Bottom line: My from-scratch implementation of Moore-Penrose pseudo-inverse using SVD (Householder + QR algorithm) works fine, but it has no advantage over the much simpler Moore-Penrose pseudo-inverse using QR (modified Gram-Schmidt) version.
The goal of a machine learning regression problem is to predict a single numeric value. For example, you might want to predict a person’s bank account balance based on age, annual income, outstanding loan debt, and so on. The simplest technique is linear regression. The prediction equation is y’ = (w0 * x0) + (w1 * x1) + . . + b, where the wi are constants called weights, the xi are predictor values, and b is a constant called the bias.
Training is the process of finding the values of the weights and bias, so that predicted y values closely match actual target y values in a set of training data. There are many ways to train a linear regression model. Three common techniques are 1.) using stochastic gradient descent (SGD), 2.) using relaxed Moore-Penrose pseudo-inverse, 3.) using pseudo-inverse via normal equations. Each of these techniques has several variations, and each variation has several sub-variations.
For example, the relaxed Moore-Penrose pseudo-inverse technique can be accomplished using QR Householder decomposition, QR Gram-Schmidt decomposition, QR Givens decomposition, SVD Golub-Reinsch, SVD Jacobi methods, SVD Lanczos, SVD Householder+QR. And as if this isn’t enough, each of these sub-variations has several significantly different implementation designs. Sheesh!
The training technique for linear regression that is considered the most stable is the SVD Householder+QR algorithm. It is used by the LAPACK library. However, the algorithm is blisteringly complex and is over 10,000 lines of Fortran code (direct and helpers).
I recently bit the bullet and implemented SVD Householder+QR using C#, and so I figured I’d put together a demo.
For the demo, I used one of my standard synthetic datasets. The data looks like:
-0.1660, 0.4406, -0.9998, -0.3953, -0.7065, 0.4840 0.0776, -0.1616, 0.3704, -0.5911, 0.7562, 0.1568 -0.9452, 0.3409, -0.1654, 0.1174, -0.7192, 0.8054 . . .
The first five values on each line are the predictors. The last value is the target to predict. The synthetic data was generated by a 5-10-1 neural network with random weights and biases. Therefore, the data has a complex underlying structure that can be predicted, but not very well by a linear model. There are 200 training items and 40 test items.
The output of the demo is:
Begin C# linear regression using pseudo-inverse (SVD) training Loading synthetic train (200) and test (40) data Done First three train X: -0.1660 0.4406 -0.9998 -0.3953 -0.7065 0.0776 -0.1616 0.3704 -0.5911 0.7562 -0.9452 0.3409 -0.1654 0.1174 -0.7192 First three train y: 0.4840 0.1568 0.8054 Creating and training Linear Regression model using SVD p-inverse Done Coefficients/weights: -0.2656 0.0333 -0.0454 0.0358 -0.1146 Bias/constant: 0.3619 Evaluating model Accuracy train (within 0.10) = 0.4600 Accuracy test (within 0.10) = 0.6500 MSE train = 0.0026 MSE test = 0.0020 Predicting for x = -0.1660 0.4406 -0.9998 -0.3953 -0.7065 Predicted y = 0.5329 End demo
I validated the demo by running the data through the scikit-learn LinearRegressor module — the results were identical.
However, my from-scratch implementation of MP pseudo-inverse via the extremely complicated SVD (Householder + QR) has no advantage over the dramatically simpler MP pseudo-inverse via QR (modified Gram-Schmidt).
Good fun.
A classic linear regression problem is to predict a person’s weight from height, age, sex, profession, and so on. I used to fly a lot and I still fly frequently. Predicting the weight of a flight attendant is heavily (adjective intended) dependent on whether the attendant flies for a U.S. airline or she flies for an airline from virtually any other country.
Left: A European flight attendant.
Center: An Asian flight attendant.
Right: A U.S. flight attendant.
Demo program. Very long, very complex. Replace “lt” (less than), “gt”, “lte”, “gte” with Boolean operator symbols (my blog editor chokes on symbols.
using System;
using System.IO;
using System.Collections.Generic;
namespace LinearRegressionPinv_SVD
{
internal class LinearRegressionProgram
{
static void Main(string[] args)
{
Console.WriteLine("\nBegin C# linear regression" +
" using pseudo-inverse (SVD) training ");
// 1. load data
Console.WriteLine("\nLoading synthetic train" +
" (200) and test (40) data");
string trainFile =
"..\\..\\..\\Data\\synthetic_train_200.txt";
int[] colsX = new int[] { 0, 1, 2, 3, 4 };
double[][] trainX =
MatLoad(trainFile, colsX, ',', "#");
double[] trainY =
MatToVec(MatLoad(trainFile,
new int[] { 5 }, ',', "#"));
string testFile =
"..\\..\\..\\Data\\synthetic_test_40.txt";
double[][] testX =
MatLoad(testFile, colsX, ',', "#");
double[] testY =
MatToVec(MatLoad(testFile,
new int[] { 5 }, ',', "#"));
Console.WriteLine("Done ");
Console.WriteLine("\nFirst three train X: ");
for (int i = 0; i "lt" 3; ++i)
VecShow(trainX[i], 4, 8);
Console.WriteLine("\nFirst three train y: ");
for (int i = 0; i "lt" 3; ++i)
Console.WriteLine(trainY[i].ToString("F4").
PadLeft(8));
// 2. create and train model using pseudo-inverse
Console.WriteLine("\nCreating and training" +
" Linear Regression model using SVD p-inverse ");
LinearRegressor model = new LinearRegressor();
model.TrainPinv(trainX, trainY);
Console.WriteLine("Done ");
// 2b. show model parameters
Console.WriteLine("\nCoefficients/weights: ");
for (int i = 0; i "lt" model.weights.Length; ++i)
Console.Write(model.weights[i].ToString("F4") + " ");
Console.WriteLine("\nBias/constant: " +
model.bias.ToString("F4"));
// 3. evaluate model
Console.WriteLine("\nEvaluating model ");
double accTrain = model.Accuracy(trainX, trainY, 0.10);
Console.WriteLine("\nAccuracy train (within 0.10) = " +
accTrain.ToString("F4"));
double accTest = model.Accuracy(testX, testY, 0.10);
Console.WriteLine("Accuracy test (within 0.10) = " +
accTest.ToString("F4"));
double mseTrain = model.MSE(trainX, trainY);
Console.WriteLine("\nMSE train = " +
mseTrain.ToString("F4"));
double mseTest = model.MSE(testX, testY);
Console.WriteLine("MSE test = " +
mseTest.ToString("F4"));
// 4. use model to predict first training item
double[] x = trainX[0];
Console.WriteLine("\nPredicting for x = ");
VecShow(x, 4, 9);
double predY = model.Predict(x);
Console.WriteLine("\nPredicted y = " +
predY.ToString("F4"));
Console.WriteLine("\nEnd demo ");
Console.ReadLine();
} // Main()
// ------------------------------------------------------
// helpers for Main(): MatLoad(), MatToVec(), VecShow()
// ------------------------------------------------------
static double[][] MatLoad(string fn, int[] usecols,
char sep, string comment)
{
List"lt"double[]"gt" result =
new List"lt"double[]"gt"();
string line = "";
FileStream ifs = new FileStream(fn, FileMode.Open);
StreamReader sr = new StreamReader(ifs);
while ((line = sr.ReadLine()) != null)
{
if (line.StartsWith(comment) == true)
continue;
string[] tokens = line.Split(sep);
List"lt"double"gt" lst = new List"lt"double"gt"();
for (int j = 0; j "lt" usecols.Length; ++j)
lst.Add(double.Parse(tokens[usecols[j]]));
double[] row = lst.ToArray();
result.Add(row);
}
sr.Close(); ifs.Close();
return result.ToArray();
}
static double[] MatToVec(double[][] mat)
{
int nRows = mat.Length;
int nCols = mat[0].Length;
double[] result = new double[nRows * nCols];
int k = 0;
for (int i = 0; i "lt" nRows; ++i)
for (int j = 0; j "lt" nCols; ++j)
result[k++] = mat[i][j];
return result;
}
static void VecShow(double[] vec, int dec, int wid)
{
for (int i = 0; i "lt" vec.Length; ++i)
Console.Write(vec[i].ToString("F" + dec).
PadLeft(wid));
Console.WriteLine("");
}
} // class Program
// ========================================================
public class LinearRegressor
{
public double[] weights;
public double bias;
private Random rnd;
// ------------------------------------------------------
public LinearRegressor(int seed = 0) // ctor
{
this.weights = new double[0]; // happy compiler
this.bias = 0;
this.rnd = new Random(seed); // not used this version
}
// ------------------------------------------------------
public double Predict(double[] x)
{
double result = 0.0;
for (int j = 0; j "lt" x.Length; ++j)
result += x[j] * this.weights[j];
result += this.bias;
return result;
}
// ------------------------------------------------------
public void TrainPinv(double[][] trainX, double[] trainY)
{
int dim = trainX[0].Length;
this.weights = new double[dim];
// w = pinv(dX) * y
double[][] X = MatDesignNested(trainX); // design mat
double[][] Xpinv = SVD.MatPinv(X);
double[] biasAndWts =
MatVecProductNested(Xpinv, trainY);
// extract bias and weights
this.bias = biasAndWts[0];
for (int i = 1; i "lt" biasAndWts.Length; ++i)
this.weights[i - 1] = biasAndWts[i];
return; // all done
// ````````````````````````````````````````````````````
static double[][] MatDesignNested(double[][] M)
{
int nRows = M.Length; int nCols = M[0].Length;
double[][] result = new double[nRows][];
for (int i = 0; i "lt" nRows; ++i)
result[i] = new double[nCols + 1];
for (int i = 0; i "lt" nRows; ++i)
{
result[i][0] = 1.0;
for (int j = 1; j "lt" nCols + 1; ++j)
result[i][j] = M[i][j - 1];
}
return result;
}
// ````````````````````````````````````````````````````
static double[] MatVecProductNested(double[][] A,
double[] v)
{
// A * v
double[] result = new double[A.Length];
for (int i = 0; i "lt" A.Length; ++i)
for (int k = 0; k "lt" A[0].Length; ++k)
result[i] += A[i][k] * v[k];
return result;
}
} // TrainPinv()
// ------------------------------------------------------
public double Accuracy(double[][] dataX, double[] dataY,
double pctClose)
{
int numCorrect = 0; int numWrong = 0;
for (int i = 0; i "lt" dataX.Length; ++i)
{
double actualY = dataY[i];
double predY = this.Predict(dataX[i]);
if (Math.Abs(predY - actualY) "lt"
Math.Abs(pctClose * actualY))
++numCorrect;
else
++numWrong;
}
return (numCorrect * 1.0) / (numWrong + numCorrect);
}
// ------------------------------------------------------
public double MSE(double[][] dataX, double[] dataY)
{
int n = dataX.Length;
double sum = 0.0;
for (int i = 0; i "lt" n; ++i)
{
double actualY = dataY[i];
double predY = this.Predict(dataX[i]);
sum += (actualY - predY) * (actualY - predY);
}
return sum / n;
}
// ------------------------------------------------------
} // class LinearRegressor
// ========================================================
public class SVD
{
public static double[][] MatPinv(double[][] A)
{
double[][] U; double[] s; double[][] Vh;
MatDecompSVD(A, out U, out s, out Vh);
double[][] Uh = MatTranspose(U);
double[][] V = MatTranspose(Vh);
double[][] S = MatMake(s.Length, s.Length);
for (int i = 0; i "lt" s.Length; ++i)
S[i][i] = 1.0 / (s[i] + 1.0e-12); // avoid div by 0
double[][] result = MatProduct(V, MatProduct(S, Uh));
return result;
}
// ------------------------------------------------------
public static void MatDecompSVD(double[][] A,
out double[][] U, out double[] s, out double[][] Vh,
double tol = 1.0e-12)
{
// SVD Householder + QR technique
int m = A.Length; int n = A[0].Length;
if (m "gte" n)
{
double[][] Q; double[][] R;
MatDecompQR(A, out Q, out R);
double[][] RtR = MatProduct(MatTranspose(R), R);
double[] evals; double[][] V;
MatDecompEigen(RtR, out evals, out V);
int[] sortIdxs = VecReversed(ArgSort(evals));
evals = VecSortedUsingIdxs(evals, sortIdxs);
V = MatSortedUsingIdxs(V, sortIdxs);
double[] ss = VecSqrt(VecClip(evals, 0.0));
int[] idxs = VecIndicesWhereNonNegative(ss, tol);
double[] ssNonZero = VecRemoveZeros(ss, idxs);
double[][] VNonZero = MatRemoveCols(V, idxs);
double[][] tmp1 = MatProduct(R, VNonZero);
double[][] tmp2 = MatDivVector(tmp1, ssNonZero);
double[][] UU = MatProduct(Q, tmp2);
U = UU;
s = ssNonZero;
Vh = MatTranspose(VNonZero);
} // m "gte" n
else
{
// use the transpose trick
double[][] dummyU;
double[] dummyS;
double[][] dummyVt;
MatDecompSVD(MatTranspose(A),
out dummyU, out dummyS, out dummyVt);
U = MatTranspose(dummyVt);
s = dummyS;
Vh = MatTranspose(dummyU);
} // m "lt" n
} // MatDecomp()
// ------------------------------------------------------
// primary helpers: MatDecompQR() and MatDecompEigen()
// ------------------------------------------------------
private static void MatDecompQR(double[][] A,
out double[][] Q, out double[][] R)
{
// reduced QR decomp using Householder reflections
int m = A.Length; int n = A[0].Length;
double[][] QQ = MatIdentity(m); // working Q
double[][] RR = MatCopy(A); // working R
for (int k = 0; k "lt" n; ++k)
{
double[] x = MatColToEnd(RR, k); // RR[k:, k]
double normx = VecNorm(x);
if (Math.Abs(normx) "lt" 1.0e-12) continue;
double[] v = VecCopy(x);
double sign;
if (x[0] "gte" 0.0) sign = 1.0; else sign = -1.0;
v[0] += sign * normx;
double normv = VecNorm(v);
for (int i = 0; i "lt" v.Length; ++i)
v[i] /= normv;
// apply reflection to R
double[][] tmp1 =
MatRowColToEnd(RR, k); // RR[k:, k:]
double[] tmp2 = VecMatProduct(v, tmp1);
double[][] tmp3 = VecOuter(v, tmp2);
double[][] B = MatScalarMult(2.0, tmp3);
MatSubtractCorner(RR, k, B); // R[k:, k:] -= B
// accumulate Q
double[][] tmp4 =
MatExtractAllRowsColToEnd(QQ, k); // QQ[:, k:]
double[] tmp5 = MatVecProduct(tmp4, v);
double[][] tmp6 = VecOuter(tmp5, v);
double[][] C = MatScalarMult(2.0, tmp6);
MatSubtractRows(QQ, k, C); // QQ[:, k:] -= C
} // for k
// return parts of QQ and RR
Q = MatExtractFirstCols(QQ, n); // Q[:, :n]
R = MatExtractFirstRows(RR, n); // R[:n, :]
} // MatDecompQR()
// ------------------------------------------------------
private static void MatDecompEigen(double[][] A,
out double[] evals, out double[][] Evecs,
double tol = 1.0e-12, int maxIter = 5000)
{
// eigen-decomp of symmetric matrix using QR
int m = A.Length; int n = A[0].Length;
double[][] AA = MatCopy(A); // don't destroy A
double[][] V = MatIdentity(n);
int iter = 0;
while (iter "lt" maxIter)
{
double[][] Q;
double[][] R;
MatDecompQR(AA, out Q, out R);
double[][] Anew = MatProduct(R, Q);
V = MatProduct(V, Q);
// # check convergence (off-diagonal norm)
double[] tmp1 = MatDiag(Anew);
double[][] tmp2 = MatCreateDiag(tmp1);
double[][] tmp3 = MatSubtract(Anew, tmp2);
double norm = MatNorm(tmp3);
if (norm "lt" tol)
{
AA = Anew; break;
}
AA = Anew;
++iter;
} // iter
if (iter == maxIter)
Console.WriteLine("Warn: exceeded maxIter ");
evals = MatDiag(AA);
Evecs = V;
} // MatDecompEigen()
// ------------------------------------------------------
// 32 secondary helpers
// ------------------------------------------------------
private static int[] ArgSort(double[] vec)
{
int n = vec.Length;
int[] idxs = new int[n];
for (int i = 0; i "lt" n; ++i)
idxs[i] = i;
double[] dup = new double[n];
for (int i = 0; i "lt" n; ++i)
dup[i] = vec[i]; // don't modify vec
// special C# overload
Array.Sort(dup, idxs); // sort idxs based on dup vals
return idxs;
}
// ------------------------------------------------------
private static double[][] MatMake(int nr, int nc)
{
double[][] result = new double[nr][];
for (int i = 0; i "lt" nr; ++i)
result[i] = new double[nc];
return result;
}
// ------------------------------------------------------
private static double[][] MatIdentity(int n)
{
double[][] result = MatMake(n, n);
for (int i = 0; i "lt" n; ++i)
result[i][i] = 1.0;
return result;
}
// ------------------------------------------------------
private static double[][] MatCopy(double[][] A)
{
int m = A.Length; int n = A[0].Length;
double[][] result = MatMake(m, n);
for (int i = 0; i "lt" m; ++i)
for (int j = 0; j "lt" n; ++j)
result[i][j] = A[i][j];
return result;
}
// ------------------------------------------------------
private static double[] MatDiag(double[][] A)
{
// return diag elements of A as a vector
int m = A.Length; int n = A[0].Length; // m == n
double[] result = new double[m];
for (int i = 0; i "lt" m; ++i)
result[i] = A[i][i];
return result;
}
// ------------------------------------------------------
private static double[][] MatCreateDiag(double[] v)
{
// create a matrix using v as diagonal elements
int n = v.Length;
double[][] result = MatMake(n, n);
for (int i = 0;i "lt" n; ++i)
result[i][i] = v[i];
return result;
}
// ------------------------------------------------------
private static double[][] MatTranspose(double[][] A)
{
int m = A.Length; int n = A[0].Length;
double[][] result = MatMake(n, m); // note
for (int i = 0; i "lt" m; ++i)
for (int j = 0; j "lt" n; ++j)
result[j][i] = A[i][j];
return result;
}
// ------------------------------------------------------
private static double[][] MatSubtract(double[][] A,
double[][] B)
{
int m = A.Length; int n = A[0].Length;
double[][] result = MatMake(m, n);
for (int i = 0; i "lt" m; ++i)
for (int j = 0; j "lt" n; ++j)
result[i][j] = A[i][j] - B[i][j];
return result;
}
// ------------------------------------------------------
private static double[] MatColToEnd(double[][] A,
int k)
{
// last part of col k, from [k,k] to end
int m = A.Length; int n = A[0].Length;
double[] result = new double[m - k];
for (int i = 0; i "lt" m - k; ++i)
result[i] = A[i + k][k];
return result;
}
// ------------------------------------------------------
private static double[][] MatRowColToEnd(double[][] A,
int k)
{
// block of A, row k to end, col k to end
// A[k:, k:]
int m = A.Length; int n = A[0].Length;
double[][] result = MatMake(m-k, n-k);
for (int i = 0; i "lt" m - k; ++i)
for (int j = 0; j "lt" n - k; ++j)
result[i][j] = A[i + k][j + k];
return result;
}
// ------------------------------------------------------
private static double[] MatVecProduct(double[][] A,
double[] v)
{
// A * v
int m = A.Length; int n = A[0].Length;
double[] result = new double[m];
for (int i = 0; i "lt" m; ++i)
for (int j = 0; j "lt" n; ++j)
result[i] += A[i][j] * v[j];
return result;
}
private static double[] VecMatProduct(double[] v,
double[][] A)
{
// v * A
int m = A.Length; int n = A[0].Length;
double[] result = new double[n];
for (int j = 0; j "lt" n; ++j)
for (int i = 0; i "lt" m; ++i)
result[j] += v[i] * A[i][j];
return result;
}
// ------------------------------------------------------
private static double[][] MatScalarMult(double x,
double[][] A)
{
// x * A element-wise
int m = A.Length; int n = A[0].Length;
double[][] result = MatMake(m, n);
for (int i = 0; i "lt" m; ++i)
for (int j = 0; j "lt" n; ++j)
result[i][j] = x * A[i][j];
return result;
}
// ------------------------------------------------------
private static void MatSubtractCorner(double[][] A,
int k, double[][] C)
{
// subtract elements in C from lower right A
// A[k:, k:] -= C
int m = A.Length; int n = A[0].Length;
for (int i = 0; i "lt" m - k; ++i)
for (int j = 0; j "lt" n - k; ++j)
A[i + k][j + k] -= C[i][j];
return; // modify A in-place
}
// ------------------------------------------------------
private static void MatSubtractRows(double[][] A,
int k, double[][] C)
{
// A[:, k:] -= C
int m = A.Length; int n = A[0].Length;
for (int i = 0; i "lt" m; ++i)
for (int j = 0; j "lt" n-k; ++j)
A[i][j+k] -= C[i][j];
return; // modify A in-place
}
// ------------------------------------------------------
private static double[][]
MatExtractAllRowsColToEnd(double[][] A, int k)
{
// A[:, k:]
int m = A.Length; int n = A[0].Length;
double[][] result = MatMake(m, n - k);
for (int i = 0; i "lt" m; ++i)
for (int j = 0; j "lt" n - k; ++j)
result[i][j] = A[i][j + k];
return result;
}
// -----------------------------------------------------
private static double[][]
MatExtractFirstCols(double[][] A, int k)
{
// A[:, :n]
int m = A.Length; int n = A[0].Length;
double[][] result = MatMake(m, k);
for (int i = 0; i "lt" m; ++i)
for (int j = 0; j "lt" k; ++j)
result[i][j] = A[i][j];
return result;
}
// ------------------------------------------------------
private static double[][]
MatExtractFirstRows(double[][] A, int k)
{
// A[:n, :]
int m = A.Length; int n = A[0].Length;
double[][] result = MatMake(k, n);
for (int i = 0; i "lt" k; ++i)
for (int j = 0; j "lt" n; ++j)
result[i][j] = A[i][j];
return result;
}
// ------------------------------------------------------
private static double[][] MatProduct(double[][] A,
double[][] B)
{
int aRows = A.Length;
int aCols = A[0].Length;
int bRows = B.Length;
int bCols = B[0].Length;
if (aCols != bRows)
throw new Exception("Non-conformable matrices");
double[][] result = MatMake(aRows, bCols);
for (int i = 0; i "lt" aRows; ++i) // each row of A
for (int j = 0; j "lt" bCols; ++j) // each col of B
for (int k = 0; k "lt" aCols; ++k)
result[i][j] += A[i][k] * B[k][j];
return result;
}
// ------------------------------------------------------
private static double[][] MatRemoveCols(double[][] A,
int[] idxs)
{
// remove the columns specified in idxs
int m = A.Length; int n = A[0].Length;
int countNonzeos = 0;
for (int i = 0; i "lt" idxs.Length; ++i)
if (idxs[i] == 1) ++countNonzeos;
double[][] result = MatMake(m, countNonzeos);
int k = 0; // destination col
for (int j = 0; j "lt" n; ++j)
{
if (idxs[j] == 0) continue; // skip this col
for (int i = 0; i "lt" m; ++i)
{
result[i][k] = A[i][j];
}
++k;
}
return result;
}
// ------------------------------------------------------
private static double[][] MatDivVector(double[][] A,
double[] v)
{
// v must be all non-zero
// divide each row of A by v, element-wise
int m = A.Length; int n = A[0].Length;
double[][] result = MatMake(m, n);
for (int i = 0; i "lt" m; ++i)
for (int j= 0; j "lt" n; ++j)
result[i][j] = A[i][j] / v[j];
return result;
}
// ------------------------------------------------------
private static double MatNorm(double[][] A)
{
// treat A as one big vector
int m = A.Length; int n = A[0].Length;
double sum = 0.0;
for (int i = 0; i "lt" m; ++i)
for (int j = 0; j "lt" n; ++j)
sum += A[i][j] * A[i][j];
return Math.Sqrt(sum);
}
private static double VecNorm(double[] v)
{
// standard vector norm
double sum = 0.0;
for (int i = 0; i "lt" v.Length; ++i)
sum += v[i] * v[i];
return Math.Sqrt(sum);
}
// ------------------------------------------------------
private static double[][]
MatSortedUsingIdxs(double[][] A, int[] idxs)
{
// arrange columns of A using order in idxs
int m = A.Length; int n = A[0].Length;
double[][] result = MatMake(m, n);
for (int i = 0; i "lt" m; ++i)
{
for (int j = 0; j "lt" n; ++j)
{
int srcCol = idxs[j];
result[i][j] = A[i][srcCol];
}
}
return result;
}
// ------------------------------------------------------
private static double[]
VecSortedUsingIdxs(double[] v, int[] idxs)
{
// arrange values in v using order specified in idxs
int n = v.Length;
double[] result = new double[n];
for (int i = 0; i "lt" n; ++i)
result[i] = v[idxs[i]];
return result;
}
// ------------------------------------------------------
private static double[] VecCopy(double[] v)
{
double[] result = new double[v.Length];
for (int i = 0; i "lt" v.Length; ++i)
result[i] = v[i];
return result;
}
// ------------------------------------------------------
private static double[][] VecOuter(double[] v1,
double[] v2)
{
// vector outer product
double[][] result = MatMake(v1.Length, v2.Length);
for (int i = 0; i "lt" v1.Length; ++i)
for (int j = 0; j "lt" v2.Length; ++j)
result[i][j] = v1[i] * v2[j];
return result;
}
// ------------------------------------------------------
private static int[] VecReversed(int[] v)
{
// return vector of v elements in reversed order
int n = v.Length;
int[] result = new int[n];
for (int i = 0; i "lt" n; ++i)
result[i] = v[n-1-i];
return result;
}
// ------------------------------------------------------
private static double[] VecClip(double[] v,
double minVal)
{
// used to make sure no negative values
int n = v.Length;
double[] result = new double[n];
for (int i = 0; i "lt" n; ++i)
{
if (v[i] "lt" minVal)
result[i] = minVal;
else
result[i] = v[i];
}
return result;
}
// ------------------------------------------------------
private static double[] VecSqrt(double[] v)
{
// sqrt each element in v
// assumes v has no negative values
int n = v.Length;
double[] result = new double[n];
for (int i = 0; i "lt" n; ++i)
result[i] = Math.Sqrt(v[i]);
return result;
}
// ------------------------------------------------------
private static int[]
VecIndicesWhereNonNegative(double[] v, double tol)
{
// indices of non-negative values (within tolerance)
int n = v.Length;
int[] result = new int[n];
for (int i = 0; i "lt" n; ++i)
{
if (Math.Abs(v[i]) "gt" tol)
result[i] = 1;
}
return result;
}
// ------------------------------------------------------
private static double[] VecRemoveZeros(double[] v,
int[] idxs)
{
// if idx = 1, val is non-zero, if 0 val is near zero
int n = v.Length;
List"lt"double"gt" lst = new List"lt"double"gt"();
for (int i = 0; i "lt" n; ++i)
{
if (idxs[i] == 1)
lst.Add(v[i]);
}
return lst.ToArray();
}
// ------------------------------------------------------
} // class SVD
// ========================================================
} // ns
Training data:
# synthetic_train_200.txt # -0.1660, 0.4406, -0.9998, -0.3953, -0.7065, 0.4840 0.0776, -0.1616, 0.3704, -0.5911, 0.7562, 0.1568 -0.9452, 0.3409, -0.1654, 0.1174, -0.7192, 0.8054 0.9365, -0.3732, 0.3846, 0.7528, 0.7892, 0.1345 -0.8299, -0.9219, -0.6603, 0.7563, -0.8033, 0.7955 0.0663, 0.3838, -0.3690, 0.3730, 0.6693, 0.3206 -0.9634, 0.5003, 0.9777, 0.4963, -0.4391, 0.7377 -0.1042, 0.8172, -0.4128, -0.4244, -0.7399, 0.4801 -0.9613, 0.3577, -0.5767, -0.4689, -0.0169, 0.6861 -0.7065, 0.1786, 0.3995, -0.7953, -0.1719, 0.5569 0.3888, -0.1716, -0.9001, 0.0718, 0.3276, 0.2500 0.1731, 0.8068, -0.7251, -0.7214, 0.6148, 0.3297 -0.2046, -0.6693, 0.8550, -0.3045, 0.5016, 0.2129 0.2473, 0.5019, -0.3022, -0.4601, 0.7918, 0.2613 -0.1438, 0.9297, 0.3269, 0.2434, -0.7705, 0.5171 0.1568, -0.1837, -0.5259, 0.8068, 0.1474, 0.3307 -0.9943, 0.2343, -0.3467, 0.0541, 0.7719, 0.5581 0.2467, -0.9684, 0.8589, 0.3818, 0.9946, 0.1092 -0.6553, -0.7257, 0.8652, 0.3936, -0.8680, 0.7018 0.8460, 0.4230, -0.7515, -0.9602, -0.9476, 0.1996 -0.9434, -0.5076, 0.7201, 0.0777, 0.1056, 0.5664 0.9392, 0.1221, -0.9627, 0.6013, -0.5341, 0.1533 0.6142, -0.2243, 0.7271, 0.4942, 0.1125, 0.1661 0.4260, 0.1194, -0.9749, -0.8561, 0.9346, 0.2230 0.1362, -0.5934, -0.4953, 0.4877, -0.6091, 0.3810 0.6937, -0.5203, -0.0125, 0.2399, 0.6580, 0.1460 -0.6864, -0.9628, -0.8600, -0.0273, 0.2127, 0.5387 0.9772, 0.1595, -0.2397, 0.1019, 0.4907, 0.1611 0.3385, -0.4702, -0.8673, -0.2598, 0.2594, 0.2270 -0.8669, -0.4794, 0.6095, -0.6131, 0.2789, 0.4700 0.0493, 0.8496, -0.4734, -0.8681, 0.4701, 0.3516 0.8639, -0.9721, -0.5313, 0.2336, 0.8980, 0.1412 0.9004, 0.1133, 0.8312, 0.2831, -0.2200, 0.1782 0.0991, 0.8524, 0.8375, -0.2102, 0.9265, 0.2150 -0.6521, -0.7473, -0.7298, 0.0113, -0.9570, 0.7422 0.6190, -0.3105, 0.8802, 0.1640, 0.7577, 0.1056 0.6895, 0.8108, -0.0802, 0.0927, 0.5972, 0.2214 0.1982, -0.9689, 0.1870, -0.1326, 0.6147, 0.1310 -0.3695, 0.7858, 0.1557, -0.6320, 0.5759, 0.3773 -0.1596, 0.3581, 0.8372, -0.9992, 0.9535, 0.2071 -0.2468, 0.9476, 0.2094, 0.6577, 0.1494, 0.4132 0.1737, 0.5000, 0.7166, 0.5102, 0.3961, 0.2611 0.7290, -0.3546, 0.3416, -0.0983, -0.2358, 0.1332 -0.3652, 0.2438, -0.1395, 0.9476, 0.3556, 0.4170 -0.6029, -0.1466, -0.3133, 0.5953, 0.7600, 0.4334 -0.4596, -0.4953, 0.7098, 0.0554, 0.6043, 0.2775 0.1450, 0.4663, 0.0380, 0.5418, 0.1377, 0.2931 -0.8636, -0.2442, -0.8407, 0.9656, -0.6368, 0.7429 0.6237, 0.7499, 0.3768, 0.1390, -0.6781, 0.2185 -0.5499, 0.1850, -0.3755, 0.8326, 0.8193, 0.4399 -0.4858, -0.7782, -0.6141, -0.0008, 0.4572, 0.4197 0.7033, -0.1683, 0.2334, -0.5327, -0.7961, 0.1776 0.0317, -0.0457, -0.6947, 0.2436, 0.0880, 0.3345 0.5031, -0.5559, 0.0387, 0.5706, -0.9553, 0.3107 -0.3513, 0.7458, 0.6894, 0.0769, 0.7332, 0.3170 0.2205, 0.5992, -0.9309, 0.5405, 0.4635, 0.3532 -0.4806, -0.4859, 0.2646, -0.3094, 0.5932, 0.3202 0.9809, -0.3995, -0.7140, 0.8026, 0.0831, 0.1600 0.9495, 0.2732, 0.9878, 0.0921, 0.0529, 0.1289 -0.9476, -0.6792, 0.4913, -0.9392, -0.2669, 0.5966 0.7247, 0.3854, 0.3819, -0.6227, -0.1162, 0.1550 -0.5922, -0.5045, -0.4757, 0.5003, -0.0860, 0.5863 -0.8861, 0.0170, -0.5761, 0.5972, -0.4053, 0.7301 0.6877, -0.2380, 0.4997, 0.0223, 0.0819, 0.1404 0.9189, 0.6079, -0.9354, 0.4188, -0.0700, 0.1907 -0.1428, -0.7820, 0.2676, 0.6059, 0.3936, 0.2790 0.5324, -0.3151, 0.6917, -0.1425, 0.6480, 0.1071 -0.8432, -0.9633, -0.8666, -0.0828, -0.7733, 0.7784 -0.9444, 0.5097, -0.2103, 0.4939, -0.0952, 0.6787 -0.0520, 0.6063, -0.1952, 0.8094, -0.9259, 0.4836 0.5477, -0.7487, 0.2370, -0.9793, 0.0773, 0.1241 0.2450, 0.8116, 0.9799, 0.4222, 0.4636, 0.2355 0.8186, -0.1983, -0.5003, -0.6531, -0.7611, 0.1511 -0.4714, 0.6382, -0.3788, 0.9648, -0.4667, 0.5950 0.0673, -0.3711, 0.8215, -0.2669, -0.1328, 0.2677 -0.9381, 0.4338, 0.7820, -0.9454, 0.0441, 0.5518 -0.3480, 0.7190, 0.1170, 0.3805, -0.0943, 0.4724 -0.9813, 0.1535, -0.3771, 0.0345, 0.8328, 0.5438 -0.1471, -0.5052, -0.2574, 0.8637, 0.8737, 0.3042 -0.5454, -0.3712, -0.6505, 0.2142, -0.1728, 0.5783 0.6327, -0.6297, 0.4038, -0.5193, 0.1484, 0.1153 -0.5424, 0.3282, -0.0055, 0.0380, -0.6506, 0.6613 0.1414, 0.9935, 0.6337, 0.1887, 0.9520, 0.2540 -0.9351, -0.8128, -0.8693, -0.0965, -0.2491, 0.7353 0.9507, -0.6640, 0.9456, 0.5349, 0.6485, 0.1059 -0.0462, -0.9737, -0.2940, -0.0159, 0.4602, 0.2606 -0.0627, -0.0852, -0.7247, -0.9782, 0.5166, 0.2977 0.0478, 0.5098, -0.0723, -0.7504, -0.3750, 0.3335 0.0090, 0.3477, 0.5403, -0.7393, -0.9542, 0.4415 -0.9748, 0.3449, 0.3736, -0.1015, 0.8296, 0.4358 0.2887, -0.9895, -0.0311, 0.7186, 0.6608, 0.2057 0.1570, -0.4518, 0.1211, 0.3435, -0.2951, 0.3244 0.7117, -0.6099, 0.4946, -0.4208, 0.5476, 0.1096 -0.2929, -0.5726, 0.5346, -0.3827, 0.4665, 0.2465 0.4889, -0.5572, -0.5718, -0.6021, -0.7150, 0.2163 -0.7782, 0.3491, 0.5996, -0.8389, -0.5366, 0.6516 -0.5847, 0.8347, 0.4226, 0.1078, -0.3910, 0.6134 0.8469, 0.4121, -0.0439, -0.7476, 0.9521, 0.1571 -0.6803, -0.5948, -0.1376, -0.1916, -0.7065, 0.7156 0.2878, 0.5086, -0.5785, 0.2019, 0.4979, 0.2980 0.2764, 0.1943, -0.4090, 0.4632, 0.8906, 0.2960 -0.8877, 0.6705, -0.6155, -0.2098, -0.3998, 0.7107 -0.8398, 0.8093, -0.2597, 0.0614, -0.0118, 0.6502 -0.8476, 0.0158, -0.4769, -0.2859, -0.7839, 0.7715 0.5751, -0.7868, 0.9714, -0.6457, 0.1448, 0.1175 0.4802, -0.7001, 0.1022, -0.5668, 0.5184, 0.1090 0.4458, -0.6469, 0.7239, -0.9604, 0.7205, 0.0779 0.5175, 0.4339, 0.9747, -0.4438, -0.9924, 0.2879 0.8678, 0.7158, 0.4577, 0.0334, 0.4139, 0.1678 0.5406, 0.5012, 0.2264, -0.1963, 0.3946, 0.2088 -0.9938, 0.5498, 0.7928, -0.5214, -0.7585, 0.7687 0.7661, 0.0863, -0.4266, -0.7233, -0.4197, 0.1466 0.2277, -0.3517, -0.0853, -0.1118, 0.6563, 0.1767 0.3499, -0.5570, -0.0655, -0.3705, 0.2537, 0.1632 0.7547, -0.1046, 0.5689, -0.0861, 0.3125, 0.1257 0.8186, 0.2110, 0.5335, 0.0094, -0.0039, 0.1391 0.6858, -0.8644, 0.1465, 0.8855, 0.0357, 0.1845 -0.4967, 0.4015, 0.0805, 0.8977, 0.2487, 0.4663 0.6760, -0.9841, 0.9787, -0.8446, -0.3557, 0.1509 -0.1203, -0.4885, 0.6054, -0.0443, -0.7313, 0.4854 0.8557, 0.7919, -0.0169, 0.7134, -0.1628, 0.2002 0.0115, -0.6209, 0.9300, -0.4116, -0.7931, 0.4052 -0.7114, -0.9718, 0.4319, 0.1290, 0.5892, 0.3661 0.3915, 0.5557, -0.1870, 0.2955, -0.6404, 0.2954 -0.3564, -0.6548, -0.1827, -0.5172, -0.1862, 0.4622 0.2392, -0.4959, 0.5857, -0.1341, -0.2850, 0.2470 -0.3394, 0.3947, -0.4627, 0.6166, -0.4094, 0.5325 0.7107, 0.7768, -0.6312, 0.1707, 0.7964, 0.2757 -0.1078, 0.8437, -0.4420, 0.2177, 0.3649, 0.4028 -0.3139, 0.5595, -0.6505, -0.3161, -0.7108, 0.5546 0.4335, 0.3986, 0.3770, -0.4932, 0.3847, 0.1810 -0.2562, -0.2894, -0.8847, 0.2633, 0.4146, 0.4036 0.2272, 0.2966, -0.6601, -0.7011, 0.0284, 0.2778 -0.0743, -0.1421, -0.0054, -0.6770, -0.3151, 0.3597 -0.4762, 0.6891, 0.6007, -0.1467, 0.2140, 0.4266 -0.4061, 0.7193, 0.3432, 0.2669, -0.7505, 0.6147 -0.0588, 0.9731, 0.8966, 0.2902, -0.6966, 0.4955 -0.0627, -0.1439, 0.1985, 0.6999, 0.5022, 0.3077 0.1587, 0.8494, -0.8705, 0.9827, -0.8940, 0.4263 -0.7850, 0.2473, -0.9040, -0.4308, -0.8779, 0.7199 0.4070, 0.3369, -0.2428, -0.6236, 0.4940, 0.2215 -0.0242, 0.0513, -0.9430, 0.2885, -0.2987, 0.3947 -0.5416, -0.1322, -0.2351, -0.0604, 0.9590, 0.3683 0.1055, 0.7783, -0.2901, -0.5090, 0.8220, 0.2984 -0.9129, 0.9015, 0.1128, -0.2473, 0.9901, 0.4776 -0.9378, 0.1424, -0.6391, 0.2619, 0.9618, 0.5368 0.7498, -0.0963, 0.4169, 0.5549, -0.0103, 0.1614 -0.2612, -0.7156, 0.4538, -0.0460, -0.1022, 0.3717 0.7720, 0.0552, -0.1818, -0.4622, -0.8560, 0.1685 -0.4177, 0.0070, 0.9319, -0.7812, 0.3461, 0.3052 -0.0001, 0.5542, -0.7128, -0.8336, -0.2016, 0.3803 0.5356, -0.4194, -0.5662, -0.9666, -0.2027, 0.1776 -0.2378, 0.3187, -0.8582, -0.6948, -0.9668, 0.5474 -0.1947, -0.3579, 0.1158, 0.9869, 0.6690, 0.2992 0.3992, 0.8365, -0.9205, -0.8593, -0.0520, 0.3154 -0.0209, 0.0793, 0.7905, -0.1067, 0.7541, 0.1864 -0.4928, -0.4524, -0.3433, 0.0951, -0.5597, 0.6261 -0.8118, 0.7404, -0.5263, -0.2280, 0.1431, 0.6349 0.0516, -0.8480, 0.7483, 0.9023, 0.6250, 0.1959 -0.3212, 0.1093, 0.9488, -0.3766, 0.3376, 0.2735 -0.3481, 0.5490, -0.3484, 0.7797, 0.5034, 0.4379 -0.5785, -0.9170, -0.3563, -0.9258, 0.3877, 0.4121 0.3407, -0.1391, 0.5356, 0.0720, -0.9203, 0.3458 -0.3287, -0.8954, 0.2102, 0.0241, 0.2349, 0.3247 -0.1353, 0.6954, -0.0919, -0.9692, 0.7461, 0.3338 0.9036, -0.8982, -0.5299, -0.8733, -0.1567, 0.1187 0.7277, -0.8368, -0.0538, -0.7489, 0.5458, 0.0830 0.9049, 0.8878, 0.2279, 0.9470, -0.3103, 0.2194 0.7957, -0.1308, -0.5284, 0.8817, 0.3684, 0.2172 0.4647, -0.4931, 0.2010, 0.6292, -0.8918, 0.3371 -0.7390, 0.6849, 0.2367, 0.0626, -0.5034, 0.7039 -0.1567, -0.8711, 0.7940, -0.5932, 0.6525, 0.1710 0.7635, -0.0265, 0.1969, 0.0545, 0.2496, 0.1445 0.7675, 0.1354, -0.7698, -0.5460, 0.1920, 0.1728 -0.5211, -0.7372, -0.6763, 0.6897, 0.2044, 0.5217 0.1913, 0.1980, 0.2314, -0.8816, 0.5006, 0.1998 0.8964, 0.0694, -0.6149, 0.5059, -0.9854, 0.1825 0.1767, 0.7104, 0.2093, 0.6452, 0.7590, 0.2832 -0.3580, -0.7541, 0.4426, -0.1193, -0.7465, 0.5657 -0.5996, 0.5766, -0.9758, -0.3933, -0.9572, 0.6800 0.9950, 0.1641, -0.4132, 0.8579, 0.0142, 0.2003 -0.4717, -0.3894, -0.2567, -0.5111, 0.1691, 0.4266 0.3917, -0.8561, 0.9422, 0.5061, 0.6123, 0.1212 -0.0366, -0.1087, 0.3449, -0.1025, 0.4086, 0.2475 0.3633, 0.3943, 0.2372, -0.6980, 0.5216, 0.1925 -0.5325, -0.6466, -0.2178, -0.3589, 0.6310, 0.3568 0.2271, 0.5200, -0.1447, -0.8011, -0.7699, 0.3128 0.6415, 0.1993, 0.3777, -0.0178, -0.8237, 0.2181 -0.5298, -0.0768, -0.6028, -0.9490, 0.4588, 0.4356 0.6870, -0.1431, 0.7294, 0.3141, 0.1621, 0.1632 -0.5985, 0.0591, 0.7889, -0.3900, 0.7419, 0.2945 0.3661, 0.7984, -0.8486, 0.7572, -0.6183, 0.3449 0.6995, 0.3342, -0.3113, -0.6972, 0.2707, 0.1712 0.2565, 0.9126, 0.1798, -0.6043, -0.1413, 0.2893 -0.3265, 0.9839, -0.2395, 0.9854, 0.0376, 0.4770 0.2690, -0.1722, 0.9818, 0.8599, -0.7015, 0.3954 -0.2102, -0.0768, 0.1219, 0.5607, -0.0256, 0.3949 0.8216, -0.9555, 0.6422, -0.6231, 0.3715, 0.0801 -0.2896, 0.9484, -0.7545, -0.6249, 0.7789, 0.4370 -0.9985, -0.5448, -0.7092, -0.5931, 0.7926, 0.5402
Test data:
# synthetic_test_40.txt # 0.7462, 0.4006, -0.0590, 0.6543, -0.0083, 0.1935 0.8495, -0.2260, -0.0142, -0.4911, 0.7699, 0.1078 -0.2335, -0.4049, 0.4352, -0.6183, -0.7636, 0.5088 0.1810, -0.5142, 0.2465, 0.2767, -0.3449, 0.3136 -0.8650, 0.7611, -0.0801, 0.5277, -0.4922, 0.7140 -0.2358, -0.7466, -0.5115, -0.8413, -0.3943, 0.4533 0.4834, 0.2300, 0.3448, -0.9832, 0.3568, 0.1360 -0.6502, -0.6300, 0.6885, 0.9652, 0.8275, 0.3046 -0.3053, 0.5604, 0.0929, 0.6329, -0.0325, 0.4756 -0.7995, 0.0740, -0.2680, 0.2086, 0.9176, 0.4565 -0.2144, -0.2141, 0.5813, 0.2902, -0.2122, 0.4119 -0.7278, -0.0987, -0.3312, -0.5641, 0.8515, 0.4438 0.3793, 0.1976, 0.4933, 0.0839, 0.4011, 0.1905 -0.8568, 0.9573, -0.5272, 0.3212, -0.8207, 0.7415 -0.5785, 0.0056, -0.7901, -0.2223, 0.0760, 0.5551 0.0735, -0.2188, 0.3925, 0.3570, 0.3746, 0.2191 0.1230, -0.2838, 0.2262, 0.8715, 0.1938, 0.2878 0.4792, -0.9248, 0.5295, 0.0366, -0.9894, 0.3149 -0.4456, 0.0697, 0.5359, -0.8938, 0.0981, 0.3879 0.8629, -0.8505, -0.4464, 0.8385, 0.5300, 0.1769 0.1995, 0.6659, 0.7921, 0.9454, 0.9970, 0.2330 -0.0249, -0.3066, -0.2927, -0.4923, 0.8220, 0.2437 0.4513, -0.9481, -0.0770, -0.4374, -0.9421, 0.2879 -0.3405, 0.5931, -0.3507, -0.3842, 0.8562, 0.3987 0.9538, 0.0471, 0.9039, 0.7760, 0.0361, 0.1706 -0.0887, 0.2104, 0.9808, 0.5478, -0.3314, 0.4128 -0.8220, -0.6302, 0.0537, -0.1658, 0.6013, 0.4306 -0.4123, -0.2880, 0.9074, -0.0461, -0.4435, 0.5144 0.0060, 0.2867, -0.7775, 0.5161, 0.7039, 0.3599 -0.7968, -0.5484, 0.9426, -0.4308, 0.8148, 0.2979 0.7811, 0.8450, -0.6877, 0.7594, 0.2640, 0.2362 -0.6802, -0.1113, -0.8325, -0.6694, -0.6056, 0.6544 0.3821, 0.1476, 0.7466, -0.5107, 0.2592, 0.1648 0.7265, 0.9683, -0.9803, -0.4943, -0.5523, 0.2454 -0.9049, -0.9797, -0.0196, -0.9090, -0.4433, 0.6447 -0.4607, 0.1811, -0.2389, 0.4050, -0.0078, 0.5229 0.2664, -0.2932, -0.4259, -0.7336, 0.8742, 0.1834 -0.4507, 0.1029, -0.6294, -0.1158, -0.6294, 0.6081 0.8948, -0.0124, 0.9278, 0.2899, -0.0314, 0.1534 -0.1323, -0.8813, -0.0146, -0.0697, 0.6135, 0.2386
.NET Test Automation Recipes
Software Testing
SciPy Programming Succinctly
Keras Succinctly
R Programming
2026 Visual Studio Live
2025 Summer MLADS Conference
2026 DevIntersection Conference
2025 Machine Learning Week
2025 Ai4 Conference
2026 G2E Conference
2026 iSC West Conference
You must be logged in to post a comment.
