I’ve been working on a non-trivial Python language software tool to covert a chess game file stored in PGN notation to a file of FEN strings See the post at https://jamesmccaffreyblog.com/2024/05/15/programmatically-converting-chess-pgn-to-fen/ for an explanation of the problem. The code is at https://github.com/jdmccaffrey/convert-pgn-to-fen.

One of the early design decisions was choosing a data structure to represent the board position of a Game State. I had already decided to represent a position as an array of string[64] like [“r”, “n”, . . “K”, “1”, “1”, “R”] but that doesn’t define how to represent the squares on the board.

The most obvious idea would be to represent board squares as a matrix using their algebraic coordinates. For example, something like board[“a”][“4”] or board[“h”][“8”]. But I knew from previous explorations into programmatic chess analysis that this matrix approach just doesn’t work as well as representing each square with an integer ID from 0 to 64. Specifically:

----------------------------------
|  0   1   2   3   4   5   6   7  | 8
|  8   9  10  11  12  13  14  15  | 7
| 16  17  18  19  20  21  22  23  | 6
| 24  25  26  27  28  29  30  31  | 5
| 32  33  34  35  36  37  38  39  | 4
| 40  41  42  43  44  45  46  47  | 3
| 48  49  50  51  52  53  54  55  | 2
| 56  57  58  59  60  61  62  63  | 1
----------------------------------
   a   b   c   d   e   f   g   h

The reason for using this representation design is the fact PGN notation tells you what piece moved, and where it landed, but does not tell you where the piece came from. For example, the move Bxc6 tells you a bishop captured something on square c6 (square 18 above), but the bishop could have potentially come from one of 11 squares: b5, a4, b7, a8, d5, e4, f3, g2, h1, d7, e8. Using the integer representation, potential came-from squares are the landing square, 18, offset by one of (+7, +14, +9, +18, +27, +36, +45, -7, -14, -9, -18). Similar logic can be used for rooks, knights, queens, and kings, but not pawns.

Determining where a piece came from is by far the most difficult part of implementing a PGN-to-FEN function.

A position I used during development for testing and an image showing the board square representation.

Additionally, notice that because a board_position member array in the GameState class is just an array[64] of strings, there’s a direct relationship between a board_position array and the integer representation.

Here’s some example code:

  gs = GameState()  # initial position
  gs.board_position[32] = "Q"  # square a4
  gs.board_position[39] = "N"  # square h4
  gs.display()

The output is:

+---+---+---+---+---+---+---+---+
| r | n | b | q | k | b | n | r | 8
+---+---+---+---+---+---+---+---+
| p | p | p | p | p | p | p | p | 7
+---+---+---+---+---+---+---+---+
|   |   |   |   |   |   |   |   | 6
+---+---+---+---+---+---+---+---+
|   |   |   |   |   |   |   |   | 5
+---+---+---+---+---+---+---+---+
| Q |   |   |   |   |   |   | N | 4
+---+---+---+---+---+---+---+---+
|   |   |   |   |   |   |   |   | 3
+---+---+---+---+---+---+---+---+
| P | P | P | P | P | P | P | P | 2
+---+---+---+---+---+---+---+---+
| R | N | B | Q | K | B | N | R | 1
+---+---+---+---+---+---+---+---+
  a   b   c   d   e   f   g   h
rnbqkbnr/pppppppp/8/8/Q6N/8/PPPPPPPP/RNBQKBNR w KQkq - 0 1

As it turns out, using an integer ID for each square means you need to add some helper functions. Specifically, square_color(), square_file(), square_rank(), square_algebraic_to_int(), and square_int_to_algebraic().

Examples:

square_color(56) == "b"  # lower left corner is black
square_file(5) == "f"  # square ID=5 is "f" file (column)
square_rank(5) == "8"  # square ID=5 is the 8th rank (row)
square_algebraic_to_int("e4") == 36
square_int_to_algebraic(36) == "e4"

Here is the code for the five helper functions. Replace “gte” (greater than or equal) and “lte” with Boolean operator symbols. (My editor seems to choke on those symbols).

# -------------------------------------------------------------------------------------------------

  @staticmethod
  def square_color(square_id):
    if square_id == 0 or square_id == 2 or square_id == 4 or square_id == 6 or \
      square_id == 9 or square_id == 11 or square_id == 13 or square_id == 15 or \
      square_id == 16 or square_id == 18 or square_id == 20 or square_id == 22 or \
      square_id == 25 or square_id == 27 or square_id == 29 or square_id == 31 or \
      square_id == 32 or square_id == 34 or square_id == 36 or square_id == 38 or \
      square_id == 41 or square_id == 43 or square_id == 45 or square_id == 47 or \
      square_id == 48 or square_id == 50 or square_id == 52 or square_id == 54 or \
      square_id == 57 or square_id == 59 or square_id == 61 or square_id == 63:
      return "w"
    else:
      return "b"

  # -----------------------------------------------------------------------------------------------

  @staticmethod
  def square_file(square_id):
    if square_id % 8 == 0: return "a"
    elif (square_id - 1) % 8 == 0: return "b"
    elif (square_id - 2) % 8 == 0: return "c"
    elif (square_id - 3) % 8 == 0: return "d"
    elif (square_id - 4) % 8 == 0: return "e"
    elif (square_id - 5) % 8 == 0: return "f"
    elif (square_id - 6) % 8 == 0: return "g"
    elif (square_id - 7) % 8 == 0: return "h"
    return "z"  # error

  # -----------------------------------------------------------------------------------------------

  @staticmethod
  def square_rank(square_id):
    if square_id "gte" 0 and square_id "lte" 7: return "8"
    elif square_id "gte" 8 and square_id "lte" 15: return "7"
    elif square_id "gte" 16 and square_id "lte" 23: return "6"
    elif square_id "gte" 24 and square_id "lte" 31: return "5"
    elif square_id "gte" 32 and square_id "lte" 39: return "4"
    elif square_id "gte" 40 and square_id "lte" 47: return "3"
    elif square_id "gte" 48 and square_id "lte" 55: return "2"
    elif square_id "gte" 56 and square_id "lte" 63: return "1"
    return "0"  # error

  # -----------------------------------------------------------------------------------------------

  @staticmethod
  def square_algebraic_to_int(algebraic_id):
    # input like "h8", result like 7
    lookup = [
      "a8","b8","c8", "d8","e8", "f8", "g8", "h8",
      "a7","b7","c7", "d7","e7", "f7", "g7", "h7",
      "a6","b6","c6", "d6","e6", "f6", "g6", "h6",
      "a5","b5","c5", "d5","e5", "f5", "g5", "h5",
      "a4","b4","c4", "d4","e4", "f4", "g4", "h4",
      "a3","b3","c3", "d3","e3", "f3", "g3", "h3",
      "a2","b2","c2", "d2","e2", "f2", "g2", "h2",
      "a1","b1","c1", "d1","e1", "f1", "g1", "h1" ]
    idx = lookup.index(algebraic_id)  # not same as string find()
    return idx   # -1 on error

  # -----------------------------------------------------------------------------------------------

  @staticmethod
  def square_int_to_algebraic(integer_id):
    # input like 63, result like "h1"
    lookup = [
      "a8","b8","c8", "d8","e8", "f8", "g8", "h8",
      "a7","b7","c7", "d7","e7", "f7", "g7", "h7",
      "a6","b6","c6", "d6","e6", "f6", "g6", "h6",
      "a5","b5","c5", "d5","e5", "f5", "g5", "h5",
      "a4","b4","c4", "d4","e4", "f4", "g4", "h4",
      "a3","b3","c3", "d3","e3", "f3", "g3", "h3",
      "a2","b2","c2", "d2","e2", "f2", "g2", "h2",
      "a1","b1","c1", "d1","e1", "f1", "g1", "h1" ]
    return lookup[integer_id]

  # -----------------------------------------------------------------------------------------------

Even though the five helper functions are simple, there are a surprising number of minor design alternatives. For example, the lookup variable in square_algebraic_to_int() and square_int_to_algebraic() is a Python List of int. Because the number of values (64) is fixed, I could have used a NumPy array. Or, because the two functions use the same lookup list, I could have made just one globally accessible list.
