I’ve been looking at adding a Transformer module to a PyTorch regression network. Because the key functionality of a Transformer is the attention mechanism, I’ve also been looking at adding a custom Attention module instead of a Transformer.

There are dozens of design alternatives, and many architecture and training hyperparameters. For the baseline architecture against which I’m comparing, I use a standard PyTorch TransformerEncoder layer, a pseudo-embedding layer, and a simplified positional encoding layer.

All of my ideas are based on natural language processing systems. In NLP, each word/token is mapped to an integer, such as “crane” = 2206. Then the integer is mapped to a vector of real values, typically about 100-1000 values — the embedding. The idea is to capture different dimensions of the meanings of the source word/token, such as crane is a kind of bird, or a kind of construction equipment, or a way to position a head to see something not in direct line of sight, etc. After embedding, in an NLP system positional encoding is necessary because the order of words in a sentence is critical. For a regression system, both embedding and positional encoding are optional. I intend to examine the architecture options as best I can.

For this investigation, I’m swapping out the baseline simplified positional encoding layer with the standard NLP positional encoding layer. My working hypothesis was that there would be no difference between the two positional encoding techniques. But my experiment suggests that the simplified positional encoding is better than the classic NLP positional encoding.

The two positional encoding techniques are quite different. The classic NLP positional encoding layer is short but complicated:

class PositionalEncoding(T.nn.Module):
  def __init__(self, d_model: int, dropout: float=0.1,
   max_len: int=5000):
    super(PositionalEncoding, self).__init__()  # old syntax
    self.dropout = T.nn.Dropout(p=dropout)
    pe = T.zeros(max_len, d_model)  # like 10x4
    position = \
      T.arange(0, max_len, dtype=T.float).unsqueeze(1)
    div_term = T.exp(T.arange(0, d_model, 2).float() * \
      (-np.log(10_000.0) / d_model))
    pe[:, 0::2] = T.sin(position * div_term)
    pe[:, 1::2] = T.cos(position * div_term)
    pe = pe.unsqueeze(0).transpose(0, 1)
    self.register_buffer('pe', pe)  # allows state-save

  def forward(self, x):
    x = x + self.pe[:x.size(0), :]
    return self.dropout(x)

It took me quite a few hours to dissect this code, and it would take several pages to explain how it works. Briefly, each embedding vector element gets a value added, which can be used internally to encode the position. There are many explanations available on the Internet, but two key ideas are 1.) the classic technique is designed for NP scenarios where an input word/token in integer form is mapped to a large (typically at least 100 elements, the dimension) vector, and 2.) the layer has a built-in dropout layer.

My simplified positional encoding layer is:

class PositionEncode(T.nn.Module):
  def __init__(self, n_features):
    super(PositionEncode, self).__init__()  # old syntax
    self.nf = n_features
    self.pe = T.zeros(n_features, dtype=T.float32)
    for i in range(n_features):
      self.pe[i] = i * (0.01 / n_features)  # no sin, cos

  def forward(self, x):
    for i in range(len(x)):
      for j in range(len(x[0])):
        x[i][j] += self.pe[j]
    return x

Instead of a complex technique that adds sine and cosine values, my simplified technique just adds a simple value. This idea will work (I think) as long as the embedded vector is not too big.

When I ran the experiment, I was mildly surprised that the classic NLP positional encoding technique seemed to perform worse than the simplified positional encoding technique, even when I set the classic version dropout value to 0. I say “seemed” because it’s virtually impossible to compare different systems because of the vast number of hyperparameter values. I have no explanation, but one possibility is that the simplified positional encoding is simply easier to train than the more complicated classic positional encoding.

A diagram of a 6-12-PE-T-(8-8)-1 system, not the 6-24-PE-T-(10-10)-1 system of the demo.

The demo uses one of my standard synthetic datasets. The data looks like:

-0.1660,  0.4406, -0.9998, -0.3953, -0.7065, -0.8153,  0.7022
-0.2065,  0.0776, -0.1616,  0.3704, -0.5911,  0.7562,  0.5666
-0.9452,  0.3409, -0.1654,  0.1174, -0.7192, -0.6038,  0.8186
 0.7528,  0.7892, -0.8299, -0.9219, -0.6603,  0.7563,  0.3687
. . .

The first six values on each line are predictors. The last value on each line is the target to predict. The data was generated by a 6-10-1 neural network with random weights and biases. There are 200 training items and 40 test items.

The baseline architecture is 6-24-PE-T-(10-10)-1 meaning 6 inputs, each to 4 embedding, plus positional encoding, fed to a Transformer, sent to two hidden layers of 10 nodes each, sent to a single output prediction node.

Here’s the output of one demo run:

Begin Transformer regression on synthetic data
Classic NLP position encoding (w/ dropout) module

Loading train (200) and test (40) data to memory
Done

First three rows of training predictors:
tensor([-0.1660,  0.4406, -0.9998, -0.3953, -0.7065, -0.8153])
tensor([-0.2065,  0.0776, -0.1616,  0.3704, -0.5911,  0.7562])
tensor([-0.9452,  0.3409, -0.1654,  0.1174, -0.7192, -0.6038])

First three target y values:
0.7022
0.5666
0.8186

Creating 6--24-PE-T-(10-10)-1 regression model

bat_size = 10
loss = MSELoss()
optimizer = Adam
lrn_rate = 0.001

Starting training
epoch =    0  |  loss = 1.6554
epoch =   20  |  loss = 0.4812
epoch =   40  |  loss = 0.1834
epoch =   60  |  loss = 0.1270
epoch =   80  |  loss = 0.1063
Done

Computing model accuracy (within 0.10 of true)
Accuracy on train data = 0.7700
Accuracy on test data = 0.6500

MSE on train data = 0.0017
MSE on test data = 0.0027

Predicting target y for train[0]:
Predicted y = 0.7017

End demo

The model accuracy (77% = 154 out of 200 correct on the training data) and mean squared error (0.0017 on training data) were not as good as the baseline architecture (84% and 0.0012).

Fascinating stuff.

It’s quite difficult to compare different versions of a machine learning regression system. It’s also difficult to compare different book covers of a novel.

The story was originally published in 1928, and then revised in 1964. Left: This is the cover from 1959, by artist Rudi Nappi (1923-2015). Center: This is a cover from 1964, also by Nappi. Right: Unknown to book publisher Grosset and Dunlap, Nappi also worked for dozens of other publishers, most of them not quite so wholesome. “Weep for a Wanton” (1956), cover art by Nappi.

Demo code. Replace “lt” (less than), “gt”, “lte”, “gte” with Boolean operator symbols (my blog editor chokes on symbols).

# synthetic_transformer_nlp_pe.py

# regression with Transformer and pseudo-embedding,
# classic NLP positional encoding on a synthetic dataset
# PyTorch 2.3.1-CPU  Anaconda3-2023.09  Python 3.11.5
# Windows 10/11

import numpy as np
import torch as T  # non-standard alias

device = T.device('cpu')  # apply to Tensor or Module

# -----------------------------------------------------------

class SynthDataset(T.utils.data.Dataset):
  # six predictors followed by target
  def __init__(self, src_file):
    tmp_x = np.loadtxt(src_file, delimiter=",",
      usecols=[0,1,2,3,4,5], dtype=np.float32)
    tmp_y = np.loadtxt(src_file, usecols=6, delimiter=",",
      dtype=np.float32)
    tmp_y = tmp_y.reshape(-1,1)  # 2D required

    self.x_data = T.tensor(tmp_x, dtype=T.float32).to(device)
    self.y_data = T.tensor(tmp_y, dtype=T.float32).to(device)

  def __len__(self):
    return len(self.x_data)

  def __getitem__(self, idx):
    preds = self.x_data[idx]
    trgts = self.y_data[idx]
    return (preds, trgts)  # as a tuple

# -----------------------------------------------------------

class SkipLinear(T.nn.Module):
  # numeric pseudo-embedding
  # -----

  class Core(T.nn.Module):
    def __init__(self, n):
      super().__init__()
      # 1 node to n nodes, n gte 2
      self.weights = T.nn.Parameter(T.zeros((n,1),
        dtype=T.float32))
      self.biases = T.nn.Parameter(T.tensor(n,
        dtype=T.float32))
      lim = 0.01
      T.nn.init.uniform_(self.weights, -lim, lim)
      T.nn.init.zeros_(self.biases)

    def forward(self, x):
      wx= T.mm(x, self.weights.t())
      v = T.add(wx, self.biases)
      return v

  # -----

  def __init__(self, n_in, n_out):
    super().__init__()
    self.n_in = n_in; self.n_out = n_out
    if n_out  % n_in != 0:
      print("FATAL: n_out must be divisible by n_in")
    n = n_out // n_in  # num nodes per input

    self.lst_modules = \
      T.nn.ModuleList([SkipLinear.Core(n) for \
        i in range(n_in)])

  def forward(self, x):
    lst_nodes = []
    for i in range(self.n_in):
      xi = x[:,i].reshape(-1,1)
      oupt = self.lst_modules[i](xi)
      lst_nodes.append(oupt)
    result = T.cat((lst_nodes[0], lst_nodes[1]), 1)
    for i in range(2,self.n_in):
      result = T.cat((result, lst_nodes[i]), 1)
    result = result.reshape(-1, self.n_out)
    return result

# -----------------------------------------------------------

# baseline simplified positional encoding

class PositionEncode(T.nn.Module):
  def __init__(self, n_features):
    super(PositionEncode, self).__init__()  # old syntax
    self.nf = n_features
    self.pe = T.zeros(n_features, dtype=T.float32)
    for i in range(n_features):
      self.pe[i] = i * (0.01 / n_features)  # no sin, cos

  def forward(self, x):
    for i in range(len(x)):
      for j in range(len(x[0])):
        x[i][j] += self.pe[j]
    return x

# -----------------------------------------------------------

# classic NLP positional encoding, PyTorch documentation

class PositionalEncoding(T.nn.Module):
  def __init__(self, d_model: int, dropout: float=0.1,
   max_len: int=5000):
    super(PositionalEncoding, self).__init__()  # old syntax
    self.dropout = T.nn.Dropout(p=dropout)
    pe = T.zeros(max_len, d_model)  # like 10x4
    position = \
      T.arange(0, max_len, dtype=T.float).unsqueeze(1)
    div_term = T.exp(T.arange(0, d_model, 2).float() * \
      (-np.log(10_000.0) / d_model))
    pe[:, 0::2] = T.sin(position * div_term)
    pe[:, 1::2] = T.cos(position * div_term)
    pe = pe.unsqueeze(0).transpose(0, 1)
    self.register_buffer('pe', pe)  # allows state-save

  def forward(self, x):
    x = x + self.pe[:x.size(0), :]
    return self.dropout(x)

# -----------------------------------------------------------

class TransformerNet(T.nn.Module):
  def __init__(self):

    super(TransformerNet, self).__init__()
    self.embed = SkipLinear(6, 24)  # 6 inputs, each goes to 4
    # self.pos_enc = \
    #   PositionEncode(24)  # simplified positional
    self.pos_enc = \
      PositionalEncoding(4, dropout=0.01)  # NLP positional
    self.enc_layer = T.nn.TransformerEncoderLayer(d_model=4,
      nhead=2, dim_feedforward=10,
      batch_first=True)  # d_model divisible by nhead
    self.trans_enc = T.nn.TransformerEncoder(self.enc_layer,
      num_layers=2)  # 6 layers is default

    self.fc1 = T.nn.Linear(24, 10)  # 6--24-PE-T-10-10-1
    self.fc2 = T.nn.Linear(10, 10)
    self.fc3 = T.nn.Linear(10, 1)

    # default weight and bias initialization

  def forward(self, x):
    z = self.embed(x)  # 6 inpts to 24 embed
    z = z.reshape(-1, 6, 4)  # bat seq embed
    z = self.pos_enc(z)
    z = self.trans_enc(z)
    z = z.reshape(-1, 24)  # torch.Size([bs, xxx])
    z = T.tanh(self.fc1(z))
    z = T.tanh(self.fc2(z))
    z = self.fc3(z)  # regression: no activation
    return z

# -----------------------------------------------------------

def accuracy(model, ds, pct_close):
  # assumes model.eval()
  # correct within pct of true income
  n_correct = 0; n_wrong = 0

  for i in range(len(ds)):
    X = ds[i][0].reshape(1,-1)  # make it a batch
    Y = ds[i][1].reshape(1)
    with T.no_grad():
      oupt = model(X)         # predicted target

    if T.abs(oupt - Y) "lt" T.abs(pct_close * Y): # note
      n_correct += 1
    else:
      n_wrong += 1
  acc = (n_correct * 1.0) / (n_correct + n_wrong)
  return acc

# -----------------------------------------------------------

def mean_sq_err(model, ds):
  # assumes model.eval()
  n = len(ds)
  sum = 0.0

  for i in range(n):
    X = ds[i][0].reshape(1,-1)  # make it a batch
    y = ds[i][1].reshape(1)
    with T.no_grad():
      oupt = model(X)         # predicted target
    diff = oupt.item() - y.item()
    sum += diff * diff
  mse = sum / n
  return mse

# -----------------------------------------------------------

def train(model, ds, bs, lr, me, le):
  # dataset, bat_size, lrn_rate, max_epochs, log interval
  train_ldr = T.utils.data.DataLoader(ds, batch_size=bs,
    shuffle=True)
  loss_func = T.nn.MSELoss()
  optimizer = T.optim.Adam(model.parameters(), lr=lr)
  # optimizer = T.optim.SGD(model.parameters(), lr=lr)

  for epoch in range(0, me):
    epoch_loss = 0.0  # for one full epoch
    for (b_idx, batch) in enumerate(train_ldr):
      X = batch[0]  # predictors
      y = batch[1]  # target
      optimizer.zero_grad()
      oupt = model(X)
      loss_val = loss_func(oupt, y)  # a tensor
      epoch_loss += loss_val.item()  # accumulate
      loss_val.backward()  # compute gradients
      optimizer.step()     # update weights

    if epoch % le == 0:
      print("epoch = %4d  |  loss = %0.4f" % \
        (epoch, epoch_loss))

# -----------------------------------------------------------

def main():
  # 0. get started
  print("\nBegin Transformer regression on synthetic data ")
  print("Classic NLP position encoding (w/ dropout) module ")
  np.random.seed(0)
  T.manual_seed(0)

  # 1. load data
  print("\nLoading train (200) and test (40) data to memory ")
  train_file = ".\\Data\\synthetic_train.txt"
  train_ds = SynthDataset(train_file)  # 200 rows
  test_file = ".\\Data\\synthetic_test.txt"
  test_ds = SynthDataset(test_file)    # 40 rows
  print("Done ")

  print("\nFirst three rows of training predictors: ")
  for i in range(3):
    print(train_ds[i][0])
  print("\nFirst three target y values: ")
  for i in range(3):
    print("%0.4f " % train_ds[i][1])

  # 2. create regression model
  print("\nCreating 6--24-PE-T-(10-10)-1 regression model ")
  net = TransformerNet().to(device)

  # 3. train model
  print("\nbat_size = 10 ")
  print("loss = MSELoss() ")
  print("optimizer = Adam ")
  print("lrn_rate = 0.001 ")

  print("\nStarting training")
  net.train()
  train(net, train_ds, bs=10, lr=0.001, me=100, le=20)
  print("Done ")

  # 4. evaluate model
  net.eval()
  print("\nComputing model accuracy (within 0.10 of true) ")
  acc_train = accuracy(net, train_ds, 0.10)  # item-by-item
  print("Accuracy on train data = %0.4f" % acc_train)
  acc_test = accuracy(net, test_ds, 0.10)
  print("Accuracy on test data = %0.4f" % acc_test)

  mse_train = mean_sq_err(net, train_ds)
  print("\nMSE on train data = %0.4f" % mse_train)
  mse_test = mean_sq_err(net, test_ds)
  print("MSE on test data = %0.4f" % mse_test)

  # 5. make a prediction
  print("\nPredicting target y for train[0]: ")
  x = train_ds[0][0].reshape(1,-1)  # item - predictors

  with T.no_grad():
    y = net(x)
  pred_raw = y.item()  # scalar
  print("Predicted y = %0.4f" % pred_raw)

  # 6. TODO: save model (state_dict approach)

  print("\nEnd demo ")

# -----------------------------------------------------------

if __name__=="__main__":
  main()

Training data:

# synthetic_train.txt
#
-0.1660,  0.4406, -0.9998, -0.3953, -0.7065, -0.8153,  0.7022
-0.2065,  0.0776, -0.1616,  0.3704, -0.5911,  0.7562,  0.5666
-0.9452,  0.3409, -0.1654,  0.1174, -0.7192, -0.6038,  0.8186
 0.7528,  0.7892, -0.8299, -0.9219, -0.6603,  0.7563,  0.3687
-0.8033, -0.1578,  0.9158,  0.0663,  0.3838, -0.3690,  0.7535
-0.9634,  0.5003,  0.9777,  0.4963, -0.4391,  0.5786,  0.7076
-0.7935, -0.1042,  0.8172, -0.4128, -0.4244, -0.7399,  0.8454
-0.0169, -0.8933,  0.1482, -0.7065,  0.1786,  0.3995,  0.7302
-0.7953, -0.1719,  0.3888, -0.1716, -0.9001,  0.0718,  0.8692
 0.8892,  0.1731,  0.8068, -0.7251, -0.7214,  0.6148,  0.4740
-0.2046, -0.6693,  0.8550, -0.3045,  0.5016,  0.4520,  0.6714
 0.5019, -0.3022, -0.4601,  0.7918, -0.1438,  0.9297,  0.4331
 0.3269,  0.2434, -0.7705,  0.8990, -0.1002,  0.1568,  0.3716
 0.8068,  0.1474, -0.9943,  0.2343, -0.3467,  0.0541,  0.3829
 0.7719, -0.2855,  0.8171,  0.2467, -0.9684,  0.8589,  0.4700
 0.8652,  0.3936, -0.8680,  0.5109,  0.5078,  0.8460,  0.2648
 0.4230, -0.7515, -0.9602, -0.9476, -0.9434, -0.5076,  0.8059
 0.1056,  0.6841, -0.7517, -0.4416,  0.1715,  0.9392,  0.3512
 0.1221, -0.9627,  0.6013, -0.5341,  0.6142, -0.2243,  0.6840
 0.1125, -0.7271, -0.8802, -0.7573, -0.9109, -0.7850,  0.8640
-0.5486,  0.4260,  0.1194, -0.9749, -0.8561,  0.9346,  0.6109
-0.4953,  0.4877, -0.6091,  0.1627,  0.9400,  0.6937,  0.3382
-0.5203, -0.0125,  0.2399,  0.6580, -0.6864, -0.9628,  0.7400
 0.2127,  0.1377, -0.3653,  0.9772,  0.1595, -0.2397,  0.4081
 0.1019,  0.4907,  0.3385, -0.4702, -0.8673, -0.2598,  0.6582
 0.5055, -0.8669, -0.4794,  0.6095, -0.6131,  0.2789,  0.6644
 0.0493,  0.8496, -0.4734, -0.8681,  0.4701,  0.5444,  0.3214
 0.9004,  0.1133,  0.8312,  0.2831, -0.2200, -0.0280,  0.3149
 0.2086,  0.0991,  0.8524,  0.8375, -0.2102,  0.9265,  0.3619
-0.7298,  0.0113, -0.9570,  0.8959,  0.6542, -0.9700,  0.6451
-0.6476, -0.3359, -0.7380,  0.6190, -0.3105,  0.8802,  0.6606
 0.6895,  0.8108, -0.0802,  0.0927,  0.5972, -0.4286,  0.2427
-0.0195,  0.1982, -0.9689,  0.1870, -0.1326,  0.6147,  0.4773
 0.1557, -0.6320,  0.5759,  0.2241, -0.8922, -0.1596,  0.7581
 0.3581,  0.8372, -0.9992,  0.9535, -0.2468,  0.9476,  0.2962
 0.1494,  0.2562, -0.4288,  0.1737,  0.5000,  0.7166,  0.3513
 0.5102,  0.3961,  0.7290, -0.3546,  0.3416, -0.0983,  0.3153
-0.1970, -0.3652,  0.2438, -0.1395,  0.9476,  0.3556,  0.4719
-0.6029, -0.1466, -0.3133,  0.5953,  0.7600,  0.8077,  0.3875
-0.4953,  0.7098,  0.0554,  0.6043,  0.1450,  0.4663,  0.4739
 0.0380,  0.5418,  0.1377, -0.0686, -0.3146, -0.8636,  0.6048
 0.9656, -0.6368,  0.6237,  0.7499,  0.3768,  0.1390,  0.3705
-0.6781, -0.0662, -0.3097, -0.5499,  0.1850, -0.3755,  0.7668
-0.6141, -0.0008,  0.4572, -0.5836, -0.5039,  0.7033,  0.7301
-0.1683,  0.2334, -0.5327, -0.7961,  0.0317, -0.0457,  0.5777
 0.0880,  0.3083, -0.7109,  0.5031, -0.5559,  0.0387,  0.5118
 0.5706, -0.9553, -0.3513,  0.7458,  0.6894,  0.0769,  0.4329
-0.8025,  0.3026,  0.4070,  0.2205,  0.5992, -0.9309,  0.7098
 0.5405,  0.4635, -0.4806, -0.4859,  0.2646, -0.3094,  0.3566
 0.5655,  0.9809, -0.3995, -0.7140,  0.8026,  0.0831,  0.2551
 0.9495,  0.2732,  0.9878,  0.0921,  0.0529, -0.7291,  0.3074
-0.6792,  0.4913, -0.9392, -0.2669,  0.7247,  0.3854,  0.4362
 0.3819, -0.6227, -0.1162,  0.1632,  0.9795, -0.5922,  0.4435
 0.5003, -0.0860, -0.8861,  0.0170, -0.5761,  0.5972,  0.5136
-0.4053, -0.9448,  0.1869,  0.6877, -0.2380,  0.4997,  0.7859
 0.9189,  0.6079, -0.9354,  0.4188, -0.0700,  0.8951,  0.2696
-0.5571, -0.4659, -0.8371, -0.1428, -0.7820,  0.2676,  0.8566
 0.5324, -0.3151,  0.6917, -0.1425,  0.6480,  0.2530,  0.4252
-0.7132, -0.8432, -0.9633, -0.8666, -0.0828, -0.7733,  0.9217
-0.0952, -0.0998, -0.0439, -0.0520,  0.6063, -0.1952,  0.5140
 0.8094, -0.9259,  0.5477, -0.7487,  0.2370, -0.9793,  0.5562
 0.9024,  0.8108,  0.5919,  0.8305, -0.7089, -0.6845,  0.2993
-0.6247,  0.2450,  0.8116,  0.9799,  0.4222,  0.4636,  0.4619
-0.5003, -0.6531, -0.7611,  0.6252, -0.7064, -0.4714,  0.8452
 0.6382, -0.3788,  0.9648, -0.4667,  0.0673, -0.3711,  0.5070
-0.1328,  0.0246,  0.8778, -0.9381,  0.4338,  0.7820,  0.5680
-0.9454,  0.0441, -0.3480,  0.7190,  0.1170,  0.3805,  0.6562
-0.4198, -0.9813,  0.1535, -0.3771,  0.0345,  0.8328,  0.7707
-0.1471, -0.5052, -0.2574,  0.8637,  0.8737,  0.6887,  0.3436
-0.3712, -0.6505,  0.2142, -0.1728,  0.6327, -0.6297,  0.7430
 0.4038, -0.5193,  0.1484, -0.3020, -0.8861, -0.5424,  0.7499
 0.0380, -0.6506,  0.1414,  0.9935,  0.6337,  0.1887,  0.4509
 0.9520,  0.8031,  0.1912, -0.9351, -0.8128, -0.8693,  0.5336
 0.9507, -0.6640,  0.9456,  0.5349,  0.6485,  0.2652,  0.3616
 0.3375, -0.0462, -0.9737, -0.2940, -0.0159,  0.4602,  0.4840
-0.7247, -0.9782,  0.5166, -0.3601,  0.9688, -0.5595,  0.7751
-0.3226,  0.0478,  0.5098, -0.0723, -0.7504, -0.3750,  0.8025
 0.5403, -0.7393, -0.9542,  0.0382,  0.6200, -0.9748,  0.5359
 0.3449,  0.3736, -0.1015,  0.8296,  0.2887, -0.9895,  0.4390
 0.6608,  0.2983,  0.3474,  0.1570, -0.4518,  0.1211,  0.3624
 0.3435, -0.2951,  0.7117, -0.6099,  0.4946, -0.4208,  0.5283
 0.6154, -0.2929, -0.5726,  0.5346, -0.3827,  0.4665,  0.4907
 0.4889, -0.5572, -0.5718, -0.6021, -0.7150, -0.2458,  0.7202
-0.8389, -0.5366, -0.5847,  0.8347,  0.4226,  0.1078,  0.6391
-0.3910,  0.6697, -0.1294,  0.8469,  0.4121, -0.0439,  0.4693
-0.1376, -0.1916, -0.7065,  0.4586, -0.6225,  0.2878,  0.6695
 0.5086, -0.5785,  0.2019,  0.4979,  0.2764,  0.1943,  0.4666
 0.8906, -0.1489,  0.5644, -0.8877,  0.6705, -0.6155,  0.3480
-0.2098, -0.3998, -0.8398,  0.8093, -0.2597,  0.0614,  0.6341
-0.5871, -0.8476,  0.0158, -0.4769, -0.2859, -0.7839,  0.9006
 0.5751, -0.7868,  0.9714, -0.6457,  0.1448, -0.9103,  0.6049
 0.0558,  0.4802, -0.7001,  0.1022, -0.5668,  0.5184,  0.4612
 0.4458, -0.6469,  0.7239, -0.9604,  0.7205,  0.1178,  0.5941
 0.4339,  0.9747, -0.4438, -0.9924,  0.8678,  0.7158,  0.2627
 0.4577,  0.0334,  0.4139,  0.5611, -0.2502,  0.5406,  0.3847
-0.1963,  0.3946, -0.9938,  0.5498,  0.7928, -0.5214,  0.5025
-0.7585, -0.5594, -0.3958,  0.7661,  0.0863, -0.4266,  0.7481
 0.2277, -0.3517, -0.0853, -0.1118,  0.6563, -0.1473,  0.4798
-0.3086,  0.3499, -0.5570, -0.0655, -0.3705,  0.2537,  0.5768
 0.5689, -0.0861,  0.3125, -0.7363, -0.1340,  0.8186,  0.5035
 0.2110,  0.5335,  0.0094, -0.0039,  0.6858, -0.8644,  0.4243
 0.0357, -0.6111,  0.6959, -0.4967,  0.4015,  0.0805,  0.6611
 0.8977,  0.2487,  0.6760, -0.9841,  0.9787, -0.8446,  0.2873
-0.9821,  0.6455,  0.7224, -0.1203, -0.4885,  0.6054,  0.6908
-0.0443, -0.7313,  0.8557,  0.7919, -0.0169,  0.7134,  0.6039
-0.2040,  0.0115, -0.6209,  0.9300, -0.4116, -0.7931,  0.6495
-0.7114, -0.9718,  0.4319,  0.1290,  0.5892,  0.0142,  0.7675
 0.5557, -0.1870,  0.2955, -0.6404, -0.3564, -0.6548,  0.6295
-0.1827, -0.5172, -0.1862,  0.9504, -0.3594,  0.9650,  0.5685
 0.7150,  0.2392, -0.4959,  0.5857, -0.1341, -0.2850,  0.3585
-0.3394,  0.3947, -0.4627,  0.6166, -0.4094,  0.0882,  0.5962
 0.7768, -0.6312,  0.1707,  0.7964, -0.1078,  0.8437,  0.4243
-0.4420,  0.2177,  0.3649, -0.5436, -0.9725, -0.1666,  0.8086
 0.5595, -0.6505, -0.3161, -0.7108,  0.4335,  0.3986,  0.5846
 0.3770, -0.4932,  0.3847, -0.5454, -0.1507, -0.2562,  0.6335
 0.2633,  0.4146,  0.2272,  0.2966, -0.6601, -0.7011,  0.5653
 0.0284,  0.7507, -0.6321, -0.0743, -0.1421, -0.0054,  0.4219
-0.4762,  0.6891,  0.6007, -0.1467,  0.2140, -0.7091,  0.6098
 0.0192, -0.4061,  0.7193,  0.3432,  0.2669, -0.7505,  0.6549
 0.8966,  0.2902, -0.6966,  0.2783,  0.1313, -0.0627,  0.2876
-0.1439,  0.1985,  0.6999,  0.5022,  0.1587,  0.8494,  0.3872
 0.2473, -0.9040, -0.4308, -0.8779,  0.4070,  0.3369,  0.6825
-0.2428, -0.6236,  0.4940, -0.3192,  0.5906, -0.0242,  0.6770
 0.2885, -0.2987, -0.5416, -0.1322, -0.2351, -0.0604,  0.6106
 0.9590, -0.2712,  0.5488,  0.1055,  0.7783, -0.2901,  0.2956
-0.9129,  0.9015,  0.1128, -0.2473,  0.9901, -0.8833,  0.6500
 0.0334, -0.9378,  0.1424, -0.6391,  0.2619,  0.9618,  0.7033
 0.4169,  0.5549, -0.0103,  0.0571, -0.6984, -0.2612,  0.4935
-0.7156,  0.4538, -0.0460, -0.1022,  0.7720,  0.0552,  0.4983
-0.8560, -0.1637, -0.9485, -0.4177,  0.0070,  0.9319,  0.6445
-0.7812,  0.3461, -0.0001,  0.5542, -0.7128, -0.8336,  0.7720
-0.6166,  0.5356, -0.4194, -0.5662, -0.9666, -0.2027,  0.7401
-0.2378,  0.3187, -0.8582, -0.6948, -0.9668, -0.7724,  0.7670
-0.3579,  0.1158,  0.9869,  0.6690,  0.3992,  0.8365,  0.4184
-0.9205, -0.8593, -0.0520, -0.3017,  0.8745, -0.0209,  0.7723
-0.1067,  0.7541, -0.4928, -0.4524, -0.3433,  0.0951,  0.4645
-0.5597,  0.3429, -0.7144, -0.8118,  0.7404, -0.5263,  0.6117
 0.0516, -0.8480,  0.7483,  0.9023,  0.6250, -0.4324,  0.5987
 0.0557, -0.3212,  0.1093,  0.9488, -0.3766,  0.3376,  0.5739
-0.3484,  0.7797,  0.5034,  0.5253, -0.0610, -0.5785,  0.5365
-0.9170, -0.3563, -0.9258,  0.3877,  0.3407, -0.1391,  0.7131
-0.9203, -0.7304, -0.6132, -0.3287, -0.8954,  0.2102,  0.9329
 0.0241,  0.2349, -0.1353,  0.6954, -0.0919, -0.9692,  0.5744
 0.6460,  0.9036, -0.8982, -0.5299, -0.8733, -0.1567,  0.4425
 0.7277, -0.8368, -0.0538, -0.7489,  0.5458,  0.6828,  0.5848
-0.5212,  0.9049,  0.8878,  0.2279,  0.9470, -0.3103,  0.4255
 0.7957, -0.1308, -0.5284,  0.8817,  0.3684, -0.8702,  0.3969
 0.2099,  0.4647, -0.4931,  0.2010,  0.6292, -0.8918,  0.4620
-0.7390,  0.6849,  0.2367,  0.0626, -0.5034, -0.4098,  0.7137
-0.8711,  0.7940, -0.5932,  0.6525,  0.7635, -0.0265,  0.5705
 0.1969,  0.0545,  0.2496,  0.7101, -0.4357,  0.7675,  0.4242
-0.5460,  0.1920, -0.5211, -0.7372, -0.6763,  0.6897,  0.6769
 0.2044,  0.9271, -0.3086,  0.1913,  0.1980,  0.2314,  0.2998
-0.6149,  0.5059, -0.9854, -0.3435,  0.8352,  0.1767,  0.4497
 0.7104,  0.2093,  0.6452,  0.7590, -0.3580, -0.7541,  0.4076
-0.7465,  0.1796, -0.9279, -0.5996,  0.5766, -0.9758,  0.7713
-0.3933, -0.9572,  0.9950,  0.1641, -0.4132,  0.8579,  0.7421
 0.1757, -0.4717, -0.3894, -0.2567, -0.5111,  0.1691,  0.7088
 0.3917, -0.8561,  0.9422,  0.5061,  0.6123,  0.5033,  0.4824
-0.1087,  0.3449, -0.1025,  0.4086,  0.3633,  0.3943,  0.3760
 0.2372, -0.6980,  0.5216,  0.5621,  0.8082, -0.5325,  0.5297
-0.3589,  0.6310,  0.2271,  0.5200, -0.1447, -0.8011,  0.5903
-0.7699, -0.2532, -0.6123,  0.6415,  0.1993,  0.3777,  0.6039
-0.5298, -0.0768, -0.6028, -0.9490,  0.4588,  0.4498,  0.6159
-0.3392,  0.6870, -0.1431,  0.7294,  0.3141,  0.1621,  0.4501
 0.7889, -0.3900,  0.7419,  0.8175, -0.3403,  0.3661,  0.4087
 0.7984, -0.8486,  0.7572, -0.6183,  0.6995,  0.3342,  0.5025
 0.2707,  0.6956,  0.6437,  0.2565,  0.9126,  0.1798,  0.2331
-0.6043, -0.1413, -0.3265,  0.9839, -0.2395,  0.9854,  0.5444
-0.8509, -0.2594, -0.7532,  0.2690, -0.1722,  0.9818,  0.6516
 0.8599, -0.7015, -0.2102, -0.0768,  0.1219,  0.5607,  0.4747
-0.4760,  0.8216, -0.9555,  0.6422, -0.6231,  0.3715,  0.5485
-0.2896,  0.9484, -0.7545, -0.6249,  0.7789,  0.1668,  0.3415
-0.5931,  0.7926,  0.7462,  0.4006, -0.0590,  0.6543,  0.4781
-0.0083, -0.2730, -0.4488,  0.8495, -0.2260, -0.0142,  0.5854
-0.2335, -0.4049,  0.4352, -0.6183, -0.7636,  0.6740,  0.7596
 0.4883,  0.1810, -0.5142,  0.2465,  0.2767, -0.3449,  0.3995
-0.4922,  0.1828, -0.1424, -0.2358, -0.7466, -0.5115,  0.7968
-0.8413, -0.3943,  0.4834,  0.2300,  0.3448, -0.9832,  0.7989
-0.5382, -0.6502, -0.6300,  0.6885,  0.9652,  0.8275,  0.4353
-0.3053,  0.5604,  0.0929,  0.6329, -0.0325,  0.1799,  0.4848
 0.0740, -0.2680,  0.2086,  0.9176, -0.2144, -0.2141,  0.5856
 0.5813,  0.2902, -0.2122,  0.3779, -0.1920, -0.7278,  0.4079
-0.5641,  0.8515,  0.3793,  0.1976,  0.4933,  0.0839,  0.4716
 0.4011,  0.8611,  0.7252, -0.6651, -0.4737, -0.8568,  0.5708
-0.5785,  0.0056, -0.7901, -0.2223,  0.0760, -0.3216,  0.7252
 0.1118,  0.0735, -0.2188,  0.3925,  0.3570,  0.3746,  0.3688
 0.2262,  0.8715,  0.1938,  0.9592, -0.1180,  0.4792,  0.2952
-0.9248,  0.5295,  0.0366, -0.9894, -0.4456,  0.0697,  0.7335
 0.2992,  0.8629, -0.8505, -0.4464,  0.8385,  0.5300,  0.2702
 0.1995,  0.6659,  0.7921,  0.9454,  0.9970, -0.7207,  0.2996
-0.3066, -0.2927, -0.4923,  0.8220,  0.4513, -0.9481,  0.6617
-0.0770, -0.4374, -0.9421,  0.7694,  0.5420, -0.3405,  0.5131
-0.3842,  0.8562,  0.9538,  0.0471,  0.9039,  0.7760,  0.3215
 0.0361, -0.2545,  0.4207, -0.0887,  0.2104,  0.9808,  0.5202
-0.8220, -0.6302,  0.0537, -0.1658,  0.6013,  0.8664,  0.6598
-0.6443,  0.7201,  0.9148,  0.9189, -0.9243, -0.8848,  0.6095
-0.2880,  0.9074, -0.0461, -0.4435,  0.0060,  0.2867,  0.4025
-0.7775,  0.5161,  0.7039,  0.6885,  0.7810, -0.2363,  0.5234
-0.5484,  0.9426, -0.4308,  0.8148,  0.7811,  0.8450,  0.3479

Test data:

# synthetic_test.txt
#
-0.6877,  0.7594,  0.2640, -0.5787, -0.3098, -0.6802,  0.7071
-0.6694, -0.6056,  0.3821,  0.1476,  0.7466, -0.5107,  0.7282
 0.2592, -0.9311,  0.0324,  0.7265,  0.9683, -0.9803,  0.5832
-0.9049, -0.9797, -0.0196, -0.9090, -0.4433,  0.2799,  0.9018
-0.4106, -0.4607,  0.1811, -0.2389,  0.4050, -0.0078,  0.6916
-0.4259, -0.7336,  0.8742,  0.6097,  0.8761, -0.6292,  0.6728
 0.8663,  0.8715, -0.4329, -0.4507,  0.1029, -0.6294,  0.2936
 0.8948, -0.0124,  0.9278,  0.2899, -0.0314,  0.9354,  0.3160
-0.7136,  0.2647,  0.3238, -0.1323, -0.8813, -0.0146,  0.8133
-0.4867, -0.2171, -0.5197,  0.3729,  0.9798, -0.6451,  0.5820
 0.6429, -0.5380, -0.8840, -0.7224,  0.8703,  0.7771,  0.5777
 0.6999, -0.1307, -0.0639,  0.2597, -0.6839, -0.9704,  0.5796
-0.4690, -0.9691,  0.3490,  0.1029, -0.3567,  0.5604,  0.8151
-0.4154, -0.6081, -0.8241,  0.7400, -0.8236,  0.3674,  0.7881
-0.7592, -0.9786,  0.1145,  0.8142,  0.7209, -0.3231,  0.6968
 0.3393,  0.6156,  0.7950, -0.0923,  0.1157,  0.0123,  0.3229
 0.3840,  0.3658,  0.0406,  0.6569,  0.0116,  0.6497,  0.2879
 0.9397,  0.4839, -0.4804,  0.1625,  0.9105, -0.8385,  0.2410
-0.8329,  0.2383, -0.5510,  0.5304,  0.1363,  0.3324,  0.5862
-0.8255, -0.2579,  0.3443, -0.6208,  0.7915,  0.8997,  0.6109
 0.9231,  0.4602, -0.1874,  0.4875, -0.4240, -0.3712,  0.3165
 0.7573, -0.4908,  0.5324,  0.8820, -0.9979, -0.0478,  0.6093
 0.3141,  0.6866, -0.6325,  0.7123, -0.2713,  0.7845,  0.3050
-0.1647, -0.6616,  0.2998, -0.9260, -0.3768, -0.3530,  0.8315
 0.2149,  0.3017,  0.6921,  0.8552,  0.3209,  0.1563,  0.3157
-0.6918,  0.7902, -0.3780,  0.0970,  0.3641, -0.5271,  0.6323
-0.6645,  0.0170,  0.5837,  0.3848, -0.7621,  0.8015,  0.7440
 0.1069, -0.8304, -0.5951,  0.7085,  0.4119,  0.7899,  0.4998
-0.3417,  0.0560,  0.3008,  0.1886, -0.5371, -0.1464,  0.7339
 0.9734, -0.8669,  0.4279, -0.3398,  0.2509, -0.4837,  0.4665
 0.3020, -0.2577, -0.4104,  0.8235,  0.8850,  0.2271,  0.3066
-0.5766,  0.6603, -0.5198,  0.2632,  0.4215,  0.4848,  0.4478
-0.2195,  0.5197,  0.8059,  0.1748, -0.8192, -0.7420,  0.6740
-0.9212, -0.5169,  0.7581,  0.9470,  0.2108,  0.9525,  0.6180
-0.9131,  0.8971, -0.3774,  0.5979,  0.6213,  0.7200,  0.4642
-0.4842,  0.8689,  0.2382,  0.9709, -0.9347,  0.4503,  0.5662
 0.1311, -0.0152, -0.4816, -0.3463, -0.5011, -0.5615,  0.6979
-0.8336,  0.5540,  0.0673,  0.4788,  0.0308, -0.2001,  0.6917
 0.9725, -0.9435,  0.8655,  0.8617, -0.2182, -0.5711,  0.6021
 0.6064, -0.4921, -0.4184,  0.8318,  0.8058,  0.0708,  0.3221
