -0.0125,  0.2399,  0.6580,  0.1460
-0.6864, -0.9628, -0.8600, -0.0273,  0.2127,  0.5387
 0.9772,  0.1595, -0.2397,  0.1019,  0.4907,  0.1611
 0.3385, -0.4702, -0.8673, -0.2598,  0.2594,  0.2270
-0.8669, -0.4794,  0.6095, -0.6131,  0.2789,  0.4700
 0.0493,  0.8496, -0.4734, -0.8681,  0.4701,  0.3516
 0.8639, -0.9721, -0.5313,  0.2336,  0.8980,  0.1412
 0.9004,  0.1133,  0.8312,  0.2831, -0.2200,  0.1782
 0.0991,  0.8524,  0.8375, -0.2102,  0.9265,  0.2150
-0.6521, -0.7473, -0.7298,  0.0113, -0.9570,  0.7422
 0.6190, -0.3105,  0.8802,  0.1640,  0.7577,  0.1056
 0.6895,  0.8108, -0.0802,  0.0927,  0.5972,  0.2214
 0.1982, -0.9689,  0.1870, -0.1326,  0.6147,  0.1310
-0.3695,  0.7858,  0.1557, -0.6320,  0.5759,  0.3773
-0.1596,  0.3581,  0.8372, -0.9992,  0.9535,  0.2071
-0.2468,  0.9476,  0.2094,  0.6577,  0.1494,  0.4132
 0.1737,  0.5000,  0.7166,  0.5102,  0.3961,  0.2611
 0.7290, -0.3546,  0.3416, -0.0983, -0.2358,  0.1332
-0.3652,  0.2438, -0.1395,  0.9476,  0.3556,  0.4170
-0.6029, -0.1466, -0.3133,  0.5953,  0.7600,  0.4334
-0.4596, -0.4953,  0.7098,  0.0554,  0.6043,  0.2775
 0.1450,  0.4663,  0.0380,  0.5418,  0.1377,  0.2931
-0.8636, -0.2442, -0.8407,  0.9656, -0.6368,  0.7429
 0.6237,  0.7499,  0.3768,  0.1390, -0.6781,  0.2185
-0.5499,  0.1850, -0.3755,  0.8326,  0.8193,  0.4399
-0.4858, -0.7782, -0.6141, -0.0008,  0.4572,  0.4197
 0.7033, -0.1683,  0.2334, -0.5327, -0.7961,  0.1776
 0.0317, -0.0457, -0.6947,  0.2436,  0.0880,  0.3345
 0.5031, -0.5559,  0.0387,  0.5706, -0.9553,  0.3107
-0.3513,  0.7458,  0.6894,  0.0769,  0.7332,  0.3170
 0.2205,  0.5992, -0.9309,  0.5405,  0.4635,  0.3532
-0.4806, -0.4859,  0.2646, -0.3094,  0.5932,  0.3202
 0.9809, -0.3995, -0.7140,  0.8026,  0.0831,  0.1600
 0.9495,  0.2732,  0.9878,  0.0921,  0.0529,  0.1289
-0.9476, -0.6792,  0.4913, -0.9392, -0.2669,  0.5966
 0.7247,  0.3854,  0.3819, -0.6227, -0.1162,  0.1550
-0.5922, -0.5045, -0.4757,  0.5003, -0.0860,  0.5863
-0.8861,  0.0170, -0.5761,  0.5972, -0.4053,  0.7301
 0.6877, -0.2380,  0.4997,  0.0223,  0.0819,  0.1404
 0.9189,  0.6079, -0.9354,  0.4188, -0.0700,  0.1907
-0.1428, -0.7820,  0.2676,  0.6059,  0.3936,  0.2790
 0.5324, -0.3151,  0.6917, -0.1425,  0.6480,  0.1071
-0.8432, -0.9633, -0.8666, -0.0828, -0.7733,  0.7784
-0.9444,  0.5097, -0.2103,  0.4939, -0.0952,  0.6787
-0.0520,  0.6063, -0.1952,  0.8094, -0.9259,  0.4836
 0.5477, -0.7487,  0.2370, -0.9793,  0.0773,  0.1241
 0.2450,  0.8116,  0.9799,  0.4222,  0.4636,  0.2355
 0.8186, -0.1983, -0.5003, -0.6531, -0.7611,  0.1511
-0.4714,  0.6382, -0.3788,  0.9648, -0.4667,  0.5950
 0.0673, -0.3711,  0.8215, -0.2669, -0.1328,  0.2677
-0.9381,  0.4338,  0.7820, -0.9454,  0.0441,  0.5518
-0.3480,  0.7190,  0.1170,  0.3805, -0.0943,  0.4724
-0.9813,  0.1535, -0.3771,  0.0345,  0.8328,  0.5438
-0.1471, -0.5052, -0.2574,  0.8637,  0.8737,  0.3042
-0.5454, -0.3712, -0.6505,  0.2142, -0.1728,  0.5783
 0.6327, -0.6297,  0.4038, -0.5193,  0.1484,  0.1153
-0.5424,  0.3282, -0.0055,  0.0380, -0.6506,  0.6613
 0.1414,  0.9935,  0.6337,  0.1887,  0.9520,  0.2540
-0.9351, -0.8128, -0.8693, -0.0965, -0.2491,  0.7353
 0.9507, -0.6640,  0.9456,  0.5349,  0.6485,  0.1059
-0.0462, -0.9737, -0.2940, -0.0159,  0.4602,  0.2606
-0.0627, -0.0852, -0.7247, -0.9782,  0.5166,  0.2977
 0.0478,  0.5098, -0.0723, -0.7504, -0.3750,  0.3335
 0.0090,  0.3477,  0.5403, -0.7393, -0.9542,  0.4415
-0.9748,  0.3449,  0.3736, -0.1015,  0.8296,  0.4358
 0.2887, -0.9895, -0.0311,  0.7186,  0.6608,  0.2057
 0.1570, -0.4518,  0.1211,  0.3435, -0.2951,  0.3244
 0.7117, -0.6099,  0.4946, -0.4208,  0.5476,  0.1096
-0.2929, -0.5726,  0.5346, -0.3827,  0.4665,  0.2465
 0.4889, -0.5572, -0.5718, -0.6021, -0.7150,  0.2163
-0.7782,  0.3491,  0.5996, -0.8389, -0.5366,  0.6516
-0.5847,  0.8347,  0.4226,  0.1078, -0.3910,  0.6134
 0.8469,  0.4121, -0.0439, -0.7476,  0.9521,  0.1571
-0.6803, -0.5948, -0.1376, -0.1916, -0.7065,  0.7156
 0.2878,  0.5086, -0.5785,  0.2019,  0.4979,  0.2980
 0.2764,  0.1943, -0.4090,  0.4632,  0.8906,  0.2960
-0.8877,  0.6705, -0.6155, -0.2098, -0.3998,  0.7107
-0.8398,  0.8093, -0.2597,  0.0614, -0.0118,  0.6502
-0.8476,  0.0158, -0.4769, -0.2859, -0.7839,  0.7715
 0.5751, -0.7868,  0.9714, -0.6457,  0.1448,  0.1175
 0.4802, -0.7001,  0.1022, -0.5668,  0.5184,  0.1090
 0.4458, -0.6469,  0.7239, -0.9604,  0.7205,  0.0779
 0.5175,  0.4339,  0.9747, -0.4438, -0.9924,  0.2879
 0.8678,  0.7158,  0.4577,  0.0334,  0.4139,  0.1678
 0.5406,  0.5012,  0.2264, -0.1963,  0.3946,  0.2088
-0.9938,  0.5498,  0.7928, -0.5214, -0.7585,  0.7687
 0.7661,  0.0863, -0.4266, -0.7233, -0.4197,  0.1466
 0.2277, -0.3517, -0.0853, -0.1118,  0.6563,  0.1767
 0.3499, -0.5570, -0.0655, -0.3705,  0.2537,  0.1632
 0.7547, -0.1046,  0.5689, -0.0861,  0.3125,  0.1257
 0.8186,  0.2110,  0.5335,  0.0094, -0.0039,  0.1391
 0.6858, -0.8644,  0.1465,  0.8855,  0.0357,  0.1845
-0.4967,  0.4015,  0.0805,  0.8977,  0.2487,  0.4663
 0.6760, -0.9841,  0.9787, -0.8446, -0.3557,  0.1509
-0.1203, -0.4885,  0.6054, -0.0443, -0.7313,  0.4854
 0.8557,  0.7919, -0.0169,  0.7134, -0.1628,  0.2002
 0.0115, -0.6209,  0.9300, -0.4116, -0.7931,  0.4052
-0.7114, -0.9718,  0.4319,  0.1290,  0.5892,  0.3661
 0.3915,  0.5557, -0.1870,  0.2955, -0.6404,  0.2954
-0.3564, -0.6548, -0.1827, -0.5172, -0.1862,  0.4622
 0.2392, -0.4959,  0.5857, -0.1341, -0.2850,  0.2470
-0.3394,  0.3947, -0.4627,  0.6166, -0.4094,  0.5325
 0.7107,  0.7768, -0.6312,  0.1707,  0.7964,  0.2757
-0.1078,  0.8437, -0.4420,  0.2177,  0.3649,  0.4028
-0.3139,  0.5595, -0.6505, -0.3161, -0.7108,  0.5546
 0.4335,  0.3986,  0.3770, -0.4932,  0.3847,  0.1810
-0.2562, -0.2894, -0.8847,  0.2633,  0.4146,  0.4036
 0.2272,  0.2966, -0.6601, -0.7011,  0.0284,  0.2778
-0.0743, -0.1421, -0.0054, -0.6770, -0.3151,  0.3597
-0.4762,  0.6891,  0.6007, -0.1467,  0.2140,  0.4266
-0.4061,  0.7193,  0.3432,  0.2669, -0.7505,  0.6147
-0.0588,  0.9731,  0.8966,  0.2902, -0.6966,  0.4955
-0.0627, -0.1439,  0.1985,  0.6999,  0.5022,  0.3077
 0.1587,  0.8494, -0.8705,  0.9827, -0.8940,  0.4263
-0.7850,  0.2473, -0.9040, -0.4308, -0.8779,  0.7199
 0.4070,  0.3369, -0.2428, -0.6236,  0.4940,  0.2215
-0.0242,  0.0513, -0.9430,  0.2885, -0.2987,  0.3947
-0.5416, -0.1322, -0.2351, -0.0604,  0.9590,  0.3683
 0.1055,  0.7783, -0.2901, -0.5090,  0.8220,  0.2984
-0.9129,  0.9015,  0.1128, -0.2473,  0.9901,  0.4776
-0.9378,  0.1424, -0.6391,  0.2619,  0.9618,  0.5368
 0.7498, -0.0963,  0.4169,  0.5549, -0.0103,  0.1614
-0.2612, -0.7156,  0.4538, -0.0460, -0.1022,  0.3717
 0.7720,  0.0552, -0.1818, -0.4622, -0.8560,  0.1685
-0.4177,  0.0070,  0.9319, -0.7812,  0.3461,  0.3052
-0.0001,  0.5542, -0.7128, -0.8336, -0.2016,  0.3803
 0.5356, -0.4194, -0.5662, -0.9666, -0.2027,  0.1776
-0.2378,  0.3187, -0.8582, -0.6948, -0.9668,  0.5474
-0.1947, -0.3579,  0.1158,  0.9869,  0.6690,  0.2992
 0.3992,  0.8365, -0.9205, -0.8593, -0.0520,  0.3154
-0.0209,  0.0793,  0.7905, -0.1067,  0.7541,  0.1864
-0.4928, -0.4524, -0.3433,  0.0951, -0.5597,  0.6261
-0.8118,  0.7404, -0.5263, -0.2280,  0.1431,  0.6349
 0.0516, -0.8480,  0.7483,  0.9023,  0.6250,  0.1959
-0.3212,  0.1093,  0.9488, -0.3766,  0.3376,  0.2735
-0.3481,  0.5490, -0.3484,  0.7797,  0.5034,  0.4379
-0.5785, -0.9170, -0.3563, -0.9258,  0.3877,  0.4121
 0.3407, -0.1391,  0.5356,  0.0720, -0.9203,  0.3458
-0.3287, -0.8954,  0.2102,  0.0241,  0.2349,  0.3247
-0.1353,  0.6954, -0.0919, -0.9692,  0.7461,  0.3338
 0.9036, -0.8982, -0.5299, -0.8733, -0.1567,  0.1187
 0.7277, -0.8368, -0.0538, -0.7489,  0.5458,  0.0830
 0.9049,  0.8878,  0.2279,  0.9470, -0.3103,  0.2194
 0.7957, -0.1308, -0.5284,  0.8817,  0.3684,  0.2172
 0.4647, -0.4931,  0.2010,  0.6292, -0.8918,  0.3371
-0.7390,  0.6849,  0.2367,  0.0626, -0.5034,  0.7039
-0.1567, -0.8711,  0.7940, -0.5932,  0.6525,  0.1710
 0.7635, -0.0265,  0.1969,  0.0545,  0.2496,  0.1445
 0.7675,  0.1354, -0.7698, -0.5460,  0.1920,  0.1728
-0.5211, -0.7372, -0.6763,  0.6897,  0.2044,  0.5217
 0.1913,  0.1980,  0.2314, -0.8816,  0.5006,  0.1998
 0.8964,  0.0694, -0.6149,  0.5059, -0.9854,  0.1825
 0.1767,  0.7104,  0.2093,  0.6452,  0.7590,  0.2832
-0.3580, -0.7541,  0.4426, -0.1193, -0.7465,  0.5657
-0.5996,  0.5766, -0.9758, -0.3933, -0.9572,  0.6800
 0.9950,  0.1641, -0.4132,  0.8579,  0.0142,  0.2003
-0.4717, -0.3894, -0.2567, -0.5111,  0.1691,  0.4266
 0.3917, -0.8561,  0.9422,  0.5061,  0.6123,  0.1212
-0.0366, -0.1087,  0.3449, -0.1025,  0.4086,  0.2475
 0.3633,  0.3943,  0.2372, -0.6980,  0.5216,  0.1925
-0.5325, -0.6466, -0.2178, -0.3589,  0.6310,  0.3568
 0.2271,  0.5200, -0.1447, -0.8011, -0.7699,  0.3128
 0.6415,  0.1993,  0.3777, -0.0178, -0.8237,  0.2181
-0.5298, -0.0768, -0.6028, -0.9490,  0.4588,  0.4356
 0.6870, -0.1431,  0.7294,  0.3141,  0.1621,  0.1632
-0.5985,  0.0591,  0.7889, -0.3900,  0.7419,  0.2945
 0.3661,  0.7984, -0.8486,  0.7572, -0.6183,  0.3449
 0.6995,  0.3342, -0.3113, -0.6972,  0.2707,  0.1712
 0.2565,  0.9126,  0.1798, -0.6043, -0.1413,  0.2893
-0.3265,  0.9839, -0.2395,  0.9854,  0.0376,  0.4770
 0.2690, -0.1722,  0.9818,  0.8599, -0.7015,  0.3954
-0.2102, -0.0768,  0.1219,  0.5607, -0.0256,  0.3949
 0.8216, -0.9555,  0.6422, -0.6231,  0.3715,  0.0801
-0.2896,  0.9484, -0.7545, -0.6249,  0.7789,  0.4370
-0.9985, -0.5448, -0.7092, -0.5931,  0.7926,  0.5402

The goal of a machine learning regression problem is to predict a single numeric value. For example, a bank might to predict the maximum safe loan amount to a customer based on customer age, current savings balance, and so on.

There are roughly a dozen major regression techniques, and each technique has several variations. Common techniques are linear regression, linear ridge regression, gradient boosting decision tree regression, and neural network regression. Each technique has pros and cons.

I use the non-standard term bistratum (“two layers”, borrowed from biology) to indicate a neural network with exactly two hidden layers.

I put together a demo using C#. I used one of my standard synthetic datasets. The data looks like:

-0.1660,  0.4406, -0.9998, -0.3953, -0.7065,  0.4840
 0.0776, -0.1616,  0.3704, -0.5911,  0.7562,  0.1568
-0.9452,  0.3409, -0.1654,  0.1174, -0.7192,  0.8054
. . .

The first four fields on each line are predictors (often called features). The last value is the target to predict. There are 200 training items and 40 test items.

The output of the demo program is:

Neural network bistratum regression using C#

Loading synthetic train (200) and test (40) data
Done

First three train X:
 -0.1660  0.4406 -0.9998 -0.3953 -0.7065
  0.0776 -0.1616  0.3704 -0.5911  0.7562
 -0.9452  0.3409 -0.1654  0.1174 -0.7192

First three train y:
  0.4840
  0.1568
  0.8054

Creating 5-(10-10)-1 tanh() identity() neural
 network regressor

Setting lrnRate = 0.0600
Setting maxEpochs = 30000
Setting decay = 0.00000100

Starting training
epoch:      0  MSE = 0.0354  acc = 0.0600
epoch:   6000  MSE = 0.0001  acc = 0.8100
epoch:  12000  MSE = 0.0001  acc = 0.7900
epoch:  18000  MSE = 0.0001  acc = 0.8100
epoch:  24000  MSE = 0.0001  acc = 0.8000
Done

Evaluating model

Accuracy (5%) on train data = 0.8100
Accuracy (5%) on test data  = 0.8000

MSE on train data = 0.0001
MSE on test data = 0.0002

Predicting y for train[0]
Predicted y = 0.4870

End demo

The demo program creates a 5-(10-10)-1 tanh() identity() neural network regression model. This means there are 5 input nodes, two hidden layers with 10 nodes each, and 1 output node. The hidden nodes uses tanh() activation, and the output node uses identity() activation.

The demo program trains the bistratum network using plain vanilla online (aka batch-1) stochastic gradient descent.

The lrnRate (learning rate) influences how quicky the model weights and biases are updated. The maxEpochs controls how many passes through the training data occur. The decay is a weight decay that discourages model weights from becoming extrememly large. When used with SGD, weight decay is mathematically equivalent to L2 regularization.

The model prediction accuracy on the training data is 81% (162 out of 200 correct), and 80% on the test data (32 out of 40 correct). A prediction is scored correct if it is withing 5% of the true target value.

I’m a big fan of 1950s science fiction movies. One of my favorite scenes in many of these old movies is “the monster in the window”.

Right: In “Tarantula” (1955), a biologist in a remote desert lab experiments with ways to grow animals to giant size. What could possibly . . . OK, how about a 50-foot hungry tarantula spider?

Demo program. Replace “lt” (less than), “gt”, “lte”, “gte” with Boolean operator symbols. (My blog editor often chokes on symbols).

using System;
using System.IO;
using System.Collections.Generic;

namespace NeuralNetworkBistratumRegression
{
  internal class NeuralNetworkBistratumRegressionProgram
  {
    static void Main(string[] args)
    {
      Console.WriteLine("\nNeural network bistratum " +
        "regression using C# ");

      // 1. load data
      Console.WriteLine("\nLoading synthetic train (200)" +
        " and test (40) data ");
      string trainFile =
        "..\\..\\..\\Data\\synthetic_train_200.txt";
      int[] colsX = new int[] { 0, 1, 2, 3, 4 };
      int colY = 5;
      double[][] trainX =
        MatLoad(trainFile, colsX, ',', "#");
      double[] trainY = MatToVec(MatLoad(trainFile,
        new int[] { colY }, ',', "#"));

      string testFile =
        "..\\..\\..\\Data\\synthetic_test_40.txt";
      double[][] testX = MatLoad(testFile, colsX, ',', "#");
      double[] testY = MatToVec(MatLoad(testFile,
        new int[] { colY }, ',', "#"));
      Console.WriteLine("Done ");

      Console.WriteLine("\nFirst three train X: ");
      for (int i = 0; i "lt" 3; ++i)
        VecShow(trainX[i], 4, 8);

      Console.WriteLine("\nFirst three train y: ");
      for (int i = 0; i "lt" 3; ++i)
        Console.WriteLine(trainY[i].ToString("F4").
          PadLeft(8));

      // 2. create NN
      Console.WriteLine("\nCreating 5-(10-10)-1 tanh()" +
        " identity() neural network regressor ");
      NeuralNetworkBistratumRegressor nn =
         new NeuralNetworkBistratumRegressor(5, 10, 10, 1);

      // 3. train NN
      double lrnRate = 0.06;
      int maxEpochs = 30_000;
      double decay = 0.000001; // .81  .80  .0001 .0002

      Console.WriteLine("\nSetting lrnRate = " +
        lrnRate.ToString("F4"));
      Console.WriteLine("Setting maxEpochs = " +
        maxEpochs);
      Console.WriteLine("Setting decay = " +
        decay.ToString("F8"));
      Console.WriteLine("\nStarting training ");
      nn.Train(trainX, trainY, lrnRate, maxEpochs, decay);
      Console.WriteLine("Done ");

      // TODO: programmatically analyze weights and
      // biases for extreme values

      // 4. evaluate trained model
      Console.WriteLine("\nEvaluating model ");
      double trainAcc = nn.Accuracy(trainX, trainY, 0.05);
      double testAcc = nn.Accuracy(testX, testY, 0.05);
      Console.WriteLine("\nAccuracy (5%) on train data = " +
        trainAcc.ToString("F4"));
      Console.WriteLine("Accuracy (5%) on test data  = " +
        testAcc.ToString("F4"));

      double trainMSE = nn.MSE(trainX, trainY);
      double testMSE = nn.MSE(testX, testY);
      Console.WriteLine("\nMSE on train data = " +
        trainMSE.ToString("F4"));
      Console.WriteLine("MSE on test data = " +
        testMSE.ToString("F4"));

      // 5. use model
      Console.WriteLine("\nPredicting y for train[0] ");
      double[] x = trainX[0];
      double predY = nn.Predict(x);
      Console.WriteLine("Predicted y = " +
        predY.ToString("F4"));

      Console.WriteLine("\nEnd demo ");
      Console.ReadLine();

    } // Main

    // ------------------------------------------------------
    // helpers for Main(): MatLoad(), MatToVec(), VecShow()
    // ------------------------------------------------------

    static double[][] MatLoad(string fn, int[] usecols,
      char sep, string comment)
    {
      List"lt"double[]"gt" result =
        new List"lt"double[]"gt"();
      string line = "";
      FileStream ifs = new FileStream(fn, FileMode.Open);
      StreamReader sr = new StreamReader(ifs);
      while ((line = sr.ReadLine()) != null)
      {
        if (line.StartsWith(comment) == true)
          continue;
        string[] tokens = line.Split(sep);
        List"lt"double"gt" lst = new List"lt"double"gt"();
        for (int j = 0; j "lt" usecols.Length; ++j)
          lst.Add(double.Parse(tokens[usecols[j]]));
        double[] row = lst.ToArray();
        result.Add(row);
      }
      sr.Close(); ifs.Close();
      return result.ToArray();
    }

    static double[] MatToVec(double[][] M)
    {
      int nRows = M.Length;
      int nCols = M[0].Length;
      double[] result = new double[nRows * nCols];
      int k = 0;
      for (int i = 0; i "lt" nRows; ++i)
        for (int j = 0; j "lt" nCols; ++j)
          result[k++] = M[i][j];
      return result;
    }

    static void VecShow(double[] vec, int dec, int wid)
    {
      for (int i = 0; i "lt" vec.Length; ++i)
        Console.Write(vec[i].ToString("F" + dec).
          PadLeft(wid));
      Console.WriteLine("");
    }

    // ------------------------------------------------------

  } // class Program

  // ========================================================

  public class NeuralNetworkBistratumRegressor
  {
    // two hidden layers
    public int numInput;
    public int numHiddenA;
    public int numHiddenB;
    public int numOutput;

    public double[] iNodes;  // input nodes
    public double[] aNodes;
    public double[] bNodes;
    public double[] oNodes;  // output nodes

    public double[][] iaWeights; // input to hidden A
    public double[][] abWeights; // hidden A to hidden B
    public double[][] boWeights; // hidden B to output

    public double[] aBiases;
    public double[] bBiases;
    public double[] oBiases;

    private Random rnd; // wt init and train shuffle

    // ------------------------------------------------------

    public NeuralNetworkBistratumRegressor(int numInput,
      int numHiddenA, int numHiddenB, int numOutput,
      int seed = 0)
    {
      this.numInput = numInput;
      this.numHiddenA = numHiddenA;
      this.numHiddenB = numHiddenB;
      this.numOutput = numOutput; // 1 for regression

      this.iNodes = new double[numInput];
      this.iaWeights = MatMake(numInput, numHiddenA);
      this.aBiases = new double[numHiddenA];
      this.aNodes = new double[numHiddenA];

      this.abWeights = MatMake(numHiddenA, numHiddenB);
      this.bBiases = new double[numHiddenB];
      this.bNodes = new double[numHiddenB];

      this.boWeights = MatMake(numHiddenB, numOutput);
      this.oBiases = new double[numOutput];
      this.oNodes = new double[numOutput];

      this.rnd = new Random(seed);
    }

    // ------------------------------------------------------

    private static double[][] MatMake(int nRows, int nCols)
    {
      double[][] result = new double[nRows][];
      for (int i = 0; i "lt" nRows; ++i)
        result[i] = new double[nCols];
      return result;
    }

    // ------------------------------------------------------

    public double Predict(double[] x)
    {
      // copy input into iNodes
      for (int i = 0; i "lt" this.numInput; ++i)
        this.iNodes[i] = x[i];

      // compute hidden layer A node values
      for (int j = 0; j "lt" this.numHiddenA; ++j)
      {
        double sum = 0.0;
        for (int i = 0; i "lt" this.numInput; ++i)
          sum += this.iNodes[i] * this.iaWeights[i][j];
        sum += this.aBiases[j];
        this.aNodes[j] = HyperTan(sum);
      }

      // compute hidden layer B node values
      for (int j = 0; j "lt" this.numHiddenB; ++j)
      {
        double sum = 0.0;
        for (int i = 0; i "lt" this.numHiddenA; ++i)
          sum += this.aNodes[i] * this.abWeights[i][j];
        sum += this.bBiases[j];
        this.bNodes[j] = HyperTan(sum);
      }

      // compute output layer node
      for (int j = 0; j "lt" this.numOutput; ++j)
      {
        double sum = 0.0;
        for (int i = 0; i "lt" this.numHiddenB; ++i)
          sum += this.bNodes[i] * this.boWeights[i][j];
        sum += this.oBiases[j];
        this.oNodes[j] = Identity(sum);
      }

      return this.oNodes[0];  // a single value
    }

    // ------------------------------------------------------

    private static double HyperTan(double x)
    {
      if (x "lt" -6.0) return -1.0;
      else if (x "gt" 6.0) return 1.0;
      else return Math.Tanh(x);
    }

    // ------------------------------------------------------

    private static double Identity(double x)
    {
      return x;
    }

    // ------------------------------------------------------

    public void Train(double[][] trainX, double[] trainY,
      double lrnRate, int maxEpochs, double decay)
    {
      // 'online' aka batch-1 SGD training (not batch)
      // init weights, leave biases at 0
      double lo = -0.01; double hi = 0.01;

      for (int i = 0; i "lt" this.numInput; ++i)
        for (int j = 0; j "lt" this.numHiddenA; ++j)
          this.iaWeights[i][j] =
            (hi - lo) * this.rnd.NextDouble() + lo;

      for (int i = 0; i "lt" this.numHiddenA; ++i)
        for (int j = 0; j "lt" this.numHiddenB; ++j)
          this.abWeights[i][j] =
            (hi - lo) * this.rnd.NextDouble() + lo;

      for (int i = 0; i "lt" this.numHiddenB; ++i)
        for (int j = 0; j "lt" this.numOutput; ++j)
          this.boWeights[i][j] =
            (hi - lo) * this.rnd.NextDouble() + lo;

      // each weight and bias has a gradient
      double[][] boGrads = MatMake(this.numHiddenB, this.numOutput);
      double[][] abGrads = MatMake(this.numHiddenA, this.numHiddenB);
      double[][] iaGrads = MatMake(this.numInput, this.numHiddenA);

      double[] oBiasGrads = new double[this.numOutput];
      double[] bBiasGrads = new double[this.numHiddenB];
      double[] aBiasGrads = new double[this.numHiddenA];

      // each output and hidden node has a 'signal'
      //  which is gradient without associated input
      //  (lower case delta in Wikipedia)
      double[] oSignals = new double[this.numOutput];
      double[] bSignals = new double[this.numHiddenB];
      double[] aSignals = new double[this.numHiddenA];

      // to shuffle order of items when training
      int[] indices = new int[trainX.Length];
      for (int i = 0; i "lt" indices.Length; ++i)
        indices[i] = i;

      int freq = (int)(maxEpochs / 5); // progress 5 times
      for (int epoch = 0; epoch "lt" maxEpochs; ++epoch)
      {
        this.Shuffle(indices); // process in scrambled order
        for (int ii = 0; ii "lt" trainX.Length; ++ii)
        {
          int idx = indices[ii];
          double[] x = trainX[idx];
          double actualY = trainY[idx];
          double predY = this.Predict(x);

          // output node signals depends on target values
          for (int k = 0; k "lt" this.numOutput; ++k)
          {
            double error = predY - actualY;  // standard
            double derivative = 1.0; // identity activation
            oSignals[k] = error * derivative;
          }

          // signal for B nodes depends on output signals
          for (int j = 0; j "lt" this.numHiddenB; ++j)
          {
            // derivative for tanh() activation
            double derivative =
              (1 + this.bNodes[j]) * (1 - this.bNodes[j]);
            double sum = 0.0;
            for (int k = 0; k "lt" this.numOutput; ++k)
              sum += oSignals[k] * this.boWeights[j][k];
            bSignals[j] = derivative * sum;
          }

          // signal for A nodes, depends on B signals
          for (int j = 0; j "lt" this.numHiddenA; ++j)
          {
            // derivative for tanh() activation
            double derivative =
              (1 + this.aNodes[j]) * (1 - this.aNodes[j]);
            double sum = 0.0;
            for (int k = 0; k "lt" this.numHiddenB; ++k)
              sum += bSignals[k] * this.abWeights[j][k];
            aSignals[j] = derivative * sum;
          }

          // at this point, all signals have been computed
          // use signals to calculate gradients left-to-right

          for (int i = 0; i "lt" this.numInput; ++i)
            for (int j = 0; j "lt" this.numHiddenA; ++j)
              iaGrads[i][j] = this.iNodes[i] * aSignals[j];

          for (int i = 0; i "lt" this.numHiddenA; ++i)
            for (int j = 0; j "lt" this.numHiddenB; ++j)
              abGrads[i][j] = this.aNodes[i] * bSignals[j];

          for (int i = 0; i "lt" this.numHiddenB; ++i)
            for (int j = 0; j "lt" this.numOutput; ++j)
              boGrads[i][j] = this.bNodes[i] * oSignals[j];

          // compute bias gradients
          for (int j = 0; j "lt" this.numHiddenA; ++j)
            aBiasGrads[j] = 1.0 * aSignals[j];
          for (int j = 0; j "lt" this.numHiddenB; ++j)
            bBiasGrads[j] = 1.0 * bSignals[j];
          for (int j = 0; j "lt" this.numOutput; ++j)
            oBiasGrads[j] = 1.0 * oSignals[j];

          // before update, decay all weights
          // wt decay is (almost) L2 regularization
          // when used with plain vanilla SGD
          for (int i = 0; i "lt" this.numInput; ++i)
            for (int j = 0; j "lt" this.numHiddenA; ++j)
              this.iaWeights[i][j] *= (1 - decay);

          for (int i = 0; i "lt" this.numHiddenA; ++i)
            for (int j = 0; j "lt" this.numHiddenB; ++j)
              this.abWeights[i][j] *= (1 - decay);

          for (int i = 0; i "lt" this.numHiddenB; ++i)
            for (int j = 0; j "lt" this.numOutput; ++j)
              this.boWeights[i][j] *= (1 - decay);

          // use gradients to update all weights

          for (int i = 0; i "lt" this.numInput; ++i)
            for (int j = 0; j "lt" this.numHiddenA; ++j)
              this.iaWeights[i][j] -= iaGrads[i][j] * lrnRate;

          for (int i = 0; i "lt" this.numHiddenA; ++i)
            for (int j = 0; j "lt" this.numHiddenB; ++j)
              this.abWeights[i][j] -= abGrads[i][j] * lrnRate;

          for (int i = 0; i "lt" this.numHiddenB; ++i)
            for (int j = 0; j "lt" this.numOutput; ++j)
              this.boWeights[i][j] -= boGrads[i][j] * lrnRate;

          // update all biases

          for (int j = 0; j "lt" this.numHiddenA; ++j)
            this.aBiases[j] -= aBiasGrads[j] * lrnRate;

          for (int j = 0; j "lt" this.numHiddenB; ++j)
            this.bBiases[j] -= bBiasGrads[j] * lrnRate;

          for (int j = 0; j "lt" this.numOutput; ++j)
            this.oBiases[j] -= oBiasGrads[j] * lrnRate;

        } // ii each train item

        // display progress
        if (epoch % freq == 0 && epoch "lt" maxEpochs)
        {
          double mse = this.MSE(trainX, trainY);
          double acc = this.Accuracy(trainX, trainY, 0.05);

          string s1 = "epoch: " +
            epoch.ToString().PadLeft(6);
          string s2 = "  MSE = " +
            mse.ToString("F4");
          string s3 = "  acc = " +
            acc.ToString("F4");
          Console.WriteLine(s1 + s2 + s3);
        }

      } // epoch

      return; // no explicit return values
    }

    // ------------------------------------------------------

    private void Shuffle(int[] indices)
    {
      // Fisher-Yates algorithm
      for (int i = 0; i "lt" indices.Length; ++i)
      {
        int r = this.rnd.Next(i, indices.Length); // note!
        int tmp = indices[r];
        indices[r] = indices[i];
        indices[i] = tmp;
      }
    }

    // ------------------------------------------------------

    public double Accuracy(double[][] dataX, double[] dataY,
      double pctClose)
    {
      // in this version, if target y is 0, only pred equal
      // exactly 0 is scored as a correct prediction
      int n = dataX.Length;
      int nCorrect = 0; int nWrong = 0;
      for (int i = 0; i "lt" n; ++i)
      {
        double predY = this.Predict(dataX[i]);
        double actualY = dataY[i];
        if (Math.Abs(predY - actualY) "lte"
          pctClose * Math.Abs(actualY))
          ++nCorrect;
        else
          ++nWrong;
      }
      return (nCorrect * 1.0) / (nCorrect + nWrong);
    }

    // ------------------------------------------------------

    public double MSE(double[][] dataX, double[] dataY)
    {
      // mean squared error
      int n = dataX.Length;
      double sum = 0.0;
      for (int i = 0; i "lt" n; ++i)
      {
        double predY = this.Predict(dataX[i]);
        double actualY = dataY[i];
        sum += (predY - actualY) * (predY - actualY);
      }
      return sum / n;
    }

    // ------------------------------------------------------

    //public double R2(double[][] dataX, double[] dataY)
    //{
    //  // coefficient of determination
    //  int n = dataX.Length;
    //  double sum = 0.0;

    //  for (int i = 0; i "lt" n; ++i) // mean of y values
    //    sum += dataY[i];
    //  double meanY = sum / n;

    //  double ssRes = 0.0; // sum squares residula
    //  double ssTot = 0.0; // sum squares total
    //  for (int i = 0; i "lt" n; ++i)
    //  {
    //    double predY = this.Predict(dataX[i]);
    //    ssRes += (dataY[i] - predY) * (dataY[i] - predY);
    //    ssTot += (dataY[i] - meanY) * (dataY[i] - meanY);
    //  }
    //  if (Math.Abs(ssTot) "lt" 1.0e-12) // avoid div by 0
    //    return 0.0;
    //  else
    //    return 1.0 - (ssRes / ssTot);
    //}

    // ------------------------------------------------------

    //public void SetWeights(double[] weights)
    //{
    //  // used for a Load function, not-yet-implemented
    //  int ptr = 0;
    //  for (int i = 0; i "lt" this.numInput; ++i)
    //    for (int j = 0; j "lt" this.numHiddenA; ++j)
    //      this.iaWeights[i][j] = weights[ptr++];

    //  for (int i = 0; i "lt" numHiddenA; ++i)
    //    this.aBiases[i] = weights[ptr++];

    //  for (int i = 0; i "lt" this.numHiddenA; ++i)
    //    for (int j = 0; j "lt" this.numHiddenB; ++j)
    //      this.abWeights[i][j] = weights[ptr++];

    //  for (int i = 0; i "lt" this.numHiddenB; ++i)
    //    this.bBiases[i] = weights[ptr++];

    //  for (int i = 0; i "lt" this.numHiddenB; ++i)
    //    for (int j = 0; j "lt" this.numOutput; ++j)
    //      this.boWeights[i][j] = weights[ptr++];

    //  for (int i = 0; i "lt" this.numOutput; ++i)
    //    this.oBiases[i] = weights[ptr++];
    //}

    // ------------------------------------------------------

  } // class NeuralNetworkBistratumRegressor

  // ========================================================

} // ns

Training data:

# synthetic_train_200.txt
#
-0.1660,  0.4406, -0.9998, -0.3953, -0.7065,  0.4840
 0.0776, -0.1616,  0.3704, -0.5911,  0.7562,  0.1568
-0.9452,  0.3409, -0.1654,  0.1174, -0.7192,  0.8054
 0.9365, -0.3732,  0.3846,  0.7528,  0.7892,  0.1345
-0.8299, -0.9219, -0.6603,  0.7563, -0.8033,  0.7955
 0.0663,  0.3838, -0.3690,  0.3730,  0.6693,  0.3206
-0.9634,  0.5003,  0.9777,  0.4963, -0.4391,  0.7377
-0.1042,  0.8172, -0.4128, -0.4244, -0.7399,  0.4801
-0.9613,  0.3577, -0.5767, -0.4689, -0.0169,  0.6861
-0.7065,  0.1786,  0.3995, -0.7953, -0.1719,  0.5569
 0.3888, -0.1716, -0.9001,  0.0718,  0.3276,  0.2500
 0.1731,  0.8068, -0.7251, -0.7214,  0.6148,  0.3297
-0.2046, -0.6693,  0.8550, -0.3045,  0.5016,  0.2129
 0.2473,  0.5019, -0.3022, -0.4601,  0.7918,  0.2613
-0.1438,  0.9297,  0.3269,  0.2434, -0.7705,  0.5171
 0.1568, -0.1837, -0.5259,  0.8068,  0.1474,  0.3307
-0.9943,  0.2343, -0.3467,  0.0541,  0.7719,  0.5581
 0.2467, -0.9684,  0.8589,  0.3818,  0.9946,  0.1092
-0.6553, -0.7257,  0.8652,  0.3936, -0.8680,  0.7018
 0.8460,  0.4230, -0.7515, -0.9602, -0.9476,  0.1996
-0.9434, -0.5076,  0.7201,  0.0777,  0.1056,  0.5664
 0.9392,  0.1221, -0.9627,  0.6013, -0.5341,  0.1533
 0.6142, -0.2243,  0.7271,  0.4942,  0.1125,  0.1661
 0.4260,  0.1194, -0.9749, -0.8561,  0.9346,  0.2230
 0.1362, -0.5934, -0.4953,  0.4877, -0.6091,  0.3810
 0.6937, -0.5203, -0.0125,  0.2399,  0.6580,  0.1460
-0.6864, -0.9628, -0.8600, -0.0273,  0.2127,  0.5387
 0.9772,  0.1595, -0.2397,  0.1019,  0.4907,  0.1611
 0.3385, -0.4702, -0.8673, -0.2598,  0.2594,  0.2270
-0.8669, -0.4794,  0.6095, -0.6131,  0.2789,  0.4700
 0.0493,  0.8496, -0.4734, -0.8681,  0.4701,  0.3516
 0.8639, -0.9721, -0.5313,  0.2336,  0.8980,  0.1412
 0.9004,  0.1133,  0.8312,  0.2831, -0.2200,  0.1782
 0.0991,  0.8524,  0.8375, -0.2102,  0.9265,  0.2150
-0.6521, -0.7473, -0.7298,  0.0113, -0.9570,  0.7422
 0.6190, -0.3105,  0.8802,  0.1640,  0.7577,  0.1056
 0.6895,  0.8108, -0.0802,  0.0927,  0.5972,  0.2214
 0.1982, -0.9689,  0.1870, -0.1326,  0.6147,  0.1310
-0.3695,  0.7858,  0.1557, -0.6320,  0.5759,  0.3773
-0.1596,  0.3581,  0.8372, -0.9992,  0.9535,  0.2071
-0.2468,  0.9476,  0.2094,  0.6577,  0.1494,  0.4132
 0.1737,  0.5000,  0.7166,  0.5102,  0.3961,  0.2611
 0.7290, -0.3546,  0.3416, -0.0983, -0.2358,  0.1332
-0.3652,  0.2438, -0.1395,  0.9476,  0.3556,  0.4170
-0.6029, -0.1466, -0.3133,  0.5953,  0.7600,  0.4334
-0.4596, -0.4953,  0.7098,  0.0554,  0.6043,  0.2775
 0.1450,  0.4663,  0.0380,  0.5418,  0.1377,  0.2931
-0.8636, -0.2442, -0.8407,  0.9656, -0.6368,  0.7429
 0.6237,  0.7499,  0.3768,  0.1390, -0.6781,  0.2185
-0.5499,  0.1850, -0.3755,  0.8326,  0.8193,  0.4399
-0.4858, -0.7782, -0.6141, -0.0008,  0.4572,  0.4197
 0.7033, -0.1683,  0.2334, -0.5327, -0.7961,  0.1776
 0.0317, -0.0457, -0.6947,  0.2436,  0.0880,  0.3345
 0.5031, -0.5559,  0.0387,  0.5706, -0.9553,  0.3107
-0.3513,  0.7458,  0.6894,  0.0769,  0.7332,  0.3170
 0.2205,  0.5992, -0.9309,  0.5405,  0.4635,  0.3532
-0.4806, -0.4859,  0.2646, -0.3094,  0.5932,  0.3202
 0.9809, -0.3995, -0.7140,  0.8026,  0.0831,  0.1600
 0.9495,  0.2732,  0.9878,  0.0921,  0.0529,  0.1289
-0.9476, -0.6792,  0.4913, -0.9392, -0.2669,  0.5966
 0.7247,  0.3854,  0.3819, -0.6227, -0.1162,  0.1550
-0.5922, -0.5045, -0.4757,  0.5003, -0.0860,  0.5863
-0.8861,  0.0170, -0.5761,  0.5972, -0.4053,  0.7301
 0.6877, -0.2380,  0.4997,  0.0223,  0.0819,  0.1404
 0.9189,  0.6079, -0.9354,  0.4188, -0.0700,  0.1907
-0.1428, -0.7820,  0.2676,  0.6059,  0.3936,  0.2790
 0.5324, -0.3151,  0.6917, -0.1425,  0.6480,  0.1071
-0.8432, -0.9633, -0.8666, -0.0828, -0.7733,  0.7784
-0.9444,  0.5097, -0.2103,  0.4939, -0.0952,  0.6787
-0.0520,  0.6063, -0.1952,  0.8094, -0.9259,  0.4836
 0.5477, -0.7487,  0.2370, -0.9793,  0.0773,  0.1241
 0.2450,  0.8116,  0.9799,  0.4222,  0.4636,  0.2355
 0.8186, -0.1983, -0.5003, -0.6531, -0.7611,  0.1511
-0.4714,  0.6382, -0.3788,  0.9648, -0.4667,  0.5950
 0.0673, -0.3711,  0.8215, -0.2669, -0.1328,  0.2677
-0.9381,  0.4338,  0.7820, -0.9454,  0.0441,  0.5518
-0.3480,  0.7190,  0.1170,  0.3805, -0.0943,  0.4724
-0.9813,  0.1535, -0.3771,  0.0345,  0.8328,  0.5438
-0.1471, -0.5052, -0.2574,  0.8637,  0.8737,  0.3042
-0.5454, -0.3712, -0.6505,  0.2142, -0.1728,  0.5783
 0.6327, -0.6297,  0.4038, -0.5193,  0.1484,  0.1153
-0.5424,  0.3282, -0.0055,  0.0380, -0.6506,  0.6613
 0.1414,  0.9935,  0.6337,  0.1887,  0.9520,  0.2540
-0.9351, -0.8128, -0.8693, -0.0965, -0.2491,  0.7353
 0.9507, -0.6640,  0.9456,  0.5349,  0.6485,  0.1059
-0.0462, -0.9737, -0.2940, -0.0159,  0.4602,  0.2606
-0.0627, -0.0852, -0.7247, -0.9782,  0.5166,  0.2977
 0.0478,  0.5098, -0.0723, -0.7504, -0.3750,  0.3335
 0.0090,  0.3477,  0.5403, -0.7393, -0.9542,  0.4415
-0.9748,  0.3449,  0.3736, -0.1015,  0.8296,  0.4358
 0.2887, -0.9895, -0.0311,  0.7186,  0.6608,  0.2057
 0.1570, -0.4518,  0.1211,  0.3435, -0.2951,  0.3244
 0.7117, -0.6099,  0.4946, -0.4208,  0.5476,  0.1096
-0.2929, -0.5726,  0.5346, -0.3827,  0.4665,  0.2465
 0.4889, -0.5572, -0.5718, -0.6021, -0.7150,  0.2163
-0.7782,  0.3491,  0.5996, -0.8389, -0.5366,  0.6516
-0.5847,  0.8347,  0.4226,  0.1078, -0.3910,  0.6134
 0.8469,  0.4121, -0.0439, -0.7476,  0.9521,  0.1571
-0.6803, -0.5948, -0.1376, -0.1916, -0.7065,  0.7156
 0.2878,  0.5086, -0.5785,  0.2019,  0.4979,  0.2980
 0.2764,  0.1943, -0.4090,  0.4632,  0.8906,  0.2960
-0.8877,  0.6705, -0.6155, -0.2098, -0.3998,  0.7107
-0.8398,  0.8093, -0.2597,  0.0614, -0.0118,  0.6502
-0.8476,  0.0158, -0.4769, -0.2859, -0.7839,  0.7715
 0.5751, -0.7868,  0.9714, -0.6457,  0.1448,  0.1175
 0.4802, -0.7001,  0.1022, -0.5668,  0.5184,  0.1090
 0.4458, -0.6469,  0.7239, -0.9604,  0.7205,  0.0779
 0.5175,  0.4339,  0.9747, -0.4438, -0.9924,  0.2879
 0.8678,  0.7158,  0.4577,  0.0334,  0.4139,  0.1678
 0.5406,  0.5012,  0.2264, -0.1963,  0.3946,  0.2088
-0.9938,  0.5498,  0.7928, -0.5214, -0.7585,  0.7687
 0.7661,  0.0863, -0.4266, -0.7233, -0.4197,  0.1466
 0.2277, -0.3517, -0.0853, -0.1118,  0.6563,  0.1767
 0.3499, -0.5570, -0.0655, -0.3705,  0.2537,  0.1632
 0.7547, -0.1046,  0.5689, -0.0861,  0.3125,  0.1257
 0.8186,  0.2110,  0.5335,  0.0094, -0.0039,  0.1391
 0.6858, -0.8644,  0.1465,  0.8855,  0.0357,  0.1845
-0.4967,  0.4015,  0.0805,  0.8977,  0.2487,  0.4663
 0.6760, -0.9841,  0.9787, -0.8446, -0.3557,  0.1509
-0.1203, -0.4885,  0.6054, -0.0443, -0.7313,  0.4854
 0.8557,  0.7919, -0.0169,  0.7134, -0.1628,  0.2002
 0.0115, -0.6209,  0.9300, -0.4116, -0.7931,  0.4052
-0.7114, -0.9718,  0.4319,  0.1290,  0.5892,  0.3661
 0.3915,  0.5557, -0.1870,  0.2955, -0.6404,  0.2954
-0.3564, -0.6548, -0.1827, -0.5172, -0.1862,  0.4622
 0.2392, -0.4959,  0.5857, -0.1341, -0.2850,  0.2470
-0.3394,  0.3947, -0.4627,  0.6166, -0.4094,  0.5325
 0.7107,  0.7768, -0.6312,  0.1707,  0.7964,  0.2757
-0.1078,  0.8437, -0.4420,  0.2177,  0.3649,  0.4028
-0.3139,  0.5595, -0.6505, -0.3161, -0.7108,  0.5546
 0.4335,  0.3986,  0.3770, -0.4932,  0.3847,  0.1810
-0.2562, -0.2894, -0.8847,  0.2633,  0.4146,  0.4036
 0.2272,  0.2966, -0.6601, -0.7011,  0.0284,  0.2778
-0.0743, -0.1421, -0.0054, -0.6770, -0.3151,  0.3597
-0.4762,  0.6891,  0.6007, -0.1467,  0.2140,  0.4266
-0.4061,  0.7193,  0.3432,  0.2669, -0.7505,  0.6147
-0.0588,  0.9731,  0.8966,  0.2902, -0.6966,  0.4955
-0.0627, -0.1439,  0.1985,  0.6999,  0.5022,  0.3077
 0.1587,  0.8494, -0.8705,  0.9827, -0.8940,  0.4263
-0.7850,  0.2473, -0.9040, -0.4308, -0.8779,  0.7199
 0.4070,  0.3369, -0.2428, -0.6236,  0.4940,  0.2215
-0.0242,  0.0513, -0.9430,  0.2885, -0.2987,  0.3947
-0.5416, -0.1322, -0.2351, -0.0604,  0.9590,  0.3683
 0.1055,  0.7783, -0.2901, -0.5090,  0.8220,  0.2984
-0.9129,  0.9015,  0.1128, -0.2473,  0.9901,  0.4776
-0.9378,  0.1424, -0.6391,  0.2619,  0.9618,  0.5368
 0.7498, -0.0963,  0.4169,  0.5549, -0.0103,  0.1614
-0.2612, -0.7156,  0.4538, -0.0460, -0.1022,  0.3717
 0.7720,  0.0552, -0.1818, -0.4622, -0.8560,  0.1685
-0.4177,  0.0070,  0.9319, -0.7812,  0.3461,  0.3052
-0.0001,  0.5542, -0.7128, -0.8336, -0.2016,  0.3803
 0.5356, -0.4194, -0.5662, -0.9666, -0.2027,  0.1776
-0.2378,  0.3187, -0.8582, -0.6948, -0.9668,  0.5474
-0.1947, -0.3579,  0.1158,  0.9869,  0.6690,  0.2992
 0.3992,  0.8365, -0.9205, -0.8593, -0.0520,  0.3154
-0.0209,  0.0793,  0.7905, -0.1067,  0.7541,  0.1864
-0.4928, -0.4524, -0.3433,  0.0951, -0.5597,  0.6261
-0.8118,  0.7404, -0.5263, -0.2280,  0.1431,  0.6349
 0.0516, -0.8480,  0.7483,  0.9023,  0.6250,  0.1959
-0.3212,  0.1093,  0.9488, -0.3766,  0.3376,  0.2735
-0.3481,  0.5490, -0.3484,  0.7797,  0.5034,  0.4379
-0.5785, -0.9170, -0.3563, -0.9258,  0.3877,  0.4121
 0.3407, -0.1391,  0.5356,  0.0720, -0.9203,  0.3458
-0.3287, -0.8954,  0.2102,  0.0241,  0.2349,  0.3247
-0.1353,  0.6954, -0.0919, -0.9692,  0.7461,  0.3338
 0.9036, -0.8982, -0.5299, -0.8733, -0.1567,  0.1187
 0.7277, -0.8368, -0.0538, -0.7489,  0.5458,  0.0830
 0.9049,  0.8878,  0.2279,  0.9470, -0.3103,  0.2194
 0.7957, -0.1308, -0.5284,  0.8817,  0.3684,  0.2172
 0.4647, -0.4931,  0.2010,  0.6292, -0.8918,  0.3371
-0.7390,  0.6849,  0.2367,  0.0626, -0.5034,  0.7039
-0.1567, -0.8711,  0.7940, -0.5932,  0.6525,  0.1710
 0.7635, -0.0265,  0.1969,  0.0545,  0.2496,  0.1445
 0.7675,  0.1354, -0.7698, -0.5460,  0.1920,  0.1728
-0.5211, -0.7372, -0.6763,  0.6897,  0.2044,  0.5217
 0.1913,  0.1980,  0.2314, -0.8816,  0.5006,  0.1998
 0.8964,  0.0694, -0.6149,  0.5059, -0.9854,  0.1825
 0.1767,  0.7104,  0.2093,  0.6452,  0.7590,  0.2832
-0.3580, -0.7541,  0.4426, -0.1193, -0.7465,  0.5657
-0.5996,  0.5766, -0.9758, -0.3933, -0.9572,  0.6800
 0.9950,  0.1641, -0.4132,  0.8579,  0.0142,  0.2003
-0.4717, -0.3894, -0.2567, -0.5111,  0.1691,  0.4266
 0.3917, -0.8561,  0.9422,  0.5061,  0.6123,  0.1212
-0.0366, -0.1087,  0.3449, -0.1025,  0.4086,  0.2475
 0.3633,  0.3943,  0.2372, -0.6980,  0.5216,  0.1925
-0.5325, -0.6466, -0.2178, -0.3589,  0.6310,  0.3568
 0.2271,  0.5200, -0.1447, -0.8011, -0.7699,  0.3128
 0.6415,  0.1993,  0.3777, -0.0178, -0.8237,  0.2181
-0.5298, -0.0768, -0.6028, -0.9490,  0.4588,  0.4356
 0.6870, -0.1431,  0.7294,  0.3141,  0.1621,  0.1632
-0.5985,  0.0591,  0.7889, -0.3900,  0.7419,  0.2945
 0.3661,  0.7984, -0.8486,  0.7572, -0.6183,  0.3449
 0.6995,  0.3342, -0.3113, -0.6972,  0.2707,  0.1712
 0.2565,  0.9126,  0.1798, -0.6043, -0.1413,  0.2893
-0.3265,  0.9839, -0.2395,  0.9854,  0.0376,  0.4770
 0.2690, -0.1722,  0.9818,  0.8599, -0.7015,  0.3954
-0.2102, -0.0768,  0.1219,  0.5607, -0.0256,  0.3949
 0.8216, -0.9555,  0.6422, -0.6231,  0.3715,  0.0801
-0.2896,  0.9484, -0.7545, -0.6249,  0.7789,  0.4370
-0.9985, -0.5448, -0.7092, -0.5931,  0.7926,  0.5402

Test data:

# synthetic_test_40.txt
#
 0.7462,  0.4006, -0.0590,  0.6543, -0.0083,  0.1935
 0.8495, -0.2260, -0.0142, -0.4911,  0.7699,  0.1078
-0.2335, -0.4049,  0.4352, -0.6183, -0.7636,  0.5088
 0.1810, -0.5142,  0.2465,  0.2767, -0.3449,  0.3136
-0.8650,  0.7611, -0.0801,  0.5277, -0.4922,  0.7140
-0.2358, -0.7466, -0.5115, -0.8413, -0.3943,  0.4533
 0.4834,  0.2300,  0.3448, -0.9832,  0.3568,  0.1360
-0.6502, -0.6300,  0.6885,  0.9652,  0.8275,  0.3046
-0.3053,  0.5604,  0.0929,  0.6329, -0.0325,  0.4756
-0.7995,  0.0740, -0.2680,  0.2086,  0.9176,  0.4565
-0.2144, -0.2141,  0.5813,  0.2902, -0.2122,  0.4119
-0.7278, -0.0987, -0.3312, -0.5641,  0.8515,  0.4438
 0.3793,  0.1976,  0.4933,  0.0839,  0.4011,  0.1905
-0.8568,  0.9573, -0.5272,  0.3212, -0.8207,  0.7415
-0.5785,  0.0056, -0.7901, -0.2223,  0.0760,  0.5551
 0.0735, -0.2188,  0.3925,  0.3570,  0.3746,  0.2191
 0.1230, -0.2838,  0.2262,  0.8715,  0.1938,  0.2878
 0.4792, -0.9248,  0.5295,  0.0366, -0.9894,  0.3149
-0.4456,  0.0697,  0.5359, -0.8938,  0.0981,  0.3879
 0.8629, -0.8505, -0.4464,  0.8385,  0.5300,  0.1769
 0.1995,  0.6659,  0.7921,  0.9454,  0.9970,  0.2330
-0.0249, -0.3066, -0.2927, -0.4923,  0.8220,  0.2437
 0.4513, -0.9481, -0.0770, -0.4374, -0.9421,  0.2879
-0.3405,  0.5931, -0.3507, -0.3842,  0.8562,  0.3987
 0.9538,  0.0471,  0.9039,  0.7760,  0.0361,  0.1706
-0.0887,  0.2104,  0.9808,  0.5478, -0.3314,  0.4128
-0.8220, -0.6302,  0.0537, -0.1658,  0.6013,  0.4306
-0.4123, -0.2880,  0.9074, -0.0461, -0.4435,  0.5144
 0.0060,  0.2867, -0.7775,  0.5161,  0.7039,  0.3599
-0.7968, -0.5484,  0.9426, -0.4308,  0.8148,  0.2979
 0.7811,  0.8450, -0.6877,  0.7594,  0.2640,  0.2362
-0.6802, -0.1113, -0.8325, -0.6694, -0.6056,  0.6544
 0.3821,  0.1476,  0.7466, -0.5107,  0.2592,  0.1648
 0.7265,  0.9683, -0.9803, -0.4943, -0.5523,  0.2454
-0.9049, -0.9797, -0.0196, -0.9090, -0.4433,  0.6447
-0.4607,  0.1811, -0.2389,  0.4050, -0.0078,  0.5229
 0.2664, -0.2932, -0.4259, -0.7336,  0.8742,  0.1834
-0.4507,  0.1029, -0.6294, -0.1158, -0.6294,  0.6081
 0.8948, -0.0124,  0.9278,  0.2899, -0.0314,  0.1534
-0.1323, -0.8813, -0.0146, -0.0697,  0.6135,  0.2386

Technically, a deep neural network is one that has two or more hidden layers of processing nodes. But deep neural networks for image processing or natural language processing typically have dozens or hundreds of hidden layers.

A special case is a neural network regressor that has exactly two hidden layers. My colleagues and I call such a system a neural network bistratum regressor. Bistratum means two layers in Latin.

In theory, a neural network with a single hidden layer can compute anything a neural network with two ot more layers can, but in practice, two hidden layers often works better.

I put together a demo to illustrate the neural network bistratum regressor input-output mechanism. The output of the demo is:

Neural network bistratum regression IO using C#

Creating 2-3-3-1 tanh() identity() neural network regressor
Done

Setting weights and biases to 0.01 to 0.25
Done

Computing output for x = [1.0, 2.0]
y = 0.4418

Displaying hidden node values:

A: 0.1586 0.1974 0.2355

B: 0.2629 0.2776 0.2923

End demo

The demo network has two input nodes, two hidden layers with three nodes each, and a single output node. The network uses tanh() activation on the hidden layer nodes, and identity() activation on the output node. The network is initialized with weights and biases values from 0.01 to 0.25. The network is fed an input of [1.0, 2.0]. The output is y = 0.4418.

This diagram explains the calculations:

Click to enlarge

The main challenge when using a neural network in finding good values for the weights and biases so that computed outputs match known correct outputs in a set of training data. The most common way to do this is by using one of many variations of stochastic gradient descent.

I’m a big fan of old science fiction movies from the 1950s. Jets had been developed only a few years earlier. Jet bombers made a couple of notable (to me anyway) appearances in two of my favorite movies of the decade.

Bottom Row: In “Beginning of the End” (1957), experiments with radiation to grow giant food result in giant locusts/grasshoppers. Hundreds of thousands of the menaces threaten to destroy Chicago and the move on. As a last resort, the military plans to use a B-36 to drop a nuclear bomb on Chicago. Scientists come up with a clever plan to use a synthetic mating call to lure the insects into Lake Michigan, and humanity is saved.

Demo program. Replace “lt” (less than), “gt”, “lte”, “gte” with Boolean operator symbols (my blog editor often chokes on symbols).

using System;
using System.IO;
using System.Collections.Generic;

namespace NeuralNetworkBistratumRegression
{
  internal class NeuralNetworkBistratumRegressionProgram
  {
    static void Main(string[] args)
    {
      Console.WriteLine("\nNeural network bistratum " +
        "regression IO using C# ");

      Console.WriteLine("\nCreating 2-3-3-1 tanh()" +
        " identity() neural network regressor ");

      NeuralNetworkBistratumRegressor nn =
         new NeuralNetworkBistratumRegressor(2, 3, 3, 1);
      Console.WriteLine("Done ");

      Console.WriteLine("\nSetting weights and biases to" +
        " 0.01 to 0.25 ");
      double[] wts = new double[] {.01, .02, .03, .04, .05,
        .06, .07, .08, .09, .10, .11, .12, .13, .14, .15,
        .16, .17, .18, .19, .20, .21, .22, .23, .24, .25 };
      nn.SetWeights(wts);
      Console.WriteLine("Done ");

      Console.WriteLine("\nComputing output" +
        " for x = [1.0, 2.0] ");
      double y = nn.Predict(new double[] { 1, 2 });
      Console.WriteLine("y = " + y.ToString("F4"));

      Console.WriteLine("\nDisplaying hidden node values: ");
      Console.WriteLine("\nA: " +
        nn.aNodes[0].ToString("F4") + " " +
        nn.aNodes[1].ToString("F4") + " " +
        nn.aNodes[2].ToString("F4"));
      Console.WriteLine("\nB: " +
        nn.bNodes[0].ToString("F4") + " " +
        nn.bNodes[1].ToString("F4") + " " +
        nn.bNodes[2].ToString("F4"));

      Console.WriteLine("\nEnd demo ");
      Console.ReadLine();

    } // Main

  } // class Program

  // ========================================================

  public class NeuralNetworkBistratumRegressor
  {
    // two hidden layers
    public int numInput;
    public int numHiddenA;
    public int numHiddenB;
    public int numOutput;

    public double[] iNodes;  // input nodes
    public double[] aNodes;
    public double[] bNodes;
    public double[] oNodes;  // output nodes

    public double[][] iaWeights; // input to hidden A
    public double[][] abWeights; // hidden A to hidden B
    public double[][] boWeights; // hidden B to output

    public double[] aBiases;
    public double[] bBiases;
    public double[] oBiases;

    private Random rnd;

    // ------------------------------------------------------

    public NeuralNetworkBistratumRegressor(int numInput,
      int numHiddenA, int numHiddenB, int numOutput,
      int seed = 0)
    {
      this.numInput = numInput;
      this.numHiddenA = numHiddenA;
      this.numHiddenB = numHiddenB;
      this.numOutput = numOutput; // 1 for regression

      this.iNodes = new double[numInput];
      this.iaWeights = MatMake(numInput, numHiddenA);
      this.aBiases = new double[numHiddenA];
      this.aNodes = new double[numHiddenA];

      this.abWeights = MatMake(numHiddenA, numHiddenB);
      this.bBiases = new double[numHiddenB];
      this.bNodes = new double[numHiddenB];

      this.boWeights = MatMake(numHiddenB, numOutput);
      this.oBiases = new double[numOutput];
      this.oNodes = new double[numOutput];

      this.rnd = new Random(seed);
    }

    // ------------------------------------------------------

    private static double[][] MatMake(int nRows, int nCols)
    {
      double[][] result = new double[nRows][];
      for (int i = 0; i "lt" nRows; ++i)
        result[i] = new double[nCols];
      return result;
    }

    // ------------------------------------------------------

    public double Predict(double[] x)
    {
      // copy input into iNodes
      for (int i = 0; i "lt" this.numInput; ++i)
        this.iNodes[i] = x[i];

      // compute hidden layer A
      for (int j = 0; j "lt" numHiddenA; ++j)
      {
        double sum = 0.0;
        for (int i = 0; i "lt" this.numInput; ++i)
          sum += this.iNodes[i] * this.iaWeights[i][j];
        sum += this.aBiases[j];
        this.aNodes[j] = HyperTan(sum);
      }

      // compute hidden layer B
      for (int j = 0; j "lt" this.numHiddenB; ++j)
      {
        double sum = 0.0;
        for (int i = 0; i "lt" this.numHiddenA; ++i)
          sum += this.aNodes[i] * this.abWeights[i][j];
        sum += this.bBiases[j];
        this.bNodes[j] = HyperTan(sum);
      }

      // compute output layer node
      for (int j = 0; j "lt" this.numOutput; ++j)
      {
        double sum = 0.0;
        for (int i = 0; i "lt" this.numHiddenB; ++i)
          sum += this.bNodes[i] * this.boWeights[i][j];
        sum += this.oBiases[j];
        this.oNodes[j] = Identity(sum);
      }

      return this.oNodes[0];  // a single value
    }

    // ------------------------------------------------------

    private static double HyperTan(double x)
    {
      if (x "lt" -6.0) return -1.0;
      else if (x "gt" 6.0) return 1.0;
      else return Math.Tanh(x);
    }

    // ------------------------------------------------------

    private static double Identity(double x)
    {
      return x;
    }


    // ------------------------------------------------------

    public void SetWeights(double[] weights)
    {
      int ptr = 0;
      for (int i = 0; i "lt" this.numInput; ++i)
        for (int j = 0; j "lt" this.numHiddenA; ++j)
          this.iaWeights[i][j] = weights[ptr++];

      for (int i = 0; i "lt" numHiddenA; ++i)
        this.aBiases[i] = weights[ptr++];

      for (int i = 0; i "lt" this.numHiddenA; ++i)
        for (int j = 0; j "lt" this.numHiddenB; ++j)
          this.abWeights[i][j] = weights[ptr++];

      for (int i = 0; i "lt" this.numHiddenB; ++i)
        this.bBiases[i] = weights[ptr++];

      for (int i = 0; i "lt" this.numHiddenB; ++i)
        for (int j = 0; j "lt" this.numOutput; ++j)
          this.boWeights[i][j] = weights[ptr++];

      for (int i = 0; i "lt" this.numOutput; ++i)
        this.oBiases[i] = weights[ptr++];
    }

    // ------------------------------------------------------

  } // class NeuralNetworkBistratumRegressor

  // ========================================================

} // ns
