Singular value decomposition (SVD) breaks down a matrix A into a matrix U, a vector s, and a matrix Vh, such that A = U * S * Vh. The S is a square matrix with the elements of vector s on the diagonal, 0s elsewhere.

If you want to compute the Moore-Penrose pseudo-inverse of A using SVD, it is A_pinv = V * Sinv * Uh. The V is the transpose of Vh, Sinv is S with the reciprocals of the elements, and Uh is the transpose of U.

As it turns out, the NumPy SVD function accepts a source matrix to decompose, and a strange full_matrices Boolean parameter. The default value is full_matrices=True, but in order to compute the pseudo-inverse, you must explicitly specify full_matrices=False.

Here’s a demo. It starts by setting up a matrix that has more rows than columns, such as the kind you’d find as training data in a machine learning problem. The demo computes the pseudo-inverse directly using the np.linalg.pinv() function:

import numpy as np
np.set_printoptions(precision=4, suppress=True)

A = np.array([
  [1, -2, 3],
  [-5, 0, 2],
  [8, 5, -4],
  [-1, 0, 9]])

print("\nA: ")
print(A)

print("\n============================== ")

print("\nA pinv() using np.linalg.pinv(): \n")
A_pinv = np.linalg.pinv(A)
print(A_pinv)

The output is:

A:
[[ 1 -2  3]
 [-5  0  2]
 [ 8  5 -4]
 [-1  0  9]]

==============================

A pinv() using np.linalg.pinv():

[[ 0.0979 -0.1201  0.0392  0.0115]
 [-0.1707  0.1607  0.1317  0.0797]
 [ 0.0297  0.0038  0.0119  0.1057]]

Next, the demo computes the pseudo-inverse by using the SVD with the full_matrices set to False:

print("\nComputing SVD with full_matrices=False ")
U, s, Vh = np.linalg.svd(A, full_matrices=False)
print("\nU: ")
print(U)
print("\ns: ")
print(s)
print("\nVh: ")
print(Vh)

Uh = U.T
V = Vh.T
p = len(s)
Sinv = np.zeros((p,p))
for i in range(p):
  Sinv[i][i] = 1.0 / (s[i] + 1.0e-12)

# V * Sinv * Uh
A_pinv = np.matmul(V, np.matmul(Sinv,Uh))
print("\nA pinv() scratch with full_matrices=False \n")
print(A_pinv)

The output is the same as when computed directly by np.linalg.pinv() and is correct:

Computing SVD with full_matrices=False

U:
[[ 0.1662 -0.3022  0.6397]
 [ 0.3568  0.2561 -0.6442]
 [-0.7379 -0.5111 -0.3448]
 [ 0.5483 -0.7628 -0.2387]]

s:
[12.8087  7.423   3.292 ]

Vh:
[[-0.63   -0.314   0.7103]
 [-0.6613 -0.2628 -0.7026]
 [ 0.4073 -0.9123 -0.0421]]

A pinv() scratch with full_matrices=False

[[ 0.0979 -0.1201  0.0392  0.0115]
 [-0.1707  0.1607  0.1317  0.0797]
 [ 0.0297  0.0038  0.0119  0.1057]]

However, when the demo tries to compute the pseudo-inverse using SVD with the default full_matrices=True, the program fails. The code:

print("\nComputing SVD with full_matrices=True ")
U, s, Vh = np.linalg.svd(A, full_matrices=True) # default!
print("\nU: ")
print(U)
print("\ns: ")
print(s)
print("\nVh: ")
print(Vh)
print("\n")

Uh = U.T
V = Vh.T
p = len(s)
Sinv = np.zeros((p,p))
for i in range(p):
  Sinv[i][i] = 1.0 / (s[i] + 1.0e-12)

# V * Sinv * Uh
A_pinv = np.matmul(V, np.matmul(Sinv,Uh))
print("\nA pinv() scratch with full_matrices=True \n")
print(A_pinv)

The output:

Computing SVD with full_matrices=True

U:
[[ 0.1662 -0.3022  0.6397 -0.6869]
 [ 0.3568  0.2561 -0.6442 -0.6262]
 [-0.7379 -0.5111 -0.3448 -0.2748]
 [ 0.5483 -0.7628 -0.2387  0.246 ]]

s:
[12.8087  7.423   3.292 ]

Vh:
[[-0.63   -0.314   0.7103]
 [-0.6613 -0.2628 -0.7026]
 [ 0.4073 -0.9123 -0.0421]]

Traceback (most recent call last):
  File "C:\VSM\PseudoInverse\pseudoinv_numpy.py",
 line 65, in
    A_pinv = np.matmul(V, np.matmul(Sinv,Uh))
                          ^^^^^^^^^^^^^^^^^^
ValueError: matmul: Input operand 1 has a mismatch
 in its core dimension 0, with gufunc signature
(n?,k),(k,m?)->(n?,m?) (size 4 is different from 3)

So, the question in my mind is, “Why is the default to svd() “full_matrices=True” when that causes calculation of the pseudo-inverse to fail?”

I have no answer to that. I know that SVD is used for dozens of different purposes in mathematics, so there may be scenarios where “full_matrices=True” is the correct option.

Over time, arcade machines have become more sensitive but much less interesting. Here are two fully_sensitive=False coin operated electro-mechanical games from Marvin’s Marvelous Mechanical Museum in West Bloomfield Township, Michigan.

Right: This old 1930s era automata machine from the UK depicts the Spanish Inquisition, complete with automated motion whipping, branding, and racking. Holy Moly!

Demo program:

# pseudoinv_numpy.py

import numpy as np
import scipy as sp

np.set_printoptions(precision=4, suppress=True)
A = np.array([
  [1, -2, 3],
  [-5, 0, 2],
  [8, 5, -4],
  [-1, 0, 9]])

print("\nA: ")
print(A)

print("\n============================== ")

print("\nA pinv() using np.linalg.pinv(): \n")
A_pinv = np.linalg.pinv(A)
print(A_pinv)

print("\n============================== ")

print("\nComputing SVD with full_matrices=False ")
U, s, Vh = np.linalg.svd(A, full_matrices=False)
print("\nU: ")
print(U)
print("\ns: ")
print(s)
print("\nVh: ")
print(Vh)

Uh = U.T
V = Vh.T
p = len(s)
Sinv = np.zeros((p,p))
for i in range(p):
  Sinv[i][i] = 1.0 / (s[i] + 1.0e-12)

# V * Sinv * Uh
A_pinv = np.matmul(V, np.matmul(Sinv,Uh))
print("\nA pinv() scratch with full_matrices=False \n")
print(A_pinv)

print("\n============================== ")

print("\nComputing SVD with full_matrices=True ")
U, s, Vh = np.linalg.svd(A, full_matrices=True)
print("\nU: ")
print(U)
print("\ns: ")
print(s)
print("\nVh: ")
print(Vh)
print("\n")

Uh = U.T
V = Vh.T
p = len(s)
Sinv = np.zeros((p,p))
for i in range(p):
  Sinv[i][i] = 1.0 / (s[i] + 1.0e-12)

# V * Sinv * Uh
A_pinv = np.matmul(V, np.matmul(Sinv,Uh))
print("\nA pinv() scratch with full_matrices=True \n")
print(A_pinv)

print("\n============================== ")
