I’ve been looking at adding a Transformer module to a PyTorch regression network. Because the key functionality of a Transformer is the attention mechanism, I’ve also been looking at adding a custom Attention module instead of a Transformer.

There are dozens of design alternatives, and many architecture and training hyperparameters. For the baseline architecture against which I’m comparing, I use a standard PyTorch TransformerEncoder layer, a numeric pseudo-embedding layer, and a simplified positional encoding layer. This is the fifth of a series of design investigations.

All of my ideas are based on natural language processing systems. In NLP, each word/token is mapped to an integer, such as “rose” = 4629. Then the integer is mapped to a vector of real values, typically about 100-1000 values — the embedding. The idea is to capture different dimensions of the meanings of the source word/token, such as rose is a type of flower, or girl’s name, or the act of standing up. After embedding, in an NLP system positional encoding is necessary because the order of words in a sentence is critical. I intend to examine the architecture options as best I can.

For this investigation, compared to the baseline architecture, I’m replacing the numeric pseudo-embedding with a fully connected linear layer, and I’m replacing the simplified positional encoding with the standard NLP-style positional encoding designed for very long input sequences. My working hypothesis going in was that the architecture would result in a model similar to one with linear layer quasi-embedding and simplified positional encoding. I was essentially correct. Implication: when using a Transformer for numeric regression scenarios, there does not seem to be an advantage to using the complex NLP style positional encoding.

A diagram of a 6-L12-PE-T-(8-8)-1 system, not the 6-L24-PE-T-(10-10)-1 system of the demo.

The demo uses one of my standard synthetic datasets. The data looks like:

-0.1660,  0.4406, -0.9998, -0.3953, -0.7065, -0.8153,  0.7022
-0.2065,  0.0776, -0.1616,  0.3704, -0.5911,  0.7562,  0.5666
-0.9452,  0.3409, -0.1654,  0.1174, -0.7192, -0.6038,  0.8186
 0.7528,  0.7892, -0.8299, -0.9219, -0.6603,  0.7563,  0.3687
. . .

The first six values on each line are predictors. The last value on each line is the target to predict. The data was generated by a 6-10-1 neural network with random weights and biases. There are 200 training items and 40 test items.

The baseline architecture is 6-24-PE-T-(10-10)-1 meaning 6 inputs, each to 4 embedding, plus simplified positional encoding, fed to a Transformer, sent to two hidden layers of 10 nodes each, sent to a single output prediction node. The demo architecture explored in this blog post is 6-L24-PE-T-(10-10)-1 meaning 6 inputs, fed to fully connected layer of 24 nodes in place of an embedding layer, NLP style positional encoding added, sent to a Transformer (with embedding dimension set to 4), sent to two fully connected layers with 10 nodes each, sent to a single output node.

A somewhat annoying factor is tyhat the standard NLP style positional encoding layer has a built-in dropout layer with a default value of 0.10. THat value didn’t work very well. After a bit of experimentation, I found that setting the dropout to 0.0 gave the best results.

Here’s the output of one demo run:

Begin Transformer regression on synthetic data
Linear layer pseudo-embedding, classic NLP positional encoding

Loading train (200) and test (40) data to memory
Done

First three rows of training predictors:
tensor([-0.1660,  0.4406, -0.9998, -0.3953, -0.7065, -0.8153])
tensor([-0.2065,  0.0776, -0.1616,  0.3704, -0.5911,  0.7562])
tensor([-0.9452,  0.3409, -0.1654,  0.1174, -0.7192, -0.6038])

First three target y values:
0.7022
0.5666
0.8186

Creating 6--L24-CPE-T-(10-10)-1 regression model

bat_size = 10
loss = MSELoss()
optimizer = Adam
lrn_rate = 0.001

Starting training
epoch =    0  |  loss = 8.2167
epoch =   20  |  loss = 0.1485
epoch =   40  |  loss = 0.0533
epoch =   60  |  loss = 0.0441
epoch =   80  |  loss = 0.0309
Done

Computing model accuracy (within 0.10 of true)
Accuracy on train data = 0.8650
Accuracy on test data = 0.7000

MSE on train data = 0.0011
MSE on test data = 0.0019

Predicting target y for train[0]:
Predicted y = 0.6859

End demo

The model accuracy (86.5% = 173 out of 200 correct on the training data) and mean squared error (0.0011 on training data) were essentially equivalent to the baseline architecture (84% accuracy and MSE = 0.0012).

Another interesting experiment.

I essentially learned to read from comic books. Pretty much everyone is familiar with the common transformations: Clark Kent into Superman, Peter Parker into Spiderman, Bruce Wayne into Batman, and so on.

Right: The Atom was Dr. Ray Palmer who could transform into a small hero using a device he invented powered by white dwarf star matter. The comic first appeared in 1962.

Demo code. Replace “lt” (less than) with Boolean operator symbol (my blog editor chokes on symbols).

# synthetic_transformer_linear_embed_nlp_pe.py

# regression with Transformer and linear layer embedding,
# (complex) NLP positional encoding on a synthetic dataset
# PyTorch 2.3.1-CPU  Anaconda3-2023.09  Python 3.11.5
# Windows 10/11

import numpy as np
import torch as T  # non-standard alias

device = T.device('cpu')  # apply to Tensor or Module

# -----------------------------------------------------------

class SynthDataset(T.utils.data.Dataset):
  # six predictors followed by target
  def __init__(self, src_file):
    tmp_x = np.loadtxt(src_file, delimiter=",",
      usecols=[0,1,2,3,4,5], dtype=np.float32)
    tmp_y = np.loadtxt(src_file, usecols=6, delimiter=",",
      dtype=np.float32)
    tmp_y = tmp_y.reshape(-1,1)  # 2D required

    self.x_data = T.tensor(tmp_x, dtype=T.float32).to(device)
    self.y_data = T.tensor(tmp_y, dtype=T.float32).to(device)

  def __len__(self):
    return len(self.x_data)

  def __getitem__(self, idx):
    preds = self.x_data[idx]
    trgts = self.y_data[idx]
    return (preds, trgts)  # as a tuple

# -----------------------------------------------------------
# simplified positional encoding

class PositionEncode(T.nn.Module):
  def __init__(self, n_features):
    super(PositionEncode, self).__init__()  # old syntax
    self.nf = n_features
    self.pe = T.zeros(n_features, dtype=T.float32)
    for i in range(n_features):
      self.pe[i] = i * (0.01 / n_features)  # no sin, cos

  def forward(self, x):
    for i in range(len(x)):
      for j in range(len(x[0])):
        x[i][j] += self.pe[j]
    return x

# -----------------------------------------------------------
# classic NLP positional encoding, PyTorch documentation

class PositionalEncoding(T.nn.Module):
  def __init__(self, d_model: int, dropout: float=0.1,
   max_len: int=5000):
    super(PositionalEncoding, self).__init__()  # old syntax
    self.dropout = T.nn.Dropout(p=dropout)
    pe = T.zeros(max_len, d_model)  # like 10x4
    position = \
      T.arange(0, max_len, dtype=T.float).unsqueeze(1)
    div_term = T.exp(T.arange(0, d_model, 2).float() * \
      (-np.log(10_000.0) / d_model))
    pe[:, 0::2] = T.sin(position * div_term)
    pe[:, 1::2] = T.cos(position * div_term)
    pe = pe.unsqueeze(0).transpose(0, 1)
    self.register_buffer('pe', pe)  # allows state-save

  def forward(self, x):
    x = x + self.pe[:x.size(0), :]
    return self.dropout(x)

# -----------------------------------------------------------

class TransformerNet(T.nn.Module):
  def __init__(self):
    super(TransformerNet, self).__init__()
    self.linear_embed = T.nn.Linear(6, 24)  # 6 to 4 each

    # self.pos_enc = PositionEncode(24)  # positional
    self.pos_enc = \
      PositionalEncoding(4, dropout=0.0)  # NLP positional

    self.enc_layer = T.nn.TransformerEncoderLayer(d_model=4,
      nhead=2, dim_feedforward=10,
      batch_first=True)  # d_model divisible by nhead
    self.trans_enc = T.nn.TransformerEncoder(self.enc_layer,
      num_layers=2)  # 6 layers is default

    self.fc1 = T.nn.Linear(24, 10)  # 6--24-PE-T-10-10-1
    self.fc2 = T.nn.Linear(10, 10)
    self.fc3 = T.nn.Linear(10, 1)

    # default weight and bias initialization

  def forward(self, x):
    z = self.linear_embed(x)  # 6 inpts to 24 pseudo-embed
    z = z.reshape(-1, 6, 4)  # bat seq embed
    z = self.pos_enc(z)  # dim = 4
    z = self.trans_enc(z)
    z = z.reshape(-1, 24)  # torch.Size([bs, xxx])
    z = T.tanh(self.fc1(z))
    z = T.tanh(self.fc2(z))
    z = self.fc3(z)  # regression: no activation
    return z

# -----------------------------------------------------------

def accuracy(model, ds, pct_close):
  # assumes model.eval()
  # correct within pct of true income
  n_correct = 0; n_wrong = 0

  for i in range(len(ds)):
    X = ds[i][0].reshape(1,-1)  # make it a batch
    Y = ds[i][1].reshape(1)
    with T.no_grad():
      oupt = model(X)         # predicted target

    if T.abs(oupt - Y) "lt" T.abs(pct_close * Y):
      n_correct += 1
    else:
      n_wrong += 1
  acc = (n_correct * 1.0) / (n_correct + n_wrong)
  return acc

# -----------------------------------------------------------

def mean_sq_err(model, ds):
  # assumes model.eval()
  n = len(ds)
  sum = 0.0

  for i in range(n):
    X = ds[i][0].reshape(1,-1)  # make it a batch
    y = ds[i][1].reshape(1)
    with T.no_grad():
      oupt = model(X)         # predicted target
    diff = oupt.item() - y.item()
    sum += diff * diff
  mse = sum / n
  return mse

# -----------------------------------------------------------

def train(model, ds, bs, lr, me, le):
  # dataset, bat_size, lrn_rate, max_epochs, log interval
  train_ldr = T.utils.data.DataLoader(ds, batch_size=bs,
    shuffle=True)
  loss_func = T.nn.MSELoss()
  optimizer = T.optim.Adam(model.parameters(), lr=lr)
  # optimizer = T.optim.SGD(model.parameters(), lr=lr)

  for epoch in range(0, me):
    epoch_loss = 0.0  # for one full epoch
    for (b_idx, batch) in enumerate(train_ldr):
      X = batch[0]  # predictors
      y = batch[1]  # target
      optimizer.zero_grad()
      oupt = model(X)
      loss_val = loss_func(oupt, y)  # a tensor
      epoch_loss += loss_val.item()  # accumulate
      loss_val.backward()  # compute gradients
      optimizer.step()     # update weights

    if epoch % le == 0:
      print("epoch = %4d  |  loss = %0.4f" % \
        (epoch, epoch_loss))

# -----------------------------------------------------------

def main():
  # 0. get started
  print("\nBegin Transformer regression on synthetic data ")
  print("Linear layer pseudo-embedding, classic " + \
    "NLP positional encoding ")
  np.random.seed(0)
  T.manual_seed(0)

  # 1. load data
  print("\nLoading train (200) and test (40) data to memory ")
  train_file = ".\\Data\\synthetic_train.txt"
  train_ds = SynthDataset(train_file)  # 200 rows
  test_file = ".\\Data\\synthetic_test.txt"
  test_ds = SynthDataset(test_file)    # 40 rows
  print("Done ")

  print("\nFirst three rows of training predictors: ")
  for i in range(3):
    print(train_ds[i][0])
  print("\nFirst three target y values: ")
  for i in range(3):
    print("%0.4f " % train_ds[i][1])

  # 2. create regression model
  print("\nCreating 6--L24-CPE-T-(10-10)-1 regression model ")
  net = TransformerNet().to(device)

  # 3. train model
  print("\nbat_size = 10 ")
  print("loss = MSELoss() ")
  print("optimizer = Adam ")
  print("lrn_rate = 0.001 ")

  print("\nStarting training")
  net.train()
  train(net, train_ds, bs=10, lr=0.001, me=100, le=20)
  print("Done ")

  # 4. evaluate model
  net.eval()
  print("\nComputing model accuracy (within 0.10 of true) ")
  acc_train = accuracy(net, train_ds, 0.10)  # item-by-item
  print("Accuracy on train data = %0.4f" % acc_train)
  acc_test = accuracy(net, test_ds, 0.10)
  print("Accuracy on test data = %0.4f" % acc_test)

  mse_train = mean_sq_err(net, train_ds)
  print("\nMSE on train data = %0.4f" % mse_train)
  mse_test = mean_sq_err(net, test_ds)
  print("MSE on test data = %0.4f" % mse_test)

  # 5. make a prediction
  print("\nPredicting target y for train[0]: ")
  x = train_ds[0][0].reshape(1,-1)  # item - predictors

  with T.no_grad():
    y = net(x)
  pred_raw = y.item()  # scalar
  print("Predicted y = %0.4f" % pred_raw)

  # 6. TODO: save model (state_dict approach)

  print("\nEnd demo ")

# -----------------------------------------------------------

if __name__=="__main__":
  main()

Training data:

# synthetic_train.txt
#
-0.1660,  0.4406, -0.9998, -0.3953, -0.7065, -0.8153,  0.7022
-0.2065,  0.0776, -0.1616,  0.3704, -0.5911,  0.7562,  0.5666
-0.9452,  0.3409, -0.1654,  0.1174, -0.7192, -0.6038,  0.8186
 0.7528,  0.7892, -0.8299, -0.9219, -0.6603,  0.7563,  0.3687
-0.8033, -0.1578,  0.9158,  0.0663,  0.3838, -0.3690,  0.7535
-0.9634,  0.5003,  0.9777,  0.4963, -0.4391,  0.5786,  0.7076
-0.7935, -0.1042,  0.8172, -0.4128, -0.4244, -0.7399,  0.8454
-0.0169, -0.8933,  0.1482, -0.7065,  0.1786,  0.3995,  0.7302
-0.7953, -0.1719,  0.3888, -0.1716, -0.9001,  0.0718,  0.8692
 0.8892,  0.1731,  0.8068, -0.7251, -0.7214,  0.6148,  0.4740
-0.2046, -0.6693,  0.8550, -0.3045,  0.5016,  0.4520,  0.6714
 0.5019, -0.3022, -0.4601,  0.7918, -0.1438,  0.9297,  0.4331
 0.3269,  0.2434, -0.7705,  0.8990, -0.1002,  0.1568,  0.3716
 0.8068,  0.1474, -0.9943,  0.2343, -0.3467,  0.0541,  0.3829
 0.7719, -0.2855,  0.8171,  0.2467, -0.9684,  0.8589,  0.4700
 0.8652,  0.3936, -0.8680,  0.5109,  0.5078,  0.8460,  0.2648
 0.4230, -0.7515, -0.9602, -0.9476, -0.9434, -0.5076,  0.8059
 0.1056,  0.6841, -0.7517, -0.4416,  0.1715,  0.9392,  0.3512
 0.1221, -0.9627,  0.6013, -0.5341,  0.6142, -0.2243,  0.6840
 0.1125, -0.7271, -0.8802, -0.7573, -0.9109, -0.7850,  0.8640
-0.5486,  0.4260,  0.1194, -0.9749, -0.8561,  0.9346,  0.6109
-0.4953,  0.4877, -0.6091,  0.1627,  0.9400,  0.6937,  0.3382
-0.5203, -0.0125,  0.2399,  0.6580, -0.6864, -0.9628,  0.7400
 0.2127,  0.1377, -0.3653,  0.9772,  0.1595, -0.2397,  0.4081
 0.1019,  0.4907,  0.3385, -0.4702, -0.8673, -0.2598,  0.6582
 0.5055, -0.8669, -0.4794,  0.6095, -0.6131,  0.2789,  0.6644
 0.0493,  0.8496, -0.4734, -0.8681,  0.4701,  0.5444,  0.3214
 0.9004,  0.1133,  0.8312,  0.2831, -0.2200, -0.0280,  0.3149
 0.2086,  0.0991,  0.8524,  0.8375, -0.2102,  0.9265,  0.3619
-0.7298,  0.0113, -0.9570,  0.8959,  0.6542, -0.9700,  0.6451
-0.6476, -0.3359, -0.7380,  0.6190, -0.3105,  0.8802,  0.6606
 0.6895,  0.8108, -0.0802,  0.0927,  0.5972, -0.4286,  0.2427
-0.0195,  0.1982, -0.9689,  0.1870, -0.1326,  0.6147,  0.4773
 0.1557, -0.6320,  0.5759,  0.2241, -0.8922, -0.1596,  0.7581
 0.3581,  0.8372, -0.9992,  0.9535, -0.2468,  0.9476,  0.2962
 0.1494,  0.2562, -0.4288,  0.1737,  0.5000,  0.7166,  0.3513
 0.5102,  0.3961,  0.7290, -0.3546,  0.3416, -0.0983,  0.3153
-0.1970, -0.3652,  0.2438, -0.1395,  0.9476,  0.3556,  0.4719
-0.6029, -0.1466, -0.3133,  0.5953,  0.7600,  0.8077,  0.3875
-0.4953,  0.7098,  0.0554,  0.6043,  0.1450,  0.4663,  0.4739
 0.0380,  0.5418,  0.1377, -0.0686, -0.3146, -0.8636,  0.6048
 0.9656, -0.6368,  0.6237,  0.7499,  0.3768,  0.1390,  0.3705
-0.6781, -0.0662, -0.3097, -0.5499,  0.1850, -0.3755,  0.7668
-0.6141, -0.0008,  0.4572, -0.5836, -0.5039,  0.7033,  0.7301
-0.1683,  0.2334, -0.5327, -0.7961,  0.0317, -0.0457,  0.5777
 0.0880,  0.3083, -0.7109,  0.5031, -0.5559,  0.0387,  0.5118
 0.5706, -0.9553, -0.3513,  0.7458,  0.6894,  0.0769,  0.4329
-0.8025,  0.3026,  0.4070,  0.2205,  0.5992, -0.9309,  0.7098
 0.5405,  0.4635, -0.4806, -0.4859,  0.2646, -0.3094,  0.3566
 0.5655,  0.9809, -0.3995, -0.7140,  0.8026,  0.0831,  0.2551
 0.9495,  0.2732,  0.9878,  0.0921,  0.0529, -0.7291,  0.3074
-0.6792,  0.4913, -0.9392, -0.2669,  0.7247,  0.3854,  0.4362
 0.3819, -0.6227, -0.1162,  0.1632,  0.9795, -0.5922,  0.4435
 0.5003, -0.0860, -0.8861,  0.0170, -0.5761,  0.5972,  0.5136
-0.4053, -0.9448,  0.1869,  0.6877, -0.2380,  0.4997,  0.7859
 0.9189,  0.6079, -0.9354,  0.4188, -0.0700,  0.8951,  0.2696
-0.5571, -0.4659, -0.8371, -0.1428, -0.7820,  0.2676,  0.8566
 0.5324, -0.3151,  0.6917, -0.1425,  0.6480,  0.2530,  0.4252
-0.7132, -0.8432, -0.9633, -0.8666, -0.0828, -0.7733,  0.9217
-0.0952, -0.0998, -0.0439, -0.0520,  0.6063, -0.1952,  0.5140
 0.8094, -0.9259,  0.5477, -0.7487,  0.2370, -0.9793,  0.5562
 0.9024,  0.8108,  0.5919,  0.8305, -0.7089, -0.6845,  0.2993
-0.6247,  0.2450,  0.8116,  0.9799,  0.4222,  0.4636,  0.4619
-0.5003, -0.6531, -0.7611,  0.6252, -0.7064, -0.4714,  0.8452
 0.6382, -0.3788,  0.9648, -0.4667,  0.0673, -0.3711,  0.5070
-0.1328,  0.0246,  0.8778, -0.9381,  0.4338,  0.7820,  0.5680
-0.9454,  0.0441, -0.3480,  0.7190,  0.1170,  0.3805,  0.6562
-0.4198, -0.9813,  0.1535, -0.3771,  0.0345,  0.8328,  0.7707
-0.1471, -0.5052, -0.2574,  0.8637,  0.8737,  0.6887,  0.3436
-0.3712, -0.6505,  0.2142, -0.1728,  0.6327, -0.6297,  0.7430
 0.4038, -0.5193,  0.1484, -0.3020, -0.8861, -0.5424,  0.7499
 0.0380, -0.6506,  0.1414,  0.9935,  0.6337,  0.1887,  0.4509
 0.9520,  0.8031,  0.1912, -0.9351, -0.8128, -0.8693,  0.5336
 0.9507, -0.6640,  0.9456,  0.5349,  0.6485,  0.2652,  0.3616
 0.3375, -0.0462, -0.9737, -0.2940, -0.0159,  0.4602,  0.4840
-0.7247, -0.9782,  0.5166, -0.3601,  0.9688, -0.5595,  0.7751
-0.3226,  0.0478,  0.5098, -0.0723, -0.7504, -0.3750,  0.8025
 0.5403, -0.7393, -0.9542,  0.0382,  0.6200, -0.9748,  0.5359
 0.3449,  0.3736, -0.1015,  0.8296,  0.2887, -0.9895,  0.4390
 0.6608,  0.2983,  0.3474,  0.1570, -0.4518,  0.1211,  0.3624
 0.3435, -0.2951,  0.7117, -0.6099,  0.4946, -0.4208,  0.5283
 0.6154, -0.2929, -0.5726,  0.5346, -0.3827,  0.4665,  0.4907
 0.4889, -0.5572, -0.5718, -0.6021, -0.7150, -0.2458,  0.7202
-0.8389, -0.5366, -0.5847,  0.8347,  0.4226,  0.1078,  0.6391
-0.3910,  0.6697, -0.1294,  0.8469,  0.4121, -0.0439,  0.4693
-0.1376, -0.1916, -0.7065,  0.4586, -0.6225,  0.2878,  0.6695
 0.5086, -0.5785,  0.2019,  0.4979,  0.2764,  0.1943,  0.4666
 0.8906, -0.1489,  0.5644, -0.8877,  0.6705, -0.6155,  0.3480
-0.2098, -0.3998, -0.8398,  0.8093, -0.2597,  0.0614,  0.6341
-0.5871, -0.8476,  0.0158, -0.4769, -0.2859, -0.7839,  0.9006
 0.5751, -0.7868,  0.9714, -0.6457,  0.1448, -0.9103,  0.6049
 0.0558,  0.4802, -0.7001,  0.1022, -0.5668,  0.5184,  0.4612
 0.4458, -0.6469,  0.7239, -0.9604,  0.7205,  0.1178,  0.5941
 0.4339,  0.9747, -0.4438, -0.9924,  0.8678,  0.7158,  0.2627
 0.4577,  0.0334,  0.4139,  0.5611, -0.2502,  0.5406,  0.3847
-0.1963,  0.3946, -0.9938,  0.5498,  0.7928, -0.5214,  0.5025
-0.7585, -0.5594, -0.3958,  0.7661,  0.0863, -0.4266,  0.7481
 0.2277, -0.3517, -0.0853, -0.1118,  0.6563, -0.1473,  0.4798
-0.3086,  0.3499, -0.5570, -0.0655, -0.3705,  0.2537,  0.5768
 0.5689, -0.0861,  0.3125, -0.7363, -0.1340,  0.8186,  0.5035
 0.2110,  0.5335,  0.0094, -0.0039,  0.6858, -0.8644,  0.4243
 0.0357, -0.6111,  0.6959, -0.4967,  0.4015,  0.0805,  0.6611
 0.8977,  0.2487,  0.6760, -0.9841,  0.9787, -0.8446,  0.2873
-0.9821,  0.6455,  0.7224, -0.1203, -0.4885,  0.6054,  0.6908
-0.0443, -0.7313,  0.8557,  0.7919, -0.0169,  0.7134,  0.6039
-0.2040,  0.0115, -0.6209,  0.9300, -0.4116, -0.7931,  0.6495
-0.7114, -0.9718,  0.4319,  0.1290,  0.5892,  0.0142,  0.7675
 0.5557, -0.1870,  0.2955, -0.6404, -0.3564, -0.6548,  0.6295
-0.1827, -0.5172, -0.1862,  0.9504, -0.3594,  0.9650,  0.5685
 0.7150,  0.2392, -0.4959,  0.5857, -0.1341, -0.2850,  0.3585
-0.3394,  0.3947, -0.4627,  0.6166, -0.4094,  0.0882,  0.5962
 0.7768, -0.6312,  0.1707,  0.7964, -0.1078,  0.8437,  0.4243
-0.4420,  0.2177,  0.3649, -0.5436, -0.9725, -0.1666,  0.8086
 0.5595, -0.6505, -0.3161, -0.7108,  0.4335,  0.3986,  0.5846
 0.3770, -0.4932,  0.3847, -0.5454, -0.1507, -0.2562,  0.6335
 0.2633,  0.4146,  0.2272,  0.2966, -0.6601, -0.7011,  0.5653
 0.0284,  0.7507, -0.6321, -0.0743, -0.1421, -0.0054,  0.4219
-0.4762,  0.6891,  0.6007, -0.1467,  0.2140, -0.7091,  0.6098
 0.0192, -0.4061,  0.7193,  0.3432,  0.2669, -0.7505,  0.6549
 0.8966,  0.2902, -0.6966,  0.2783,  0.1313, -0.0627,  0.2876
-0.1439,  0.1985,  0.6999,  0.5022,  0.1587,  0.8494,  0.3872
 0.2473, -0.9040, -0.4308, -0.8779,  0.4070,  0.3369,  0.6825
-0.2428, -0.6236,  0.4940, -0.3192,  0.5906, -0.0242,  0.6770
 0.2885, -0.2987, -0.5416, -0.1322, -0.2351, -0.0604,  0.6106
 0.9590, -0.2712,  0.5488,  0.1055,  0.7783, -0.2901,  0.2956
-0.9129,  0.9015,  0.1128, -0.2473,  0.9901, -0.8833,  0.6500
 0.0334, -0.9378,  0.1424, -0.6391,  0.2619,  0.9618,  0.7033
 0.4169,  0.5549, -0.0103,  0.0571, -0.6984, -0.2612,  0.4935
-0.7156,  0.4538, -0.0460, -0.1022,  0.7720,  0.0552,  0.4983
-0.8560, -0.1637, -0.9485, -0.4177,  0.0070,  0.9319,  0.6445
-0.7812,  0.3461, -0.0001,  0.5542, -0.7128, -0.8336,  0.7720
-0.6166,  0.5356, -0.4194, -0.5662, -0.9666, -0.2027,  0.7401
-0.2378,  0.3187, -0.8582, -0.6948, -0.9668, -0.7724,  0.7670
-0.3579,  0.1158,  0.9869,  0.6690,  0.3992,  0.8365,  0.4184
-0.9205, -0.8593, -0.0520, -0.3017,  0.8745, -0.0209,  0.7723
-0.1067,  0.7541, -0.4928, -0.4524, -0.3433,  0.0951,  0.4645
-0.5597,  0.3429, -0.7144, -0.8118,  0.7404, -0.5263,  0.6117
 0.0516, -0.8480,  0.7483,  0.9023,  0.6250, -0.4324,  0.5987
 0.0557, -0.3212,  0.1093,  0.9488, -0.3766,  0.3376,  0.5739
-0.3484,  0.7797,  0.5034,  0.5253, -0.0610, -0.5785,  0.5365
-0.9170, -0.3563, -0.9258,  0.3877,  0.3407, -0.1391,  0.7131
-0.9203, -0.7304, -0.6132, -0.3287, -0.8954,  0.2102,  0.9329
 0.0241,  0.2349, -0.1353,  0.6954, -0.0919, -0.9692,  0.5744
 0.6460,  0.9036, -0.8982, -0.5299, -0.8733, -0.1567,  0.4425
 0.7277, -0.8368, -0.0538, -0.7489,  0.5458,  0.6828,  0.5848
-0.5212,  0.9049,  0.8878,  0.2279,  0.9470, -0.3103,  0.4255
 0.7957, -0.1308, -0.5284,  0.8817,  0.3684, -0.8702,  0.3969
 0.2099,  0.4647, -0.4931,  0.2010,  0.6292, -0.8918,  0.4620
-0.7390,  0.6849,  0.2367,  0.0626, -0.5034, -0.4098,  0.7137
-0.8711,  0.7940, -0.5932,  0.6525,  0.7635, -0.0265,  0.5705
 0.1969,  0.0545,  0.2496,  0.7101, -0.4357,  0.7675,  0.4242
-0.5460,  0.1920, -0.5211, -0.7372, -0.6763,  0.6897,  0.6769
 0.2044,  0.9271, -0.3086,  0.1913,  0.1980,  0.2314,  0.2998
-0.6149,  0.5059, -0.9854, -0.3435,  0.8352,  0.1767,  0.4497
 0.7104,  0.2093,  0.6452,  0.7590, -0.3580, -0.7541,  0.4076
-0.7465,  0.1796, -0.9279, -0.5996,  0.5766, -0.9758,  0.7713
-0.3933, -0.9572,  0.9950,  0.1641, -0.4132,  0.8579,  0.7421
 0.1757, -0.4717, -0.3894, -0.2567, -0.5111,  0.1691,  0.7088
 0.3917, -0.8561,  0.9422,  0.5061,  0.6123,  0.5033,  0.4824
-0.1087,  0.3449, -0.1025,  0.4086,  0.3633,  0.3943,  0.3760
 0.2372, -0.6980,  0.5216,  0.5621,  0.8082, -0.5325,  0.5297
-0.3589,  0.6310,  0.2271,  0.5200, -0.1447, -0.8011,  0.5903
-0.7699, -0.2532, -0.6123,  0.6415,  0.1993,  0.3777,  0.6039
-0.5298, -0.0768, -0.6028, -0.9490,  0.4588,  0.4498,  0.6159
-0.3392,  0.6870, -0.1431,  0.7294,  0.3141,  0.1621,  0.4501
 0.7889, -0.3900,  0.7419,  0.8175, -0.3403,  0.3661,  0.4087
 0.7984, -0.8486,  0.7572, -0.6183,  0.6995,  0.3342,  0.5025
 0.2707,  0.6956,  0.6437,  0.2565,  0.9126,  0.1798,  0.2331
-0.6043, -0.1413, -0.3265,  0.9839, -0.2395,  0.9854,  0.5444
-0.8509, -0.2594, -0.7532,  0.2690, -0.1722,  0.9818,  0.6516
 0.8599, -0.7015, -0.2102, -0.0768,  0.1219,  0.5607,  0.4747
-0.4760,  0.8216, -0.9555,  0.6422, -0.6231,  0.3715,  0.5485
-0.2896,  0.9484, -0.7545, -0.6249,  0.7789,  0.1668,  0.3415
-0.5931,  0.7926,  0.7462,  0.4006, -0.0590,  0.6543,  0.4781
-0.0083, -0.2730, -0.4488,  0.8495, -0.2260, -0.0142,  0.5854
-0.2335, -0.4049,  0.4352, -0.6183, -0.7636,  0.6740,  0.7596
 0.4883,  0.1810, -0.5142,  0.2465,  0.2767, -0.3449,  0.3995
-0.4922,  0.1828, -0.1424, -0.2358, -0.7466, -0.5115,  0.7968
-0.8413, -0.3943,  0.4834,  0.2300,  0.3448, -0.9832,  0.7989
-0.5382, -0.6502, -0.6300,  0.6885,  0.9652,  0.8275,  0.4353
-0.3053,  0.5604,  0.0929,  0.6329, -0.0325,  0.1799,  0.4848
 0.0740, -0.2680,  0.2086,  0.9176, -0.2144, -0.2141,  0.5856
 0.5813,  0.2902, -0.2122,  0.3779, -0.1920, -0.7278,  0.4079
-0.5641,  0.8515,  0.3793,  0.1976,  0.4933,  0.0839,  0.4716
 0.4011,  0.8611,  0.7252, -0.6651, -0.4737, -0.8568,  0.5708
-0.5785,  0.0056, -0.7901, -0.2223,  0.0760, -0.3216,  0.7252
 0.1118,  0.0735, -0.2188,  0.3925,  0.3570,  0.3746,  0.3688
 0.2262,  0.8715,  0.1938,  0.9592, -0.1180,  0.4792,  0.2952
-0.9248,  0.5295,  0.0366, -0.9894, -0.4456,  0.0697,  0.7335
 0.2992,  0.8629, -0.8505, -0.4464,  0.8385,  0.5300,  0.2702
 0.1995,  0.6659,  0.7921,  0.9454,  0.9970, -0.7207,  0.2996
-0.3066, -0.2927, -0.4923,  0.8220,  0.4513, -0.9481,  0.6617
-0.0770, -0.4374, -0.9421,  0.7694,  0.5420, -0.3405,  0.5131
-0.3842,  0.8562,  0.9538,  0.0471,  0.9039,  0.7760,  0.3215
 0.0361, -0.2545,  0.4207, -0.0887,  0.2104,  0.9808,  0.5202
-0.8220, -0.6302,  0.0537, -0.1658,  0.6013,  0.8664,  0.6598
-0.6443,  0.7201,  0.9148,  0.9189, -0.9243, -0.8848,  0.6095
-0.2880,  0.9074, -0.0461, -0.4435,  0.0060,  0.2867,  0.4025
-0.7775,  0.5161,  0.7039,  0.6885,  0.7810, -0.2363,  0.5234
-0.5484,  0.9426, -0.4308,  0.8148,  0.7811,  0.8450,  0.3479

Test data:

# synthetic_test.txt
#
-0.6877,  0.7594,  0.2640, -0.5787, -0.3098, -0.6802,  0.7071
-0.6694, -0.6056,  0.3821,  0.1476,  0.7466, -0.5107,  0.7282
 0.2592, -0.9311,  0.0324,  0.7265,  0.9683, -0.9803,  0.5832
-0.9049, -0.9797, -0.0196, -0.9090, -0.4433,  0.2799,  0.9018
-0.4106, -0.4607,  0.1811, -0.2389,  0.4050, -0.0078,  0.6916
-0.4259, -0.7336,  0.8742,  0.6097,  0.8761, -0.6292,  0.6728
 0.8663,  0.8715, -0.4329, -0.4507,  0.1029, -0.6294,  0.2936
 0.8948, -0.0124,  0.9278,  0.2899, -0.0314,  0.9354,  0.3160
-0.7136,  0.2647,  0.3238, -0.1323, -0.8813, -0.0146,  0.8133
-0.4867, -0.2171, -0.5197,  0.3729,  0.9798, -0.6451,  0.5820
 0.6429, -0.5380, -0.8840, -0.7224,  0.8703,  0.7771,  0.5777
 0.6999, -0.1307, -0.0639,  0.2597, -0.6839, -0.9704,  0.5796
-0.4690, -0.9691,  0.3490,  0.1029, -0.3567,  0.5604,  0.8151
-0.4154, -0.6081, -0.8241,  0.7400, -0.8236,  0.3674,  0.7881
-0.7592, -0.9786,  0.1145,  0.8142,  0.7209, -0.3231,  0.6968
 0.3393,  0.6156,  0.7950, -0.0923,  0.1157,  0.0123,  0.3229
 0.3840,  0.3658,  0.0406,  0.6569,  0.0116,  0.6497,  0.2879
 0.9397,  0.4839, -0.4804,  0.1625,  0.9105, -0.8385,  0.2410
-0.8329,  0.2383, -0.5510,  0.5304,  0.1363,  0.3324,  0.5862
-0.8255, -0.2579,  0.3443, -0.6208,  0.7915,  0.8997,  0.6109
 0.9231,  0.4602, -0.1874,  0.4875, -0.4240, -0.3712,  0.3165
 0.7573, -0.4908,  0.5324,  0.8820, -0.9979, -0.0478,  0.6093
 0.3141,  0.6866, -0.6325,  0.7123, -0.2713,  0.7845,  0.3050
-0.1647, -0.6616,  0.2998, -0.9260, -0.3768, -0.3530,  0.8315
 0.2149,  0.3017,  0.6921,  0.8552,  0.3209,  0.1563,  0.3157
-0.6918,  0.7902, -0.3780,  0.0970,  0.3641, -0.5271,  0.6323
-0.6645,  0.0170,  0.5837,  0.3848, -0.7621,  0.8015,  0.7440
 0.1069, -0.8304, -0.5951,  0.7085,  0.4119,  0.7899,  0.4998
-0.3417,  0.0560,  0.3008,  0.1886, -0.5371, -0.1464,  0.7339
 0.9734, -0.8669,  0.4279, -0.3398,  0.2509, -0.4837,  0.4665
 0.3020, -0.2577, -0.4104,  0.8235,  0.8850,  0.2271,  0.3066
-0.5766,  0.6603, -0.5198,  0.2632,  0.4215,  0.4848,  0.4478
-0.2195,  0.5197,  0.8059,  0.1748, -0.8192, -0.7420,  0.6740
-0.9212, -0.5169,  0.7581,  0.9470,  0.2108,  0.9525,  0.6180
-0.9131,  0.8971, -0.3774,  0.5979,  0.6213,  0.7200,  0.4642
-0.4842,  0.8689,  0.2382,  0.9709, -0.9347,  0.4503,  0.5662
 0.1311, -0.0152, -0.4816, -0.3463, -0.5011, -0.5615,  0.6979
-0.8336,  0.5540,  0.0673,  0.4788,  0.0308, -0.2001,  0.6917
 0.9725, -0.9435,  0.8655,  0.8617, -0.2182, -0.5711,  0.6021
 0.6064, -0.4921, -0.4184,  0.8318,  0.8058,  0.0708,  0.3221
